eGauge Display Caster
Visit the online store page
Model: EDC
eGauge Display Caster
The eGauge Display Caster provides an easy method display an eGauge meter device interface on
a TV or monitor via HDMI through an easy-to-use interface.
The Display Caster has a USB input for power, USB inputs for keyboard and mouse for initial
configuration, and an HDMI output to connect to a TV or monitor. Network/internet connection can
be obtained through built-in 2.4GHz WiFi or an Ethernet-direct connection.
Once the Display Caster is configured, the saved eGauge device interface will be displayed after
automatically recovering from a power outage or communication loss.
Specifications
USB-C powered*
USB for keyboard and mouse
Micro-HDMI to HDMI output*
2.4GHz b/g/n
* Versions shipped prior to 2023-08-18 are powered by Micro-USB and have a full-size HDMI port
Hardware included
eGauge Display Caster
USB-C to USB-A for power*
120V to USB-C power adapter for power*
Micro-HDMI to HDMI cable*
Printed Manual
Velcro for mounting
* Versions shipped prior to 2023-08-18 include a Micro-USB to USB-A cable, 120V to Micro-USB
adapter, and HDMI cable instead
Assembly/installation information
1. Connect keyboard and mouse via USB
2. Connect HDMI to television or monitor
3. Apply power using the 120V supply adapter, or USB-to-USB cable
The default password for the display caster is printed on the paper attached to the manual,
as well as inside the box with the eGauge Display Caster. The password can be changed
during setup.
Do not leave keyboard/mouse, or USB ports accessible in public kiosk display
4. Configure network, timezone, and device to display and save as default (see Display
Caster Manual for software setup information).
Software configuration Information
Ensure timezone is set correctly
Ensure default kiosk is saved
Follow the Display Caster Manual for software setup.
Factory Reset
Connect a keyboard and use the following key combination.
Current model: shift+escape, f, r, tab one at a time.
Older models: ctrl+shift+j simultaneously.
Documents
Display Caster Manual (current version)
Display Caster Manual (old version)
Please visit kb.egauge.net for the most up-to-date documentation.
