User Manual

2-IN-1 Gaming Headset

Language Guide

English

日本語

Français

Deutsch

Русский

Português

①

②

③

④

⑤

⑥

⑦

⑧

EKSA E900 Pro Gaming Headset

Detachable Microphone

Microphone Foam Cover

USB Audio Cable

3.5 mm Audio Cable

Carry Pouch

User Manual

Y Extension Cable

Package Contents

Specifications

Interface Type: 3.5 mm / USB

Driver Diameter: 50 mm

Sensitivity: 118 ± 3 dB

Impedance: 32 Ω

Frequency Response: 20 Hz – 20 kHz

Size: 6.0 mm * 2.7 mm

Sensitivity: -42 ± 3 dB (call mic)

Impedance: 2.2 kΩ

Supply Voltage: 3 V

Current Consumption: Max 0.5 mA

Leatherette Head Beam

Adjustable Headband

Protein Memory Foam Earmuffs

Detachable Microphone

Microphone Port

Type-C Audio Port

Light On/Off Button

Mic Mute Button

Volume Control Wheel

USB Audio Cable

3.5 mm Audio Cable

Y Extension Cable

Product Overview

①

②

③

④

⑤

⑥

⑦

⑧

⑨

⑩

⑪

⑫

Operation Guide

Light On/Off Button:

Volume Control Wheel:

Single click: Light on/off

Mic Mute Button:

Scroll downwards: Volume -

Scroll upwards: Volume +

Up: Microphone on

Down: Microphone off

Click

Main Features

0º

30º

60º

-60º

90º

-90º

60º

-60º

30º

0º

-30º

1. Immersive 7.1 Surround Sound

Before enjoying the 7.1 virtual surround sound, please make sure your

USB audio output is connected to the headset. Then you need to

download the EKSA Surround 7.1 driver from our official website

(https://www.eksa.net/download).

Note: EKSA Surround 7.1 driver only supports Windows system.

2. All-Platform Compatibility

The package includes two independent audio cables with different

interfaces. This gaming headset is widely compatible with PS®5, PS®4,

Xbox® One, Nintendo Switch™, PC, laptops, macOS, mobile devices, etc.

Nintendo Switch™

PC/macOS/Laptop

PS®4/PS®5

Xbox One® S/X mobile devices

Type-C interface

USB interface

3.5 mm interface

PS®4/PS®5

The first step

Please plug the

audio cable into

the headset first

The second step

Then plug the other side of the

audio cable into the device

USB Sound Settings

Windows®

macOS

Microphone Settings:

Audio Settings:

Follow the steps below to ensure your EKSA E900 Pro headset is the

default audio device.

[Control Panel]

[System Preferences] [Sound]

[Input] [EKSA E900 Pro]

[EKSA E900 Pro]

[Sound]

[Playback]

[EKSA E900 Pro (Set as Default Device)]

[Recording]

[Hardware and Sound]

[Control Panel]

[Sound]

[EKSA E900 Pro (Set as Default Device)]

[Output]

[Hardware and Sound]

[Settings]

[Sound]

[Microphone - Input Device - Headset (EKSA E900 Pro)]

[Adjust Microphone Level]

[Audio Output - Output Device - Headset (EKSA E900 Pro)]

[Switch Output Device Automatically]

[Volume - Headphones]

How to Use

PlayStation® 4 / PlayStation® 5:

Connect your PS®4/PS®5 directly using the USB or 3.5 mm audio

cable, and then follow the following steps to check the audio settings

to ensure that your PS®4/PS®5 automatically switches audio for

playback and microphone.

PS®4

PS®5

[Settings]

[Devices]

[Audio Devices]

[Output Device - Headset (EKSA E900 Pro)]

[Input Device - Headset (EKSA E900 Pro)]

[Volume Control (Headphones)]

[Adjust Microphone Level]

[Switch Output Device Automatically]

Guide for Xbox® Users

The controller has a 3.5 mm jack:

no adapter is required

The controller doesn't have a 3.5 mm

jack: a Microsoft adapter is required

(not included)

Xbox One® S/X controller Xbox® One controller (old version)

Xbox One® S/X:

To work on the NEW version of the Xbox One® S/X controller, you can

directly connect your headset to the controller via the 3.5 mm audio

cable.

Note:

1. The headset is not compatible with Xbox® 360.

2. Old version of Xbox® One needs a Microsoft adapter (not included).

How to Use

FAQ

Q1: My headset has no audio / I cannot hear anything from

my headset.

A: (1) First, ensure you’ve plugged the headset correctly into your

device. If that doesn’t work, check your audio settings to ensure

that you enable your speakers and don’t mute your device, then

check the volume of your device and headphone to ensure it is

at a proper level.

(2) Unplug the audio cable and reinsert it; wipe off the stains

or dust on the interface; reconnect the headset to your

device and check whether the microphone works properly now.

Q2: I cannot use the headset's microphone when connecting

to my computer.

A: (1) Go to Control Panel > Hardware and Sound > Sound. Disable the

onboard microphone on your computer, and make the Headset

Microphone default.

(2) Check that the microphone is not muted.

A: (1) Check that the microphone is not muted.

(2) Make sure that your headset is the default audio device through

the audio settings. Please refer to page 5 for more specific

sound setting methods.

(3) Make sure your device is compatible with the headset. The E900

Pro headset is not compatible with Xbox® 360, and the Old

version of Xbox® One needs an extra Microsoft adapter

(not included).

(4) If these have been confirmed and the headset is compatible with

the device, but the headset's microphone still cannot work,

please feel free to contact us (inf[email protected]).

Q3: The person on the other end of the call cannot hear me.
