EKSA H1 Plus Bedienungsanleitung

User Manual

H1 Plus

EKSAtelecom H1 Plus Wireless Headset

EKSA PC Adapter

Type-C Charging Cable

Replacement Ear Pad

Carry Pouch

User Manual

①

②

③

④

⑤

⑥

Package Contents

Specifications

Headset Bluetooth Version: 5.0

Effective Wireless Range: 30 m / 99 ft

Adapter Bluetooth Version: 5.2

Effective Wireless Range: 10 m / 32 ft

Music Time: ≈57 hours (70% volume)

Talk Time: ≈30 hours (70% volume)

Charging Time: ≈1.5 hours

Speaker Diameter: 40 mm

Impedance: 32 Ω ± 15%

Sensitivity: 114 ± 3 dB

Frequency Response: 20 Hz – 20 kHz

Size: 2.7 mm * 1.85 mm

Sensitivity: -25 ± 1 dB

Frequency Response: 100 Hz – 10 kHz

Impedance: 2.2 kΩ

Polar Pattern: Omnidirectional

Mic: EKSAtelecom VoicePure Technology

User Manual

H1 Plus

Product Overview

Call Indicator

EKSAtelecom VoicePure Technology

Type-C Charging Port

Volume +

Bluetooth Indicator

Multi-Function Button (MFB)

Volume -

Mic Mute Button

Charging Indicator

EKSA PC Adapter

Replacement Ear Pad

1110

Remove

Install

Operation Guide

Multi-Function Button:

Press for 3 seconds: Headphone on/off

Click: Play/Pause

Triple Click: Voice Assistant/Siri

Volume Button:

Click: Volume + / -

Press for 2 seconds

to next/previous track

2″

Mic Mute Button:

Siri

Click: Microphone on/off

3″

Call Functions

x1 Answer

Reject

Double Click

Click

Press for 2 seconds

Click

Hang up

Amy

Redial:

Call Handling:

Redial your last

call number

2″

Call Functions

Three-Way Calling:

Amy

00:10

On the phone

New call Tom

Amy

Click

Double Click Press for

2 seconds

2″

Answer a new

call and hang

up your

current call

Tom Amy Tom Amy TomAmy

Keep your

current call and

reject a new call

Tom Amy

Keep your

current call

Answer a

new call

Three-way calling mode

During a three-way call

Switch between two calls

Double Click

Bluetooth Pairing

EKSA-H1 Plus

1. Turn on EKSAtelecom H1

Plus, until its Bluetooth

indicator flashes alternately

between red and blue,

indicating that the headset

is in pairing mode.

2. Turn on the Bluetooth of your device, activate the search feature, and

select "EKSA-H1 Plus". After pairing, the Bluetooth indicator flashes

slowly in blue light with a voice prompt "your headset is connected",

confirming a successful connection.

3. To connect to a new device, turn off the Bluetooth of the currently paired

device and follow the above steps to connect successfully to a new device.

Note:

1. Keep the distance between the EKSAtelecom H1 Plus and your device within 1 meter.

2. If necessary, the pin code to complete pairing is "0000".

3. While in pairing state, if a connection cannot be established within 10 minutes, the

headset will turn off automatically.

4. When the headset is turned on again, it will connect to the last connected device

automatically.

Mobile

Phone:

3″

device A device B

Bluetooth Pairing

1. Plug the EKSA PC adapter into your PC's USB port. The adapter

will turn on automatically with a name of "EKSA PC Adapter"

displaying on your computer.

PC:

USB-A interface

Type-C interface

(Not included)

If you want to connect the headset to a PC, you can use the EKSA

PC adapter provided in the package. Then, you can enjoy the call

function and compatibility of the third-party software of the PC.

Follow the steps below to get it done.

Bluetooth Pairing

2. When enabled, the indicator on the EKSA PC adapter will flash a

blue light, which indicates that it is in pairing mode. Then, put the

headset on pairing mode and place it as close to the EKSA PC

adapter as possible (within 8 inches). The headset will automati-

cally connect to the EKSA PC adapter.

Note: It takes about 20 seconds to establish a connection between the headset and a PC for

the first time. Suppose the connection is unsuccessful, please unplug the adapter and

plug it back into the PC. Then restart the headset's pairing mode and reconnect to your

computer.

USB-A interface

Type-C interface

Indicator flashes in blue light

(Not included)

3. After the headset is successfully connected, the Bluetooth

indicator on the headset will slowly flash a blue light while the

EKSA PC adapter's indicator will always be blue.

Dual Pairing

EKSA-H1 Plus

OFF

1. After successfully connecting the EKSAtelecom H1 Plus to device

A, turn off the Bluetooth of device A. The headset’s Bluetooth

indicator flashes in red and blue alternately to signify pairing mode.

2. Turn on the Bluetooth of device B, activate search mode, and

connect to "EKSA-H1 Plus".

3. Turn on the Bluetooth of device A to connect with "EKSA-H1 Plus".

This puts both devices A and B in a simultaneous connection with

"EKSA-H1 Plus".

device A

device B device B
