EKSA E910 Bedienungsanleitung
5.8GHz Wireless
Gaming Headset
E910
User Manual
11, Headband: PU Leather + Stainless Steel
2, Head Clip: ABS
3, Fork: Aluminum Alloy
4, Shell: ABS
5, Stretchable Mic: ABS
6, Earmuffs: PU Leather Memory Foam
7, LED Light: Red EKSA Logo
8, Headbeam: Protein Leather Memory Foam
9, 5.8GHz USB Dongle
1
2
3
4
5
67
8
9
11
13
14
12
10
Overviews:
10, Volume Control Wheel: Volume Up/Down
11, LED Indicator
12, Mic Mute Button
13, Power Button: Headphones on/Headphones off
14, Charging Port: Type C
2Headphone Parameters:
USB Dongle Parameters:
Speaker Diameter
Signal Reception Strength
Signal Transmission Strength
Transmission Delay
Libattery Capacity
Charging Time
Working Time
Connection Status Standby Time
Off Status Standby Time
Working Voltage
Working Current
Charging Port
Φ50mm
-85dBm
3dBm
15 milliseconds
1200mA
about 4 hours
about 10 hours （at 70% Volume）about 200 hours
about 900 hours
DC 5V
100mA
Type C
Frequency
Signal Reception Strength
Signal Transmission Strength
Transmission Distance
Working Voltage
Working Current
5.8GHz
-85dBm
8dBm
15m/49ft (360°)
DC 5V
68mA
3Speaker Parameters:
Microphone Parameters:
Package Includes:
1* EKSA E910 Wireless Gaming Headset
1* 5.8G USB Dongle
1* 3.5mm Audio Cable
1* Leather Carry Pouch
1* Type C Charging Cable
1* User Manual
Speaker Diameter
Frequency Response
Speaker Sensitivity
Speaker Impedance
Standard Input Power
Max Input Power
Φ50mm Neodymium Driver
20Hz -20KHz
115dB ± 3dB
32Ω±15%
10mW
20mW
Working Voltage
Output Sound Pressure
Frequency Response
Microphone Directivity
3.2V-4.2V
-42±3dB
50Hz -10KHz
Unidirectional
4Key Descriptions:
1)Volume Control Wheel:
In the music or call status, the volume of dialing "+" will increase, and the volume of
dialing "-" will decrease;
2)LED Indicator:
a, Blue light flashes slowly, in Searching Signal status;
b, Blue light always on, in Connected status;
c, Red light always on, in Charging status;
d, Red light off, in Fully Charged status;
3)Mic Mute Button:
Shortly press the " " button to turn off the microphone, and headphones accompanied
by a "microphone off" prompt;
Press the " " button again to turn on the microphone, and headphones accompanied by
a "microphone on" prompt;
4)Power Button:
Press the “ ” button for 2-3 seconds to turn on the headphone, and accompanied by a
"Power on" prompt, the Blue light flash slowly; Press again the “ ” button for 2-3
seconds to turn off the headphone, and accompanied by a "Power off" prompt, the Blue
light off;
( Note 1: In the music or gaming status, shortly press the “ ” button, the Surround Sound
will turn on/off;
Note 2: If you hear a beep from the headset, it means that the battery is low, and the
headset will shut down in 20 minutes. You need to charge it; )
5How to Use?
1, Usage on Windows 7/8/10 PC
Plug the 5.8G USB Dongle into any USB ports that can work normally on PC. The headset will
automatically paired when it is turned on. Then you can use it without installing any
drivers.
2, Usage on Laptop
Step 1:
1. Insert the 5.8G USB Dongle into the USB port on the Laptop;
2. Open your ''Sound'' settings from ''Control Panel'' and select ''Hardware and Sound'' and
then select ''Sound''. (You can also right-click your sound icon on the system tray and select
Playback devices).
Step 2:
In the Playback tab, select ''USB Audio Devices'' from the list and click ''Set as Default Device''.
63, Usage on Mac/ Mac OS
Step 1, Insert the 5.8G USB Dongle into the USB port on Mac;
Step 2, In "System Preferences", click on the “Sound" icon;
Step 3, Click on the Input tab and select the “USB Audio Device" for default sound input;
Step 4, Click on the Output tab and select the “USB Audio Device" for default sound output;
4, Usage on PS4/PS5
Insert the 5.8G USB Dongle directly to the Playstation 4 Console and
follow these steps:
Step 1, Navigate to the Settings Menu and select it;
Step 2, Highlight the ''Devices '' menu option and select it;
Step 3, Scroll down to ''Audio Devices'' and select it;
Step 4, Choose ''Output to Headphones'' and select ''All Audio'';
7
TV
5, Usage on Xbox One (TV Mode)
Step 1, Power up the Xbox One console;
Step 2, Connect one side of the HDMI cable to “HDMI OUT TO TV” socket on Xbox One
console;
Step 3, Connect another side of the HDMI cable to TV;
Step 4, Turn on the TV power and switch the input mode to HDMI. Please make sure
the screen displays normally;
Step 5, Insert the 5.8G USB dongle to TV and play;
(Tips: Only suitable for the TV with USB 2.0 or USB 3.0 port!)
HDMI
86, Usage on Nintendo Switch (TV Mode)
Step 1, Open the back cover of the Nintendo Switch Dock;
Step 2, Connect the AC transformer to the top jack of Nintendo Switch Dock, and the
HDMI cable to the bottom jack. Close the back cover of the Nintendo Switch Dock;
Step 3, Connect the AC transformer to the outlet;
Step 4, Connect the HDMI cable to TV;
Step 5, Remove the left and right Joy-Cons from the console;
Step 6, Place the console in the center of the Nintendo Switch Dock and slowly
insert it from the top into the Nintendo Switch Dock. Once inserted to the bottom, the
console screen will disappear;
Step 7, Turn on the TV power and switch the input mode to HDM. Please make sure
the screen displays normally;
Step 8, Connect the 5.8G USB transmitter to TV and play;
(Tips: Only suitable for the TV with USB 2.0 or USB 3.0 port!)
TV
Vital Tips:
1, This wireless gaming headset is compatible with almost game devices, such as Win
7/8/10 PC, Xbox One, PS4/PS5, Nintendo Switch, Laptop, Mac/Mac OS, TV;
2, Please fully charge the headset before using it for the first time. And unplug the USB
charging cable immediately after fully charged;
3, Please make sure that the headset is off before charging it;
9After-Sales Service
Thank you for choosing EKSA, we hope you enjoy our products! If there is any questions
you can contact us via
HongKong Customer Center: +852 6940 4955
(Mon. to Fri. 9:00 a.m- 6:30 p.m, UTC+8 HKT)
India Customer Center: +91 8929 369 620
(Mon. to Fri. 9:30 a.m-5:30 p.m, IST)
Warm Notices
If you can’t connect the headset/headphones to your devices, please ask us for
complete FAQ guidance. You can find the solution finally;
Depending on your head/ear size/shape, it may be a little tight (feels like “on ear") for
someone to wear which is designed to avoid sound leakage. In case of that and to get
both audio and wearing comfort, please take off the headphone every 1~2 hours to get
your ears relaxed and protect them from the muggy environment in use;
Please read this User Manual carefully before using it, thank you!
