Elan RMK3 Bedienungsanleitung
The RMK3 Rack Mount Kit is designed to facilitate
mounting ELAN dual rack-space integrated Multi-Room
Controllers and Amplifiers into standard 19" equipment
racks in order to provide optimum air flow and heat dis-
persion for these units. The RMK3 will take up three rack
spaces when installed.
Features
• Provides Optimum Air Flow & Heat
Dispersion for ELAN Multi-Room
Controllers & Amplifiers
• Secure Rack-Mount Solution for ELAN
Dual Rack-Space Units
• Attractive Appearance
Installation
To install the RMK3 into a standard 19" equipment rack:
1. Slide the rack mount kit onto the unit from the
front as shown in Fig. 1.
2. Ensure that the unit is flush with the front of the
mounting kit. Install each of the eight screws
(included) through the side mounting flanges
into the holes in the sides of the unit as shown in
Fig. 2.
Important Note: Hand tighten screws! Over-
tightening could cause damage to the product
mounted in the RMK3.
3. Once the unit is securely mounted into the RMK3,
install the entire assembly into a standard 19”
equipment rack from the front using four rack
screws (not included). See Fig. 3.
19" Equipment Rack
Rack Screws
¸
RMK3 Rack Mount Kit
Fig. 1
Fig. 2
Fig. 3
1
Limited Lifetime Warranty
ELAN HOME SYSTEMS L.L.C. (“ELAN”) warrants to the original purchaser only that the RMK3 Rack Mount
Kit is free from defects in materials and workmanship provided that the product was purchased from an
authorized ELAN Home Systems Dealer. If the purchaser discovers that such item was not as warranted
above and promptly notifies ELAN in writing, ELAN shall repair or replace the item at the company’s option.
This warranty shall not apply (a) to equipment not manufactured by ELAN, (b) to equipment which shall have
been installed by other than an ELAN authorized installer, (c) to installed equipment which is not installed
to ELAN’s specifications, (d) to equipment which shall have been repaired or altered by others than ELAN,
(e) to equipment which shall have been subjected to negligence, accident, or damage by circumstances
beyond ELAN’s control, including, but not limited to, lightning, flood, electrical surge, tornado, earthquake,
or other catastrophic events beyond ELAN’s control, or to improper operation, maintenance or storage, or
to other than normal use of service. With respect to equipment sold by, but not manufactured by ELAN, the
warranty obligations of ELAN shall in all respects conform to the warranty actually extended to ELAN by its
supplier. The foregoing warranties do not cover reimbursement for labor, transportation, removal, installa-
tion or other expenses which may be incurred in connection with repair or replacement.
Except as may be expressly provided and authorized in writing by ELAN, ELAN shall not be subject to any
other obligations or liabilities whatsoever with respect to equipment manufactured by ELAN or services
rendered by ELAN.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESSED AND IMPLIED
WARRANTIES EXCEPT WARRANTIES OF TITLE, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
ATTENTION: TO OUR VALUED CONSUMERS
To ensure that consumers obtain quality pre-sale and after-sale support and service, ELAN Home Systems
products are sold exclusively through authorized dealers. ELAN products are not sold online. The warran-
ties on ELAN products are NOT VALID if the products have been purchased from an unauthorized dealer or
an online E-tailer. To determine if your ELAN reseller is authorized, please call ELAN Home Systems at (859)
269-7760.
2428 Palumbo Dr.
Lexington, KY USA 40509
Voice 859-269-7760
Tech Support 800-622-3526
www.elanhomesystems.com
2
RMK3 Rack Mount Kit
P/N 9900774 REV:A
