Elavon ICT250 Bedienungsanleitung

Thank you for choosing talech and Elavon.

This guide shows you how to set up and connect your iCT250 device to talech Register.

If you have any questions, contact talech support at support@talech.com or 888.995.1998.

Your iCT device supports the following payment methods:

***** *e.g. Apple Pay™

Chip & PIN Contactless

*Apple Pay™ is a registered trademark in the United States and other countries - 01 -

iCT250 Setup Guide

Installation

Remove box contents

Insert paper roll and connect ethernet cable

iCT250 Terminal

Magic Box

Power Supply

Phone Cable

Paper Roll

Your iCT box should include:

Li flap on top of the terminal and

insert the paper roll.

Connect an ethernet cable from the

magic box to your router.

- 02 -

(side view)

iCT250 Configuration

Open “Admin Menu”.

Press the “#” button from the home screen

to enter the Admin Menu.

Select “Communications”.

Select “Setup Menu”.

To select an option press the green button

or corresponding # on the keypad.

Select “Ethernet”.

- 03 -

ADMIN MENU

ADMIN MENU COMMUNICATIONS

1 - Clerk Menu

2 - Batch Menu

3 - Setup Menu

4 - Maintenance

1 - Merchant

2 - Communications

3 - Receipts

4 - Trans Options

1 - ComsPriority

2 - Dial

3 - Ethernet

4 - RS232

iCT250 Configuration

5 6

Press yellow button to go back

to the home screen.

Select “Ethernet Setup”. Select “Dynamic IP”.

NOTE: Write down IP address displayed.

- 04 -

8Press the “#” button from the

keypad to enter the Admin Menu.

(Shown in Step 7)

ETHERNET MENU ETHERNET SETUP

1 - Current Setup

2 - Ethernet Setup

3 - Timers Setup

1 - Dynamic IP

2 - Static IP

ADMIN MENU

1 - Merchant

2 - Communications

3 - Receipts

4 - Trans Options

iCT250 Configuration

9 10

11 Select “Enable SemiInteg”.

Select “Misc. Options”. Select “Semi-Integrated”.

- 05 -

12 Select the “On” option.

NOTE: This enables semi-integration.

SEMI-INTEGRATED

ETHERNET MENU MISC. OPTIONS

1 - Enable SemiInteg

2 - Communication Type

3 - Receipts Options

6 - Security

7 - Terminal Info

8 - Host Managment

9 - Misc. Options

1 - Semi-Integrated

SEMI-INTEGRATED

Enable SemiIntegrated

On O

iCT250 Configuration

- 06 -

Press yellow button to go back

to the Semi-Integrated menu.

Select “Communication Type”.

Select “Ethernet”. 16 Enter 6556 as the

Communications Port.

ETHERNET MENU

192.168.2.2

Enter Terminal

Port

6556

SEMI-INTEGRATED

1 - Enable SemiInteg

2 - Communication Type

3 - Receipts Options

1 - RS232

2 - USB

3 - Ethernet

iCT250 Configuration

- 06 -

Select “Receipts Options”.

Select the “ECR” option.

SEMI-INTEGRATED

RECEIPT OPTIONS

1 - Enable SemiInteg

2 - Communication Type

3 - Receipts Options

1 - ECR

2 - Terminal

17 Press yellow button to go back

to the Semi-Integrated menu.

talech App Configuration

Select Card Reader.

(highlighted in light blue)

Open talech Register on your iPad.

Select iCT220 and iCT250.

- 07 -

Go to the setting menu.

talech App Configuration

Enter the IP address and port

address obtained by the terminal.

(highlighted in light blue)

- 08 -

Go back to talech Register.

Settings are now saved.

Your iCT terminal now is connected to talech Register

and ready to accept payments.

email: support@talech.com | phone: 888.995.1998

Thank you again for choosing talech and Elavon to be part of your business experience.

If you have questions, please don’t hesitate to contact us. We are here 24/7.
