Measurement menu (Fig. 25)
The picture shows some available measure pages as example.
Application (see also
parameter menu “APPLiC”)
Total kvarh; kvar sys
Note*: in application F kvarh is calculated by both positive and negative
kvar integration
PF per phase, A, V LL, V LN, THD VLL, THD VLN, THD A, An, Working
hours.
Note: to see the THD measure the THD function must be enabled
Exported kWh (kWh-), working hours of exported kWh (h-)
Available variables only via RS485
V LN sys, V LL sys, VA sys, VA L1, VA L2, VA L3, var L1, var L2, var L3, W L1, W L2, W L3.
Wrong wiring detection function (supporting the voltages/currents connections to the metering
device).
Information menu (Fig. 26)
Available information pages for ALL MODELS
Disp. values in the example (fig.26)
Year of production and firmware release
Y 2017 (Year); r.A0 (revision)
kWh 0.001 (kWh per pulse); LED
Type of system and type of connection
SYS 3P.n (system, see also fig 6, 7);
4W (4 Wires connection)
Voltage transformer ratio
Pulse output: kWh per pulse
Serial communication address
Available information pages AEM35 ONLY
Disp. values in the example (fig.26)
Current transformer ratio
Available information pages for AEM35V ONLY
Disp. values in the example (fig.26)
Type of current sensor (Ct or RoG)
Current sensor nominal primary current
Measurement faults
If the measured signal exceeds the admitted analyser limits, a specific message appears:
• EEE blinking: the measured value is out of limits
• EEE on: the measurement depends on a value that is out of limits
NOTE: active and reactive energy measurements are displayed but do not change.
