PRODUCT WHITE PAPER

http://www.elitescreens.com

Elite Screens Inc. |Elite Screens Europe GmbH| Elite Screens India |Elite Screens China Ltd.

Elite Screens Taiwan Corp |Elite Screens Japan |Elite Screens Australia

  

Section 1: Screen Design .

1.1 What is it for?

Manually operated (non-motorized) retractable ront projection screen with integrated

mounting solutions allowing it to be installed on the wall or ceiling suspended. The

Manual Screen is or commercial or residential ront projection presentations. It is an

ultra a ordable, high per ormance, manual pull-down projection screen.

1.2 How does it work?

The manual screen utilizes a spring loaded auto-locking system or variable height

adjustments. Pulling the lanyard or center handle brings down the screen material to the

desired height. Gently stopping on the downward pull and guiding the material as it rises

a ew inches into its locked position. A gentle pull on the center handle or lanyard will

cause the locking mechanism to disengage allowing the spring loaded retraction

mechanism to draw the screen back up into the casing.

Section 2: Product Features .

2.1 Characteristics

Screen Material

• MaxWhite™ B screen material is durable and easy to clean

• 4K Ultra HD and Active 3D ready

• 180° wide viewing angle or commercial presentations or residential home cinema

• Black backed screen material eliminates light penetration or superior color reproduction

• Standard 4-side black masking borders

Design and Installation

• Available in 100” diagonal sizes in 1:1, 4:3, 16:9, and 16:10 aspect ratio, 120” diagonal in

4:3, 16:9, and 16:10, and 135” diagonal in 4:3 ad 16:9

• Screen lanyard or easy operation included – allows screen’s pull down handle to be

reached rom high areas

• Dual wall and ceiling installation design

• Optional 6” and 12” L brackets available

• 2-year warranty

2.2 Certifications

PRODUCT WHITE PAPER

http://www.elitescreens.com

Elite Screens Inc. |Elite Screens Europe GmbH| Elite Screens India |Elite Screens China Ltd.

Elite Screens Taiwan Corp |Elite Screens Japan |Elite Screens Australia

2.3 Model Nu bers

Model

Nu ber

Diagonal

Size

Aspect

Ratio

View

Height

(in)

View

Width

(in)

Screen

Material Gain Case

Color

Net

Weight

(lbs)

Gross

Weight

(lbs)

Packaging Di ensions

(LxHxW)

M100S 100" 1:1 71.0 71.0 MaxWhite B 1.0 White 12.2 14.5 89.0" x 4.7" x4.7"

M100V 100" 4:3 60.0 80.0 MaxWhite B 1.0 White 12.3 15.0 96.0"x 4.7" x 4.7"

M100H 100" 16:9 49.0 87.0 MaxWhite B 1.0 White 10.6 13.0 79.2" x 4.7" x 4.7"

M100X 100" 16:10 53.0 84.5 MaxWhite B 1.0 White 11.8 14.4 93.6"X4.7"X4.5"

M120V 120" 4:3 72.0 96.0 MaxWhite B 1.0 Black 21.6 25.4 114.7"x5.5"x5.5"

M120H 120" 16:9 58.8 104.6 MaxWhite B 1.0 Black 21.7 25.7 112.0"X5.5"X5.5"

M120X 120" 16:10 63.6 101.8 MaxWhite B 1.0 Black 21.4 24.7 106.1"x5.5"x5.5"

M135V 135” 4:3 81.0 108.0 MaxWhite B 1.0 White 30.3 37.6 118.0"x6.5"x6.0"

M135H 135” 16:9 66.2 117.2 MaxWhite B 1.0 Black 32.1 41.4 128.0"x6.3"x6.0"

Section 3: Screen Material Speci ications .

3.1 Characteristics

Elite’s MaxWhite™ B material is a matte white

material ormulated to meet our conventional

screens that delivers optimal picture quality. Its

neutral 1.0 gain allows or the widest possible

viewing angles o 180° (90° Le t and Right). The

matte sur ace o the MaxWhite™ B o ers superb

di usion uni ormity while delivering radiant

image and color reproduction. The screen sur ace

has black-backing to avoid light penetration and

can be cleaned sa ely with mild soap and water.

Features & Benefits

• Gain: 1.0

• Viewing Angle: 180° (90°LR)

• Black-backing

• Wide di usion uni ormity – maintains luminance levels throughout entire sur ace

• Sur ace can be cleaned with soap, water and a so t cloth

• Multi-Layer Weave and Textured

• Sur ace Coating

• Mildew Resistance

PRODUCT WHITE PAPER

http://www.elitescreens.com

Elite Screens Inc. |Elite Screens Europe GmbH| Elite Screens India |Elite Screens China Ltd.

Elite Screens Taiwan Corp |Elite Screens Japan |Elite Screens Australia

Specifications

Thickness

0.36 mm

Weight

350 g/m2

Maximum Height

3.2 M (10 t)

axis Gain

1.0

Hal

Gain Angle

Does not reach hal gain

3.2 Gain and Viewing Angle Chart

Section 4: Execution .

4.1 Installation Methods

Ceiling Installation

Wall Installation

PRODUCT WHITE PAPER

http://www.elitescreens.com

Elite Screens Inc. |Elite Screens Europe GmbH| Elite Screens India |Elite Screens China Ltd.

Elite Screens Taiwan Corp |Elite Screens Japan |Elite Screens Australia

Flush Wall Installation

1. Measure the distance of the keyholes on the end caps and mark the location of where

the screen is to be installed for the pre-drilled hole.

2. After marking the area and drilling the hole, insert the proper screw into the drilled

hole and leave about 1/ ” of an inch from the wall to mount the screen.

3. Mount your screen from the keyhole located on back of screen’s left and right end caps.

Note: Do not remove the end caps to mount the screen to the wall.

Removing the end caps will release the tension of the internal spring mechanism.

Note: No hardware is included with this screen for installation. For wall mounting in to drywall, drywall

anchors and screws will su ice to sustain the weight o this screen. For any other type o wall mounting,

please consult with your local hardware store to obtain the proper hardware.

Ceiling Installation

U-bolts included with Manual B series for hanging fro the

ceiling using chains and S-hooks. (Chains and S-hooks not

included)

Screen Operation

1. Pull the screen down from the lanyard or from the handle only

ata 90-degree angle. The screen is designed to lock at 2 inch

intervals. To achieve this, make sure to pull straight down and

allowing the screen to come up to lock into place. Do not attempt

to pull the screen down by the surface or touch the screen, as it

will damage the screen and void the warranty.

2. To retract the screen, simply pull the screen down more than 2

inches with a quick snap of the wrist and guide it back up in to the

housing without releasing the handle.

Attention: When retracting, always pull the screen down at a 90-degree

angle and do not let go until the screen is entirely inside the housing. I ever the screen eels stuck, keep in mind

that the screen’s mechanism is new and needs to be run up/down a ew times to loosen up. I this happens,

care ully, with a little orce, yank the screen straight down to unlock the mechanism.

Keyhole located on

back of end cap.

Side view

PRODUCT WHITE PAPER

http://www.elitescreens.com

Elite Screens Inc. |Elite Screens Europe GmbH| Elite Screens India |Elite Screens China Ltd.

Elite Screens Taiwan Corp |Elite Screens Japan |Elite Screens Australia

4.2 R-TYPE Installation Methods

A. Flush Wall Installation

1. Measure the distance of the keyholes on the end caps and mark the location of where

the screen is to be installed for the pre-drilled hole.

2. After marking the area and drilling the hole, insert the proper screw into the drilled

hole and leave about 1/ of an inch from the wall to mount the screen.

3. Mount your screen from the keyhole located on the back of the screen’s left and right end

caps.

B. Flush Ceiling Mounting (only for models 135” and above)

1. Measure the distance bet een the top scre holes located on the top of the end caps.

2. Mark the location o where the screen is to be installed or the pre-drilled hole.

3. Drill your hole, use a hollow wall anchor i needed

4. Insert the proper screw into the drilled hole and secure the screen to the ceiling.

C. Suspended Ceiling Installation for models 100”-120”)

1. You can hang the screen from the ceiling by using

chains (not included) and hooking them to the D-ring

loops on models 100”-120”, which are located on each end

of the end cap.

For models 135”- and above, D-ring or U-bolts (not

included) are required to create loops for anging t e

screen wit c ains from t eend caps’ flanges.

Note: Please consult with a hardware store pro essional or

proper screws or your speci ic wall or ceiling installation.

The installer must ensure that proper mounting hardware and

asteners used are o adequate strength and suitable or the mounting sur ace.

Models: 100

”

120

”

ring

Keyhole located on

back o end cap

Front view

Side view

Flange with a pair

o screw holes

Example shown is the end cap

or the 100”

–

120” models.

Models: 135

”

and above*

*U-bolts and D-ring not included.

PRODUCT WHITE PAPER

http://www.elitescreens.com

Elite Screens Inc. |Elite Screens Europe GmbH| Elite Screens India |Elite Screens China Ltd.

Elite Screens Taiwan Corp |Elite Screens Japan |Elite Screens Australia

Screen Operation

1. Pull the screen down from the lanyard or from the handle only at

a 90-degree angle. The screen is designed to lock at 2 inch intervals.

To achieve this, make sure to pull straight down and allowing the

screen to come up to lock into place. Do not attempt to pull the

screen down by the surface or touch the screen, as it will

damage the screen and void the warranty.

2. To retract the screen, simply pull the screen down more than two

inches with a quick snap of the wrist and guide it back up in to the

housing without releasing the handle.

Attention: When retracting, always pull the screen down at a 90-degree

angle and do not let go until the screen is entirely inside the housing. I ever the screen eels stuck, keep in mind

that the screen’s mechanism is new and needs to be run up/down a ew times to loosen up. I this happens,

care ully, with a little orce, yank the screen straight down to unlock the mechanism.

Section 5: Product Speci ications .

5.1.1 R-TYPE Di ensions for 100” and 120” odels

Model

Nu ber

Diag.

Size

Case

Length

(A)

View

(A1)

Screen

W (A2)

Weight

bar

Length

(A3)

Overall

Height

(B)

View

(B1)

Top

Border

(B2)

B3 B4 A4 B5 B6

Unit: Inches

M100V 100" 86.1 80.0 82.2 85.4 71.7 60.0 5.6 68.3 2.0 85.0 1.1 1.1

M100X 100" 88.7 87.0 84.8 88.0 63.8 53.0 4.7 60.5 2.0 87.6 1.1 1.1

M100S 100" 76.6 70.5 72.7 75.8 79.6 70.5 3.0 76.2 2.0 75.4 1.1 1.1

M100H 100" 93.3 87.2 89.4 92.5 59.9 49.0 4.7 56.5 2.0 92.1 1.1 1.1

M120V 120" 102.9 96.0 99.0 102.1 83.5 72.0 4.5 79.8 2.4 101.7 1.5 1.5

M120X 120" 108.7 101.8 104.8 107.9 75.1 63.6 4.5 71.3 2.4 107.5 1.5 1.5

M120H 120" 111.0 104.7 107.1 110.2 82.5 59.1 17.7 78.8 1.2 109.8 1.2 1.2

Unit:

M100V 100" 2188 2032 2088 2168 1821 1524 141 1736 50 2158 28 28

M100X 100" 2254 2210 2154 2234 1621 1346 119 1536 50 2224 28 28

M100S 100" 1946 1790 1846 1926 2021 1790 75 1936 50 1916 28 28

M100H 100" 2370 2214 2270 2350 1521 1245 120 1436 50 2340 28 28

M120V 120" 2614 2438 2514 2594 2121 1829 114 2026 62 2584 38 38

M120X

120"

2761

2585

2661

2741

1907

1615

114

1812

2731

M120H 120" 2820 2660 2720 2800 2096 1500 450 2001 30 2790 30 30

PRODUCT WHITE PAPER

http://www.elitescreens.com

Elite Screens Inc. |Elite Screens Europe GmbH| Elite Screens India |Elite Screens China Ltd.

Elite Screens Taiwan Corp |Elite Screens Japan |Elite Screens Australia

5.1.2 R-TYPE Di ensions for 135” odels

5.2.1 Drawings for 100” and 120” odels

Model

Nu ber

Diag.

Size

Case

Length

(A)

View

W (A1)

Screen

W (A2)

Weight

bar

Length

(A3)

Overall

Height

(B)

View

H (B1) B2 B3 B4 A4 Left/Right

Border

Unit: Inches

M135V 135” 115.7 107.9 111.0 114.2 105.4 81.1 17.7 101.2 1.6 113.8 1.6

M135H 135” 126.0 118.1 121.3 124.4 90.9 66.5 17.7 86.7 1.6 124.0 1.6

Unit:

M135V 135” 2940 2740 2820 2900 2678 2060 450 2571 40 2890 40

M135H 135” 3200 3000 3080 3160 2308 1690 450 2201 40 3150 40

PRODUCT WHITE PAPER

http://www.elitescreens.com

Elite Screens Inc. |Elite Screens Europe GmbH| Elite Screens India |Elite Screens China Ltd.

Elite Screens Taiwan Corp |Elite Screens Japan |Elite Screens Australia

5.2.2 Drawings for 135” odels

5.3 E-TYPE Di ensions for 100" and 120" odels

Model

Nu ber

Diag.

Size

Case

Length

(A)

View

Width

(A1)

Screen

Width

(A2)

Weight

bar

length

(A3)

Overall

Height

(B)

View

Height

(B1)

B2 B3

Botto

Border

(B4)

Left

Border

(B5)

Right

Border

(B6)

Screen

Material

to Wall

(C1)

Unit: Inches

M100S 100" 77.1 70.5 72.7 75.7 79.4 70.5 2.9 76.1 2.0 1.1 1.1 0.9

M100V 100" 86.4 80.0 82.2 85.2 71.6 60.0 5.5 68.2 2.0 1.1 1.1 0.9

M100H 100" 93.8 87.2 89.4 92.4 59.8 49.0 4.7 56.4 2.0 1.1 1.1 0.9

M100X 100" 91.5 84.8 87.0 87.7 63.7 53.0 4.7 60.4 2.0 1.1 1.1 0.9

M120V 120" 102.7 96.0 99.0 101.9 83.4 71.9 4.5 79.6 2.4 1.5 1.5 0.9

M120H 120" 110.9 104.6 107.6 110.7 82.5 65.7 4.5 69.4 2.4 1.5 1.5 0.9

M120X 120" 108.1 101.6 104.6 107.7 74.9 63.5 4.5 71.2 2.4 1.5 1.5 0.9

PRODUCT WHITE PAPER

http://www.elitescreens.com

Elite Screens Inc. |Elite Screens Europe GmbH| Elite Screens India |Elite Screens China Ltd.

Elite Screens Taiwan Corp |Elite Screens Japan |Elite Screens Australia

Model

Nu ber

Diag.

Size

Case

Length

(A)

View

Width

(A1)

Screen

Width

(A2)

Weight

bar

length

(A3)

Overall

Height

(B)

View

Height

(B1)

B2 B3

Botto

Border

(B4)

Left

Border

(B5)

Right

Border

(B6)

Screen

Material

to Wall

(C1)

Unit:

M100S 100" 1958 1790 1846 1923 2017 1790 74 1933 51 28 28 23

M100V 100" 2194 2032 2088 2164 1819 1524 140 1732 50 28 28 23

M100H 100" 2382 2214 2270 2347 1519 1245 119 1433 50 28 28 23

M100X 100" 2323 2154 2210 2228 1618 1346 119 1534 50 28 28 23

M120V 120" 2609 2438 2515 2588 2118 1826 114 2022 62 38 38 23

M120H

120"

2816

2657

2733

2812

2096

1670

114

1762

M120X 120" 2745 2581 2657 2736 1902 1613 114 1808 62 38 38 23

5.4 Drawings for 100" and 120" odels

PRODUCT WHITE PAPER

http://www.elitescreens.com

Elite Screens Inc. |Elite Screens Europe GmbH| Elite Screens India |Elite Screens China Ltd.

Elite Screens Taiwan Corp |Elite Screens Japan |Elite Screens Australia

5.5 Pictures

Manual B Series White Casing – Closed

Casing Close Up o 100” and 120” models

Weight Bar Detail

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Elite Screens Projektionsfläche Handbücher

Elite Screens

Elite Screens YardMaster Manual Series Bedienungsanleitung

Elite Screens

Elite Screens Elite Tripod Series Bedienungsanleitung

Elite Screens

Elite Screens Evanesce B Series Kurzanleitung

Elite Screens

Elite Screens Kestrel Stage Series Bedienungsanleitung

Elite Screens

Elite Screens TE100HW2 Bedienungsanleitung

Elite Screens

Elite Screens Aeon CineGrey 4D AT Series Bedienungsanleitung

Elite Screens

Elite Screens Home100IWH2-A Bedienungsanleitung

Elite Screens

Elite Screens EB100HW2-E12 Kurzanleitung

Elite Screens

Elite Screens CineTension 2 Series Bedienungsanleitung

Elite Screens

Elite Screens Lights-On Portable Series Bedienungsanleitung

Elite Screens

Elite Screens EDGE FREE Aeon StarBright 9 Series Bedienungsanleitung

Elite Screens

Elite Screens Home100IWH3 Bedienungsanleitung

Elite Screens

Elite Screens Evanesce B Series Bedienungsanleitung

Elite Screens

Elite Screens Elite Ez-Frame Series Bedienungsanleitung

Elite Screens

Elite Screens F60XWV1 Bedienungsanleitung

Elite Screens

Elite Screens Manual SRM Pro Series Bedienungsanleitung

Elite Screens

Elite Screens Aeon CLR 3 Series Bedienungsanleitung

Elite Screens

Elite Screens YARD MASTER MANUAL SERIES Bedienungsanleitung

Elite Screens

Elite Screens Spectrum Series Bedienungsanleitung

Elite Screens

Elite Screens Evanesce Plus Series Bedienungsanleitung

Elite Screens

Elite Screens ezFrame Plus Series Bedienungsanleitung

Elite Screens

Elite Screens Evanesce Tension Series Bedienungsanleitung

Elite Screens

Elite Screens Sable Frame 2 Series Bedienungsanleitung

Elite Screens

Elite Screens Evanesce Tension Series Bedienungsanleitung

Beliebte Projektionsfläche Handbücher anderer Marken

FART PRODUKT

FART PRODUKT Standard SCREEN Bedienungsanleitung

Draper

Draper E Series Handbuch

Laarhoven

Laarhoven Companion II Bedienungsanleitung

Renogy

Renogy RMS-LFPS-US Bedienungsanleitung

Da-Lite

Da-Lite ExecutiveElectrol Bedienungsanleitung

Samsung

Samsung S*H65* Bedienungsanleitung

FONESTAR

FONESTAR PPTR-43100-FA Bedienungsanleitung

Slide Clear

Slide Clear Varro XL Bedienungsanleitung

OS РХ-090Н Bedienungsanleitung

Niko

Niko 10-845 Bedienungsanleitung

Speaka Professional

Speaka Professional 2357532 Betriebsanleitung

Sima

Sima XL-72 Bedienungsanleitung

Jasic

Jasic EVO 2.0 ET-200P Bedienungsanleitung

InFocus

InFocus SC-WALL GRY-92H Handbuch

Barco

Barco OverView MVL-615 Bedienungsanleitung

Draper

Draper Envoy Handbuch

SI Dynamic 2 XL Bedienungsanleitung

Draper

Draper Nocturne+ E Montageanleitung
