Universal Ceiling Projector Mount

A56-E25B2

UserGuide





Rev.030111‐AS

www.elitescreens.com i[email protected]2



SPECIFICATIONS

Maxweightforceilingandwallinstallation.37.4lbs.

TotalweightoftheA56‐E25B2. 3lbs.

OveralldimensionsoftheA56‐E25B2.(LxWxH)12.5”x4.3”x2.3”







TheA56‐E25B2Projectormountis90%compatiblewith

mostprojectorfootprintdesigns.Itiseasytousefor

low/highceilingsandshort‐throwwallprojector

installations.Itcanbeadjustedinbothlengthand

heighttooptimizetherightlevelofprojection.

ExampleofA56‐

E25B2asashort‐

throwmountfor

wallinstallation.

ExampleofA56‐E25B2

withoutextensionbarfora

flushmounttotheceiling.

ExampleoftheA56‐E25B2

withextensionbarforhigh

orangledceilings.

Rev.030111‐AS

www.elitescreens.com i[email protected]3







Thisinstallationisdesignedtobringthe

projectorclosertotheceilingtoaccommodate

roomsize.Theextensiondoesnotnecessarily

havetoberemovedfortheprojectortobe

mounted.Thedesignofthisparticularmount

hastheabilitytobeextendedorflushedcloser

totheceiling.Theextraaccessoriescanbe

removedandreplacedwithadditionalparts.The

extrahardwareisdesignedtofit90%ofthe

differentprojectortypesintheUS.Somescrews

mayberequiredfortheprojector.Forproper

installation,pleasemakesuretheprojectorhas

theoptionofbeingceilingmounted.Please

referenceintheprojector’smanualformount

options.Theprojectormounthasthecapability

totiltata20‐30%angleinacircularmotion.

Flush Ceiling Mount

M5 x 12 Hex screws

M5Washer

d

f

e

Shortextension

Extensionfor

spiderleg.

Longextension

forspiderleg.

Theseextensionsareextrapartsformounting

purposes.Bysimplyremovingeitherextension

fromthemountyoucanhaveitshortenedor

extendeddependingonthesizeandmodelof

yourprojector.Thespiderlegsare

manufacturedtoextendifneededtoprovide

extraextensiontoreachthecorrectmount

screw.Byaddingextension(e)youcanhavethe

spiderlegsextendedfurtherforreachingthe

projector’sscrewpoints.Extension(d)canbe

placedwithextension(e)bysecuringitwith

screwtype(b).Extension(f)isanextra

accessory;themounthas2extensionssimilarto

extension(f).Thiswillonlyberequiredifthe

extensionsarenotlongenoughforyour

ector.

#1

Rev.030111‐AS

www.elitescreens.com i[email protected]4



Upper

extension

21” ¼ long

Optional extensions can be

purchased at your local

hardware store.

M6 Threaded

rod

M6 x 16

CSK

Phillips

(4nos.)

M6Long

nut

(

4nos.

)



M6Anchors(4nos.)

M5 x 12 Hex screws

M5Washer

Ceiling

plate

Upper

extension

Theprojectorcablecanbe

insertedthroughtheextension

foraconcealedinstallation.

Lower

extension M5Washer

M5x12Hexscrews

M5x12Hexscrews

M5Washer

Pan/tilt

swivel

Spider

hook

Spider hook for projector mount can be

adjusted/extended for perfect installation fit.

Projector

outlet

Adjustable

drop height up

to 23” ¾ Extension can be

removed for low ceiling.

b

a

b

a

b

c

Standardmountingscrews/partsforLCD/DLPprojector:

a.M5Washer(4nos.)

b.M5x12Phillipscrews(4nos.)

c.Spiderhookfortheprojectormount.

d.Extraspiderlegextension(Short).

e.Extensionforspiderleg(LongBracket).

f.Extraspiderlegextension(LongExtension).

Mount assembly with extension bar #2

Rev.030111‐AS

www.elitescreens.com i[email protected]5







 

OptionalZA56‐WP

(wallplatemountforshort‐throwwallmountonwoodstuds)

Availableatwww.shop.elitescreens.com

Short-throw mount assembly #3

Removethe2.5”PhillipsheadscrewfromthePan/TiltSwiveltoeasilymodifyyourmounttobeusedasa

short‐throwMount.NextistoremovetheStraightBladeheadscrews(2)fromthePan/TiltSwivel.Connectthe

SpiderBodytothePanTiltSwivel(asshowninpicture),andsecurewithoneM4x8Phillipsscrewandthe

M5x55screwandM5Nut.ConnecttheExtensionBartothePan/TiltSwivelandsecureonbothsideswiththe

M4x8Phillipsscrews.AttheotherendoftheExtensionBar,connecttheWallPlateandsecurewiththeM5x10

Phillipsscrews.Note:ExtensionBarwillneedtobeadjustedtoconnecttothePan/TiltSwivelandtheWall

Plate.AfterconnectingtheSpiderLegstotheSpiderBody,themountisreadytobeattachedtotheprojector

andmounteddirectlytothewallorontheoptionalZA56‐WP(WallPlates).
