Elo TouchSystems 1220L Bedienungsanleitung

No part of this publication may be reproduced, transmitted, transcribed, stored in a

retrieval system, or translated into any language or computer language, in any form or by

any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or

otherwise without prior written permission of Elo TouchSystems.

Disclaimer

The information in this document is subject to change without notice. Elo TouchSystems

makes no representations or warranties with respect to the contents hereof, and spe-

cifically disclaims any implied warranties of merchantability or fitness for a particular

purpose. Elo TouchSystems reserves the right to revise this publication and to make

changes from time to time in the content hereof without obligation of Elo TouchSystems to

notify any person of such revisions or changes.

Trademark Acknowledgments

IntelliTouch, SecureTouch, AccuTouch, Entuitive, and MonitorMouse are trademarks of

Elo TouchSystems, Inc.

Other product names mentioned herein may be trademarks or registered trademarks of

their respective companies. Elo TouchSystems claims no interest in trademarks other

than its own.

Usage Notice

Precautions ................................................................................. 3

Introduction

About the Product ....................................................................... 4

Package Overview...................................................................... 5

Installation

Product Overview........................................................................ 6

Start Your Installation .................................................................. 7

User Controls

Front Panel Controls ................................................................... 9

How to Use the OSD Menus....................................................... 10

On-Screen Display Menus ......................................................... 11

Appendices

Troubleshooting........................................................................... 14

Warning Signal............................................................................ 15

Product Dimensions ................................................................... 16

TouchmonitorSpecifications.........................................................17

Compatibility Modes ................................................................... 19

Installing the Driver Software....................................................... 20

RegulatoryInformation.................................................................23

Warranty.......................................................................................25

Table of Contents

Usage Notice

Warning- To prevent the risk of fire or shock hazards, do not

expose this product to rain or moisture.

Warning- Do not open or disassemble the product as this

may cause electric shock.

Precautions

Follow all warnings, precautions and maintenance as recom-

mended in this user’s manual to maximize the life of your unit.

Do:

qTurnofftheproductbeforecleaning.

qUse only a dry soft cloth or clean wipe when cleaning the

LCDpanel surface.

qUse a soft cloth moistened with mild detergent to clean the

displayhousing.

qUseonlyhighquality and safety approvedAC/DCpower

adapter.

qDisconnect the power plug fromAC outlet if the product is not

usedfor a longperiod of time.

Don’t:

qDo not touch the LCD panel surface with sharp or hard objects.

qDonot use abrasive cleaners,waxesor solvents for your

cleaning.

qDonotoperate the product underthefollowing conditions:

-Extremely hot, cold orhumid environment.

-Areas susceptible to excessive dust and dirt.

-Near any appliance generating astrongmagnetic field.

- Place in direct sunlight.

Introduction

AbouttheProduct

This product is a 12.1” SVGA TFT color LCD touchmonitor with the

followingfeatures:

qDirectanalogRGB input

qActivematrixTFTLCD technology

q12.1”diagonal screen size

q16.7million displayable colors

qSVGA 800 x 600 addressable pixels

qAuto-adjustment

qFullscreen re-scaling capability

q31 ~ 54kHz horizontal scan

q56~ 85Hz high refreshrate

qMultilingualOSD user controls

qVESADPMSpowersaving

qSerialtouchinterface(RS232 cable)

qBuilt-inspeakers

qPatented touch technology of Elo TouchSystems.

Forfull product specifications referto

TouchmonitorSpecifications

,page

16.

RS-232Touchscreen

InterfaceCable

Audio-InCable

US/Canada

PowerCord

Package Overview

Check that the following 10 items are present and in good condition:

MacVideoAdapter

User’sGuideand

softwareCD

Manual

Software

VGASignalCable

Europeanpower cable

PowerAdapter

LCDTouchmonitor

6Installation

ProductOverview

uMainUnit

uRear View

MENU SELECT

LCDTouchmonitor

Stand UserControls

Power

Switch Ear

Phone

Audio

Power

DC-In

Display

Input RS-232

Touch

Interface

StartYourInstallation

uTilt

Grasp both sides of the monitor screen with your hands and adjust the

tilt as desired.

uConnecting the Touchmonitor (Figure 7.1)

Tosetup this touchmonitor,please refer to thefollowing figureandproce-

dures.

1. Be sure all equipment is off.

2. Connect the VGA signal cable from display input connector to the

15-pin connector of your host computer and tighten the screws.

3. Connect the female end of the touchscreen cable to the serial port on

the back of your PC, and the male end of the cable to your

touchmonitor.

4. Connectthe DC power cordtothe power connector;plugone end of

theAC power cordinto the power adapter,and thenthe other end into

an electrical outlet.

5. ConnecttheAudio-In cablefromaudio input port ofyourtouchmonitor to

theAudio-out port ofyourcomputer.If youneedto use earphone,

connectyour earphone cable tothe earphone port ofyourdisplay.

6.Turnon both yourcomputerand touchmonitor.

uInstall Driver Software

Pleasereferto page 20 for driver softwareinstructions.

Notice:To ensure the LCD display works well with your computer, please configure the

display mode of your graphic card to less than or equal to 800 x 600 resolution. Make sure the

timing of the display mode is compatible with the LCD display. We have listed the Compatibility

Modes of this LCD display in the appendices for your reference.

Power Adapter

Audio-In Cable

VGA Signal Cable

Mac Adapter

Power Cord RS-232 Touch

Cable

(Figure 7.1)

UserControls

FrontPanelControls

No. / Icon Control Function

MENU Menu button Displays the OSD menus

SELECT Select Selects the adjustment items

from OSD menus.

3Decrease / Select Decreases value of the

adjustment items or selects

the functions.

4Increase / Select Increases value of the

adjustment items or selects

the functions.

Power LED 1. Green indicates the display

is turned on.

2. Amber indicates the display

in power-saving mode.

 

MENU SELECT


