PureBB Single Phase
User manual
PureBB Single Phase User manual
1Elspec
Table of Contents
Table of Contents 1
1. General 2
Introduction 2
Limited Warranty & Limitation of Liability 3
NOTICE REGARDING PROPRIETARY RIGHTS 4
Safety Precautions 5
Unpacking Components & Accessories 6
2.
Using the PureBB Analyzer
7
Connections & Plugs 7
Connecting the PureBB 8
LEDs Indications 9
3. PQZ Recording 10
4. Using the USB cable 11
5. Using the PQSCADA Sapphire 11
6. PQSCADA Sapphire Installation 14
License Activation 16
6.1.1 On-line activation 16
6.1.2 Off-line activation 18
7. Specifications 22
1. General
Elspec 2
1. General
Introduction
The PureBB Single Phase Power Quality Analyzer records and
stores voltages and current waveforms data from a working power
outlet. Once the analyzer have been plugged-in to the power outlet,
the PureBB start to collect waveform data that canbe downloaded to
a personal computer for complete analysis.
The device comes in 2 versions:
SPG-5112-A090 –W.O. current measurement
SPG-5111-A090 –with current measurement
Power quality post recording processing and analysis are available
using thefree PQSCADA Sapphire Express Edition software via drag
and drop of recorded PQZ files for immediate analysis, PQ trending,
events occurrences and reports.
Recorded information is saved in a non-volatile memory microSD
card which is accessed either via the device USB slot connected to
a PC, or by inserting the SD card in a reader connected to a PC.
The advanced design ensures accurate recording of all voltages and
current parameters. The Analyzer and PQSCADA Sapphire features
include:
Light weight, hand-held portable PQ Analyzer
Continuous waveform recording at 256 Sample/Cycle
50/60Hz
Class A devices IEC61000-4-30
Configuration FREE Device
Easy USB connectivity to PC
SD card slot hot swap
Please refer to the PQSCADA Sapphire Users Manual, located on
the PureBB Manual USB drive, for more information. The manual
provides instruction for installation and use, as well as general
instructions for connecting to Elspec power quality analyzers.
PureBB Single Phase User manual
3Elspec
Limited Warranty & Limitation of Liability
Each Elspec product is under warranty to be free from defects in
material and workmanship under normal use and service. The
warranty period is for one year and commences on the date of
shipment. Parts, product repairs, andservices areunder warranty for
90 days. This warranty extends only to the original buyer or end-user
customer and it does not apply to fuses, disposable batteries, or to
any product which, in Elspec's opinion, has been misused, altered,
neglected, contaminated, or damaged by accident or abnormal
conditions in the operation or handling of the product. Elspec
guarantees that the software will operate substantially in accordance
with its functional specifications for 90 days and that it has been
properly recorded on non-defective media. Elspec does not
guarantee that the software will be error free and operate without
interruption. Elspec authorized re-sellers shall extend this warranty
on new and unused products to end-user customers only, but do not
have authority to extend a greater or different warranty on behalf of
Elspec. Warranty support is available only if the product is purchased
through an Elspec authorized sales outlet or Buyer has paid the
applicable international price. Elspecreserves the right to invoice the
Buyer for any importation costs for the repair/replacement of parts
when the product purchased in one country is submitted for repair in
another country. Elspec’s warranty obligation is limited, at Elspec's
option, to refund of the purchase price, free of charge repair, or
replacement of a defective product which is returned to Elspec within
the warranty period. For warranty service, contact Elspec directly to
obtain a return-authorization. On receipt of the authorization, return
the product to Elspec with a description of the problem, including
prepaid postage and insurance (FOB destination). Elspec assumes
no risk for damage in transit. Following warranty repair, the product
will be returned to the Buyer, transportation prepaid (FOB
destination). If Elspec determines that the failure was caused by
neglect, misuse, contamination, alteration, accident, or abnormal
condition of operation of handling, including overvoltage failures
caused by use outside the product's specified rating, or normal wear
and tear of mechanical components, Elspec will provide an estimate
of repair costs and obtain authorization before commencing work.
Following repair, the product will be returned to the Buyer,
transportation prepaid, and the Buyer will be billed for the repair and
return postage transportation charges (FOB Shipping Point). This
warranty is the Buyer's sole and exclusive remedy and is in lieu of all
other warranties, express or implied, including but not limited to any
implied warranty of merchantability or fitness for aparticular purpose.
Elspec shall not be liable for any special, indirect, incidental, or
consequential damages or losses, including loss of data arising from
any cause or theory. Since some countries or states do not allow
limitation of the term of an implied warranty, or exclusion or limitation
1. General
Elspec 4
of incidental or consequential damages, the limitations and
exclusions of this warranty may not apply to every buyer. If any
provision of this Warranty is held invalid or unenforceable by a court
or other decision-maker of competent jurisdiction, such holding will
not affect the validity or enforceability of any other provision.
NOTICE REGARDING PROPRIETARY RIGHTS
This publication contains information proprietary to Elspec. By
accepting & using this manual, you agree that the information
contained herein will be used solely for the purpose of operating
equipment developed & manufactured by Elspec.
PureBB Single Phase User manual
5Elspec
Safety Precautions
We, Elspec Engineering Ltd. Conduct the following Routine tests as
part of the production line: -Dielectric strength test between mains
and ground, test voltage 2120Vdc or 1500Vac -Grounding continuity
between earthpin of the appliance inlet and earth pin of the appliance
outlet
Kindly review & take all the necessary safety precautions prior to
proceeding.
WARNINGS
Protection provided by the equipment can be impaired if used in a
manner not specified by the manufacturer
Review the entire manual before using the instrument and its
accessories
Observe all warnings and cautions
Do not operate the instrument around explosive gas or vapor
Avoid working alone
Before use, inspect the instrument, leads and accessories for
mechanical damage, and replace when needed
Pay special attention to the insulation surrounding the connectors
and plugs
Remove all accessories that are not in use
Make sure the instrument is properly grounded to a protective
earth ground
Do not insert power or any other connectors above the rating of
the instrument as shown on the name plate
During installation, ensure that the device is completely
disconnected from any live points and\or plugs
Do not insert metal objects into connectors and openings
Never open the instrument’s enclosure during operation;
Dangerous voltages are present
Do not expose the instrument to extreme moisture and or rain
do not operate the instrument or its accessories when found wet
for any reason
1. General
Elspec 6
Unpacking Components & Accessories
The following items are included in your Analyzer Kit:
#
Description
Cat. number
1
Pure Single Phase BlackBox
Power Quality Analyzer
SPG-531A-0090
2
USB Cable type A male to type B
male 1.5m black
EHA-0159-9100
3
Elspec BlackBox Installation
USB drive
SMX-0408-0103
4
4GB Micro SD card
EBO-4096-9094
5
Universal Female Adapter
EHA-9001-2100
6
Power Cable for Europe
10A/230V, straight, 1.8M, Black /
Power Cable for America
10A/125V, straight, 1.8M, Black
EPC-2012-2190 /
EPC-7012-2190
PureBB Single Phase User manual
7Elspec
2. Using the PureBB Analyzer
Connections & Plugs
The PureBB single phase power quality analyzer has the following
connections & Plugs:
2. Using the PureBB Analyzer
Elspec 8
Connecting the PureBB
Plug the female end of the Power Cable to the Main Power Supply
inlet socket of the analyzer.
Connect the male plug end of the Power Cable to the electrical
supply outlet.
Wait for approx. 1min for the analyzer to be initialized. At the end of
the initializing process the unit power led should be solid green and
the SD card led should be blinking green.
To measure current, plug your load into the Universal Female
Adapter (Supplied).
Leave the Analyzer plugged in for a few hours or days depending on
your application and the micro SD card size.
When you are ready, disconnect it from the power outlet and connect
it to a PC running PQSCADA Sapphire.
Electric utility specialists can also send the Recorder to a utility
consumer who can connect it to their own electric outlet for a
specified period. When finished taking data, the consumer can then
send the Recorder back to the electric utility specialist. The specialist
can analyze the collected data with PQSCADA Sapphire. Collected
data, and real-time clock data stay intact in transit via the Recorder’s
non-volatile memory.
PureBB Single Phase User manual
9Elspec
LEDs Indications
The PureBB have 3 operational bi-color (green/red) LEDs –Unit
Power, USB connectivity and SD card. These LEDs provide the
following information:
Power LED:
Led Status
Description
Solid Green
The analyzer in powered-up and working well
Blinking Green
N/A
Solid Red
Carnell is initializing (during analyzer
initializing process).
DSP Error.
Blinking Red
System is initializing (during analyzer
initializing process).
FW Upgrade is in process (SD LED will be
blinking as well)
USB LED:
Led Status
Description
Solid Green
USB connection detected
Blinking Green
N/A
Solid Red
N/A
Blinking Red
N/A
SD LED:
Led Status
Description
Solid Green
N/A
Blinking Green
Recording is O.K
Solid Red
No micro SD card
Corrupted micro SD card
Blinking Red
Not recording, USB connected
