LP10000ExDC Installation and Reference Manual
Table of Contents
Installation
Features
Compatibility
Prerequisites
Set Jumpers
Install HBA
Attach Media
Apply Power
View LEDs
Reference
Specifications
FCC Statement
Declaration of Conformity
Laser Safety
Emulex Documentation, Drivers and Software
1
Installation
Features
The Emulex LP10000ExDC host bus adapter offers highly integrated 2Gb/s Fibre Channel
connectivity solutions for enterprise-class storage area networks. The LP10000ExDC is a
new member of the LP10000 family and is designed for use with PCI-Express servers. The
LP10000ExDC HBA delivers state of the art performance through the use of "Thor",
Emulex’s sixth generation Fibre Channel controller and is a dual channel HBA in a
standard height, half-length card form factor.
The PCI-Express architecture is an open specification designed to address the wide range
of current and future system interconnect requirements. It also defines a flexible, scalable,
high-speed, serial, point-to-point, hot pluggable/hot swappable interconnect that is
software-compatible with PCI.
The PCI-Express architecture allows the LP10000ExDC to use the same drivers and
management tools as the LP10000 host bus adapters for PCI and PCI-X systems.
Emulex’s unique Service Level Interface (SLI) driver architecture, which enables the
independence of the operating systems device driver from the underlying HBA platform,
will allow OEMs and end users to migrate to this new system architecture seamlessly
(without having to change or rewrite drivers utilities and other management tools).
Emulex’s firmware-based architecture, which allows for new features and other upgrades
without costly changes to the adapter hardware, provides the kind of technical flexibility
and investment protection that is critical when working with new and evolving technology.
Major Features
●Compliant with the PCI-Express 1.0a
❍x1 or x4 lane link interface at 2.5Gbit/s per lane (auto-negotiated with
system)
❍Support VC0 (1 Virtual Channel) and TC0 (1 Traffic Class)
❍Configuration / IO / Memory read/write, completion, message
❍Support 64-bit addressing
❍32-bit CRC for all transmitted data packets
❍16-bit CRC on all link message information
Emulex Documentation, Drivers and Software
2
●Compatible with both 1 Gigabit (1Gb) and 2 Gigabit (2Gb) Fibre Channel (FC)
Interface
●Auto-negotiation between 1Gb and 2Gb link attachments
●High Performance Fibre Channel host adapter with dual internal processors
●Full support for all FC Topologies – point-to-point, arbitrated loop, and fabric
●Full support for FC service class 2 and 3
●Maximum FC throughput achieved via full duplex hardware support
●End-to-end data path-parity and CRC protection, including internal data path RAMs
●Architectural support for multiple upper layer protocols
●State-of-the-art circuitry in Thor (on each port)
●Internal 32-bit ARM 946E-S processor with instruction and data cache
●Internal SerDes 1Gb/2Gb core
●High speed QDR II external memory with separate read and write data paths
●Host Interface via Emulex standard drivers or through custom drivers written to the
Emulex Service Level Interface (SLI-2) that is compatible with the LP7000/LP8000/
LP9002L/LP9802/LP10000 Drivers
●Comprehensive array of operating system drivers
❍Emulex standard and OEM derivatives of device drivers for Windows 2000,
Windows Server 2003, Linux, and Netware.
❍Device drivers for legacy operating systems, Windows NT 4.0 and Solaris
x86, based on market demand.
❍Drivers for both SCSI and IP (where supported) Protocols
❍Driver support for Fibre Channel boot functionality
●On-board Context Management by Firmware (per port)
Emulex Documentation, Drivers and Software
3
❍Up to 510 FC Port Logins
❍Up to 2048 concurrent Exchanges
❍I/O multiplexing down to FC Frame level
●Large data buffers capable of supporting 101 buffer-to-buffer (BB) credits per port
for short-wave applications.
●Link management and recovery handled by Firmware
●On-board diagnostic trace capability accessible via optional connection
Compatibility
Software Environments Windows Server 2003, Windows 2000, Windows NT
and Linux
Hardware Environments PCI-Express hardware platforms: x86 (for IA-32)
platforms
Prerequisites
●PCI-Express 1.0a system bus interface, x1 or x4 lane transfer link at 2.5 Gb/
second per lane (primary bus interface). System must have a 4x PCI-Express slot
minimum.
●3.3V and 12V PCI-Express power required for operation
●Media and connectors
Emulex Documentation, Drivers and Software
4
Set Jumpers
Caution Emulex LightPulse®Host Bus Adapters (HBAs) contain
electronic components that can be damaged by static
electricity through an electrostatic discharge (ESD) event.
To prevent ESD damage, maintain constant contact with
any grounded metal surface. A grounding wrist strap is
useful for this purpose. Handle the card carefully at all
times and preferably by the edges. Avoid touching
electronic components and keep the card in the original
packaging until you are ready for installation.
The device ID jumpers are used in custom applications. Do not change the jumper settings
for a standard Emulex installation.
The HBA has two pairs of jumper blocks that control the HBA's device ID. You change the
HBA's device ID by changing the jumper settings. P0_JX1 & P0_JX2 control the device ID
for Port 0, and P1_JX1 & P1_JX2 control the device ID for Port 1. The default device ID for
both ports is FA00.
Device ID Port 0
Jumper Setting Port 1
Jumper Setting
FA00 JX1:1-2, JX2:2-3 JX1:1-2, JX2:2-3
1AE5 JX1:2-3, JX2:2-3 JX1:2-3, JX2:2-3
FA01 JX1:2-3, JX2:1-2 JX1:2-3, JX2:1-2
Emulex Documentation, Drivers and Software
5
Install the Host Bus Adapter Board
Caution Emulex LightPulse®Host Bus Adapters (HBAs) contain
electronic components that can be damaged by static
electricity through an electrostatic discharge (ESD) event.
To prevent ESD damage, maintain constant contact with
any grounded metal surface. A grounding wrist strap is
useful for this purpose. Handle the card carefully at all
times and preferably by the edges. Avoid touching
electronic components and keep the card in the original
packaging until you are ready for installation.
1. Record IEEE and serial numbers.
Each host bus adapter is shipped with a unique 64-bit identifier called the IEEE
address. The Fibre Channel industry uses a World Wide Name (WWN) derived
from the IEEE address, and this number is needed for Fibre Channel connectivity.
Since this adapter has two ports, there are two IEEE addresses. The IEEE address
is used when configuring your system. The serial number is used when
communicating with Emulex. All numbers are clearly marked on the board. We
recommend that you record these numbers before installation.
2. Turn off and unplug the computer.
3. Remove the computer case.
Note For best I/O performance, place the adapter into
an empty PCI Express 1.0a compliant slot that is
capable of running in x4 link width.
4. Remove the blank panel from an empty 4x, 8x or 16x PCI-Express bus slot.
5. Insert the host bus adapter into the empty PCI Express slot. Press firmly until the
adapter is seated.
6. Secure the host bus adapter's mounting bracket to the case with the panel screw
or clip.
7. Replace the computer case and tighten case screws.
The host bus adapter is now installed in the PC and is ready for media attachment.
Emulex Documentation, Drivers and Software
6
Attach Media
Note The host bus adapter will not allow normal data
transmission on an optical link unless it is connected to
another similar or compatible laser product (that is,
multimode to multimode.)
Use multimode fiber optic cable, with short-wave lasers, that adheres to the following
specifications:
Fiber Optic Cable Maximum Length Minimum
Length Connector
62.5/125 µm (multimode) 300 meters at 1.0625 Gb/s
150 meters at 2.125 Gb/s 2 meters LC
50/125 µm (multimode) 500 meters at 1.0625 Gb/s
300 meters at 2.125 Gb/s 2 meters LC
1. Connect the fiber optic cable to the LC connector on the HBA.
2. Connect the other end of the cable to the Fibre Channel device.
After the media is connected to the host bus adapter, you are ready to apply power to the
computer.
Emulex Documentation, Drivers and Software
7
Apply Power
1. Verify that the host bus adapter is securely installed in the computer.
2. Verify that the correct media is attached.
3. Plug in and turn on the computer.
4. Observe LEDs for Power On Self Test (POST) results.
View LEDs
Green and yellow LEDs can be seen through openings in the host bus
adapter's mounting bracket. Green indicates power and yellow signifies port
activity. Each port has a corresponding set of green and yellow LEDs.
POST conditions and results are summarized in the following table.
Yellow
LED Green
LED State
OFF OFF Wake-up failure (dead board)
ON OFF POST failure (dead board)
Slow blink
(1 Hz) OFF Wake-up failure (dead board)
Fast blink
(4 Hz) OFF Failure in POST (dead board)
Flashing
(irregular) OFF POST processing in progress
OFF ON Failure while functioning
ON ON Failure while functioning
Slow blink ON Normal operating condition - 1 Gb link rate
Emulex Documentation, Drivers and Software
8
Fast blink ON Normal operating condition - 2 Gb link rate
OFF Slow blink Normal - link down or not yet started
Slow blink Slow blink Offline for download
Fast blink Slow blink Restricted offline mode (waiting for restart)
Flashing Slow blink Restricted offline mode, test active
Emulex Documentation, Drivers and Software
9
Reference
Specifications
Parameter Range
Media Interface The Thor controller interfaces to the physical
media through an FC-0 Media Interface (FC-PI
compliant transceiver), and then connects
through dual optical fiber LC connectors.
Physical Dimensions PCI-Express standard half-length card size
(4.367" x 6.600")
Power Requirements (Watts, Typ/
Max) PCI-Express x4:
●3.8/5.4 watts @ +3.3 VDC
●11.9/17.0 watts @ +12.0 VDC
●15.7/22.3 watts (total power)
Airflow 100 lf/min (minimum)
Temperature 32° to 113° F (0° to 45° C), Operating
-40° to 158° F (-40° to 70° C), Storage
Humidity 5% to 95% non-condensing
Agency Approvals for
LP10000ExDC
Class 1 Laser Product per DHHS 21CFR (J) &
EN60825-1
UL recognized to UL 60950-1:2003
CUR recognized to CSA 22.2, No. 60950-1-03
Baurt-certified by TUV to EN60950
FCC Rules, Part 15, Class A
Industry Canada, ICES-003, Class A
EMC Directive 89/336/EEC (CE Mark)
EN55022, Class A
EN55024
Australian EMC Framework (C-Tick Mark)
AS/NZS 3548:1995 Class A
Japan VCCI, Class A
Taiwan BSMI, Class A
Korea MIC, Class A
Emulex Documentation, Drivers and Software
10
Inhaltsverzeichnis
Andere Emulex Adapter Handbücher
Emulex
Emulex LP10000 Bedienungsanleitung
Emulex
Emulex LP952L Installations- und Betriebsanleitung
Emulex
Emulex LP982 Installations- und Betriebsanleitung
Emulex
Emulex LPe11004 HBA Montageanleitung
Emulex
Emulex LP1050 Installations- und Betriebsanleitung
Emulex
Emulex OneConnect OCm11102-N-X Betriebsanleitung
Emulex
Emulex NC551i Bedienungsanleitung
Emulex
Emulex LPe1150 HBA Bedienungsanleitung
Emulex
Emulex OneConnect OCe14000-Series Bedienungsanleitung
Emulex
Emulex LP1005DC-CM2 Bedienungsanleitung
Emulex
Emulex OneConnect OCe14000-Series Bedienungsanleitung
Emulex
Emulex LP21000 Bedienungsanleitung
Emulex
Emulex LPE11000 HBA Bedienungsanleitung
Emulex
Emulex LP1050DC Installations- und Betriebsanleitung
Emulex
Emulex OneConnect OCe14000-Series Bedienungsanleitung
Emulex
Emulex LP10000 Installations- und Betriebsanleitung
Emulex
Emulex LPe15004-Series Bedienungsanleitung
Emulex
Emulex LPe11002 HBA Bedienungsanleitung
Emulex
Emulex LP9802DC Installations- und Betriebsanleitung
Emulex
Emulex LP1050Ex Installations- und Betriebsanleitung
