Enable-IT 865 PTZQ PRO Bedienungsanleitung

Enable-IT 865 PTZQ Pro

Rev B High Powered PoE+

Ethernet Extender

User Manual

documentation may be reproduced in any form, or by any means, or used to make any

derivative work (such as translation, transformation, or adaptation) without written

permission from Enable-IT, Inc.

Enable-IT, Inc. reserves the right to revise this documentation and to make changes in

content from time to time without obligation on the part of Enable-IT, Inc., to provide

notification of such revision or change.

Enable-IT, Inc. provides this documentation without warranty, term, or condition of any

kind, either implied or expressed, including, but not limited to, the implied warranties,

terms or conditions of merchantability, satisfactory quality, and fitness for a particular

purpose. Enable-IT, Inc. may make improvements or changes in the product(s) and/or

the program(s) described in this documentation at any time.

If there is any software on removable media described in this documentation it can be

provided on request. Please contact Enable-IT, Inc. and a copy will be provided to you.

UNITED STATES GOVERNMENT LEGEND

If you are a United States government agency, then this documentation and the

software described herein are provided to you subject to the following:

All technical data and computer software are commercial in nature and developed solely

at private expense. Software is delivered as "Commercial Computer Software" as

defined in DFARS 252.227-7014 (June 1995) or as a "commercial item" as defined in

FAR 2.101 (a) and as such is provided with only such rights as are provided in Enable-

IT, Inc.'s standard commercial license for the software/firmware.

Technical data is provided with limited rights only as provided in DFAR 252.227-7015

(Nov 1995) or FAR 52.227-14 (June 1987), whichever is applicable. You agree not to

remove or deface any portion of any legend provided on any licensed program or

documentation contained in, or delivered to you in conjunction with, this User Manual.

Unless otherwise indicated, Enable-IT, Inc. registered trademarks are registered in the

United States and may, or may not, be registered in other countries

TABLE OF CONTENTS

ABOUT THIS USER MANUAL......................................................................................4

INTRODUCING THE 865 PTZQ PRO EXTENDED POEAND ETHERNET KIT............5

About The 865 PTZQ PRO EXTENDED PoE and ETHERNET KIT........... 5

Key Benefits ................................................................................................6

Summary Of Features.................................................................................6

Multi Use Applications.................................................................................7

INSTALLING THE 865 PTZQ PRO EXTENDED POEAND ETHERNET KIT...............8

Site Plan – Installation Design Considerations............................................8

Unpacking the Enable-IT 865 PTZQ PRO KIT............................................9

Perform An Out Of The Box Test (OOTBT).................................................9

Performing The On-Site Installation ............................................................10

Mounting the 865 PTZQ PRO KIT...............................................................10

Building the 865 PTZQ PRO Interlink Wiring...............................................10

Cabling Devices to the Enable-IT 865PTZQ PRO Kit .................................10

Troubleshooting...........................................................................................11

Performance Settings (DIP Switch).............................................................12

TECHNICAL SUPPORT ...............................................................................................13

Online Technical Services...........................................................................13

World Wide Web Site ..................................................................................13

Returning Products for Warranty Repair .....................................................13

Returning Products for Refund....................................................................13

ENABLE-IT,INC.LIMITED WARRANTY........................................................................14

ABOUT THIS USER MANUAL

This product User Manual provides all the information needed to install and use the

Enable-IT 865 PTZQ PRO EXTENDED PoE and ETHERNET KIT. This User Manual is

intended for use by technicians who are responsible for installing and setting up network

equipment. Consequently, it is assumed that the installer has a basic working

knowledge of LANs (Local Area Networks), PoE (Power-over-Ethernet) and voice

telecom wiring.

Most Enable-IT documents are available in Adobe Acrobat Reader Portable Document

Format (PDF) or HTML on the Enable-IT’s website under the Support tab.

INTRODUCING THE 865 PTZQ PRO KIT

Congratulations on purchasing the Enable-IT 865 PTZQ PRO EXTENDED PoE and

ETHERNET KIT — the simplest method to install your High Powered PoE PTZ Security

cameras using Ethernet or telephone wiring. This is the world’s first solution to deliver

Voice, Ethernet Data and Power over Ethernet (PoE) in a combined package that

exceeds the IEEE distance limitations for all Ethernet equipment.

WARNING: Output LAN ports 1 & 2 on the 865 PTZQ PRO CPE are PoE enabled and

not for use with non-PoE equipment as it may damage any non-PoE equipment.

This chapter contains introductory information about how it can be used in your network

and covers the following topics:

•About the 865 PTZQ PRO Extended PoE and Ethernet Kit

•Key Benefits

•Summary of Features

•Typical Use Applications

About the 865 PTZQ PRO Extended PoE and Ethernet Kit

The 865 PTZQ PRO Extended PoE and Ethernet Kit provides a complete all in one

solution and lower cost alternative for installing a PoE device beyond IEEE Ethernet cabling

distance limitations or for installing a remote LAN requiring no power at the remote end.

Traditional methods require installation of costly fiber (that can’t carry power) or a series

of hubs/repeaters and the use of voice and PoE equipment combined.

The preferred network access for these PoE devices is a dedicated Ethernet line,

however Ethernet over twisted pair wiring has its distance limitations of just 328 ft. In

order to drive Ethernet signal further, one would have to add repeaters to each

segment of 328ft twisted pair cabling; this is often insufficient and too costly in multi-

story buildings. Fortunately the Enable-IT 865 Series Extended Ethernet extends

High Power PoE+ and 100Mbps Ethernet up to 4.5 times beyond the 328ft/100m limit up

to 1,500ft/458m distance. If using the PoE to remotely power the 865 CPE (remote

device) and using standalone remote self-powered LAN than it will extend Ethernet data

up to 3,500ft/1,067m distance using LAN ports 3-4 output.

The 865 PTZQ PRO enables the simple installation of a PTZ PoE+ device up to 1,500ft

(458m) from your LAN and Power Source. – This is ideal for installing High Powered

PoE+ PTZ Security cameras or for a standalone remote self powered LAN up to 3,500ft

(1,067m).

WARNING: Output LAN ports 1 & 2 on the 865 PTZQ PRO CPE are PoE enabled and

not for use with non-PoE equipment as it may damage any non-PoE equipment.

The Enable-IT 865 PTZQ PRO Extended Poe and Ethernet kit has been tested to provide full

duplex transport up to 100MB/s over 2-pair telephone wiring or better.

Key Benefits

Unit Model

Wiring

Min Data Rate

Max. Distance

865PTZQ CAT3, CAT5e or better

100Mbps FD*

1,500ft / 458m

The following list identifies the 865 PTZQ PRO Extended PoE and Ethernet Kit key

benefits.

•Quad switched PoE+ enabled LAN RJ-45 10/100 Ethernet ports on each end for

expansion without adding a hub or switch on each end.

•The Enable-IT 865 PTZQ PRO Extended PoE and Ethernet Kit requires No

Power (CPE remote end), No Firmware, No Maintenance

•Broadband technology that delivers in-building PoE+ and Ethernet access over

existing Category 3 , Category 5e wiring or better up to 1,500ft or 458m.

•Provides one scalable infrastructure for Internet access, dual POTS, VoIP, video,

Power over Ethernet (PoE) and virtual private networking.

•Low profile box with voice line, Ethernet data and PoE+ all in a single RJ-45

Ethernet jack (Interlink port).

Summary of Features

The Enable-IT 865 PTZQ PRO Extended PoE and Ethernet Kit has the following

hardware features:

•PoE and Extended Ethernet line over existing CAT 3 up to CAT5e / CAT6 wiring

•Uses RJ-45 Interlink port for transport (single voice, PoE and 100Mbps data)

•Rapid Telco style installation – no programming required

•Supports digital VoD channels and Maintains existing telephone (lifeline POTS)

•Drives Ethernet 100 Mbps full-duplex service delivery with PoE up to 3,500ft or 1,067m

•Network Equipment independence – Transparent to protocols/applications/MAC

•Cisco PoE single line injector support built in.

•Transparent to single line 802.3af PoE devices.

Specifications: Functionality:

Power Indicator Data Rates 100Mbps Full Duplex

100Mbps Link status/Activity Full Duplex/Half Duplex status/Collisions

VDSL2 Link Status/Activity Protocol independent

Dimensions: 865 PTZQ PRO Interlink port pins:

Height: 1.5" (38mm) Pins 1 & 2 – Data

Depth: 3.75" (95mm) Pins 3, 4 & 5 – PoE positive power

Width: 5.75” (146mm) Pins 6, 7 & 8 – PoE negative power

Interfaces Environment

(1) 5v 2A DC Power Adapter 2.1mm Operating temp: -49°F to 168°F ( -45°to 7 6°C)

(4) RJ-45 100MB LAN Auto negotiate Port Storage temp: -49°F to 168°F ( -45°to 76°C)

(1) RJ-45 Interlink Port Humidity 5% to 95%, non-condensing

LAN 1 port pins:

Pins 1, 2, 3 & 6 – Ethernet Data

Pins 4 & 5 – PoE positive power

Pins 7 & 8 – PoE negative power

Multi Use Applications

Enable-IT 865 PTZQ PRO Extended PoE and Ethernet Kit is a versatile multipurpose

solution installed for the use of PoE equipment such as High Powered PoE+ PTZ

Cameras. Non-PoE equipment may be damaged if used and the Enable-IT 865 PTZQ

PRO kit should be used to bridge non-PoE equipment.

The 865 PTZQ PRO Extended PoE and Ethernet Kit allows a standard Ethernet

segment injected with 56v PoE+ to be deployed quickly over existing 2 pair Telco

Copper Wiring or CAT5e cabling up to 1,500ft / 458m to a remote unpowered location.

Installers have the convenience of a 100Mbps LAN Ethernet unit for peace of mind

connectivity and no device maintenance. Rapid installation allows for minimal

interruption and the Broadband technology allows for investment protection up to 10-15

years with no firmware or replacement issues. Bandwidth can be scaled according to

the Broadband Access Provider needs. The 865 PTZQ PRO Extended PoE and

Ethernet Kit is a passive device so interruption of Internet service does not affect POTS

services. Carriers and Access Providers can come and go, but the 865 PTZQ PRO

Extended PoE and Ethernet Kit technologies continue to provide lasting value such as

the other utilities like water, gas and electricity.

The Enable-IT 865 PTZQ PRO Extended PoE and Ethernet Kit is suited for the following key

environments:

•Commercial Buildings (Multi-Tenant Units)

•Business Parks (Multi-Tenant Units)

•Apartments (Multi-Residential Units)

•Hotels (Multi-Hospitality Units)

•Business Suites (Multi-Hospitality Units)

•School Campuses (University, K-12)

•College Housing (Multi-Residential Units)

•Mining Operations – Quarries, Mine shafts

•Nautical Infrastructure – Cruise ships, Marinas, dive operations, subs

•Video Surveillance/Security

•WiFi Deployment – ISP’s, RV Parks, Construction sites

•Manufacturing – Foundries, pharmaceutical, aerospace, automotive,

petroleum, concrete plants, etc.

•Retail POS – Department stores, Bars, restaurants, retail spaces

•Government – Naval ships, FEMA, Housing, USGS, National Parks, Forestry,

Research stations, NASA, utilities, etc.

•Education – outdoor camps, college campuses

•Healthcare – Hospitals, elder care, outpatient facilities

•Entertainment – Movie theaters, home entertainment, fairs, outdoor venues

INSTALLING THE 865 PTZQ PRO KIT

The Enable-IT 865 PTZQ PRO Extended PoE and Ethernet Kit has a distance restriction

of 1,500ft or 458m over 2-pair of Category 3 up to 4-pair Category 5e / CAT6 wiring from

your LAN and power source to the remote PoE device. Therefore quick, simple site

surveys and installation planning are highly recommended – This is ideal for installing PoE

IP Security cameras or PoE WiFi Access Points.

This chapter describes the recommended installation process for the Enable-IT 865

PTZQ PRO Extended PoE and Ethernet Kit. It covers the following topics:

•Site Plan – Installation Design Considerations

•Unpacking the Enable-IT 865 PTZQ PRO Extended PoE and Ethernet Kit

•Perform an out of the box Test

•Performing the On-Site Installation

Site Plan - Installation Design Considerations

The planning process should involve a site walkthrough and discovery survey. Electrical

Cable measurement tools are the most reliable method to determine the longest run of

hidden wiring. Estimate the best locations to position the Broadband Concentrators to

adequately reach desired connectivity on each floor. Document your findings to use in

designing a network topology to support the Ethernet Switches and backbone

connectivity. Key points to remember in the Site Survey.

•Total distance limitation of 1,500ft / 458m from end to end.

•2 Pair CAT-3 wiring or 4-pair Cat5e .30 Gage or better cabling is required for the

865 PTZQ PRO Interlink transmission.

•Not compatible with any PoE switches as the PoE switches are not smart enough

to understand Extender Ethernet timing mechanisms and fail to set correct output

voltage and will subsequently disable the PoE switch port.

•Transparent to single line 802.3at PoE injectors and devices.

For CAT3 wiring (2-pair/4 wires) you will need to crimp a RJ-45 Male Head to each

end of the contiguous wire run and using the following pins(1,2,4 or 5, 7 or 8) straight

through. This will deliver Ethernet Data and PoE.

For CAT5e or better wiring (4-pair/8 wires) you will need to crimp a RJ-45 Male Head

to each end of the contiguous wire run and using the following pins(1,2,3,4,5,6,7 & 8)

straight through. This will deliver Ethernet Data and PoE. This can be either T-568A

or T-568B spec.

Unpacking the Enable-IT 865 PTZQ PRO Extended PoE and Ethernet Kit

865 PTZQ PRO CO

Carefully remove the Enable-IT 865 PTZQ PRO Extended PoE and Ethernet Kit all

packing materials from the box. Verify that the items listed below are present. Make sure

that the equipment supplied matches what you ordered. If any items are missing or

damaged, please contact Enable-IT or your distributor for assistance.

•(2) The Enable-IT 865 PTZQ PRO & Extended Ethernet Units (CO & CPE)

o5v AC/DC Power adapter for 865 PTZQ CO

o10’ LAN patch cables

oEnable-IT 375 75W - 56v High Power PoE+ Injector

•(1) Enable-IT 865 PTZQ PRO Extended PoE and Ethernet Kit User Manual

Perform an out of the box Test

We highly recommend a quick test to ensure the working order of your 865 PTZQ PRO

units. To do this, please use one of the Ethernet patch cords provided and attach to the

865 PTZQ Interlink port on each 865 PTZQ unit.

Using the 5v power adapter, power up the 865 PTZQ PRO CO Unit and run another

Ethernet patch cord from LAN2/PoE on the 865 PTZQ PRO CO to LAN2/PoE on the 865

PTZQ PRO CPE. Next you will need to connect your PTZQ camera to the LAN1/PoE port

on the 865 PTZQ PRO CPE.

The last step is to then connect the 375 PoE Injector to the LAN1/PoE port on the 865

PTZQ PRO CO. After a few seconds you should see a solid Green Interlink Sync LED on

each unit to confirm a link is established. The Green Interlink Sync LED will pulse rapidly

as it detects traffic. This confirms basic proper operation of the units.

WARNING: Output LAN ports 1 & 2 on the 865 PTZQ PRO CPE are PoE enabled and

not for use with non-PoE equipment as it may damage any non-PoE equipment.

LED indicators will provide visual operational status of the 865 PTZQ PRO units.

Mode – Yellow Solid LED

Off = CO unit

On = CPE unit

Sync – Green slow to fast flicker LED on power up – indicates negotiation of a link

– Green solid LED indicates link established and rapid pulse is traffic

Act – Yellow LED

Off = No device attached or detected

On = Solid, indicates the presence of local LAN

On = Blinking, indicates the presence of local LAN traffic

Pwr – Green Solid LED indicates the unit is receiving 5v power

Performing the On-Site Installation

After removing the Enable-IT 865 PTZQ PRO Extended PoE and Ethernet Kit from the

box and performing the out of the box testing all that remains to install the unit on-site is

to mount the unit, build the interconnect wiring, add voice lines if needed and attach the

LAN device cabling with the provided Ethernet Patch cords.

Mounting the Enable-IT 865 PTZQ PRO Extended PoE and Ethernet Units

The Enable-IT 865 PTZQ PRO Extended PoE and Ethernet Kit is designed for quick

wall mounting. Choose a location to mount each of the Enable-IT 865 PTZQ’s

where the maximum distance does not exceed 1,500ft or 458m total between

devices to be connected. When mounting the Enable-IT 865 PTZQ PRO Extended

PoE and Ethernet Kit it is recommended that you use the appropriate anchors for

your mounting surface. If mounting on plywood use wood screws; if mounting onto

drywall or sheetrock, use plastic drywall anchors or Velcro can also be used as the

units are very lightweight.

Building the 865PTZ Q PRO Interlink wiring

The most important aspect of the install is the correct wiring of the Interlink cabling.

For CAT3 wiring (2-pair/4 wires) you will need to crimp a RJ-45 Male Head to each

end of the contiguous wire run and using the following pins(1,2,4 or 5, 7 or 8) straight

through. This will deliver Ethernet Data and PoE.

For CAT5e or better wiring (4-pair/8 wires) you will need to crimp a RJ-45 Male Head

to each end of the contiguous wire run and using the following pins(1,2,3,4,5,6,7 & 8)

straight through. This will deliver Ethernet Data and PoE. This can be either T-568A

or T-568B spec.

Attaching cabling and devices to the Enable-IT 865 PTZQ PRO Extended PoE and

Ethernet Kit. Attach your remote PoE device to the 865 PTZQ PRO CPE unit

LAN/PoE ports with Ethernet patch cord provided. Attach your local LAN to the 375

PoE injector Data IN port. Attach the power adapter to the 865 PTZQ CO unit. Attach

the 375 PoE+ injector to the 865 PTZQ PRO CO LAN1/PoE port with Ethernet patch

cord provided. Apply power to the 375 PoE injector with the country power cord

provided. Your equipment should now be powered up and functioning properly.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Enable-IT Extender Handbücher

Enable-IT

Enable-IT 850 CPE Bedienungsanleitung

Enable-IT

Enable-IT 870 CPE Bedienungsanleitung

Enable-IT

Enable-IT 828 Bedienungsanleitung

Enable-IT

Enable-IT 860 PRO Rev C Bedienungsanleitung

Enable-IT

Enable-IT 860XW PRO Bedienungsanleitung

Enable-IT

Enable-IT 895 Series Bedienungsanleitung

Enable-IT

Enable-IT 860XC PRO Bedienungsanleitung

Enable-IT

Enable-IT 865 PTZ PRO Bedienungsanleitung

Enable-IT

Enable-IT 8955M Bedienungsanleitung

Enable-IT

Enable-IT 860 W PRO Bedienungsanleitung

Enable-IT

Enable-IT 360 Bedienungsanleitung

Enable-IT

Enable-IT 8924 Bedienungsanleitung

Enable-IT

Enable-IT 865C PRO Bedienungsanleitung

Enable-IT

Enable-IT 860XS PRO Bedienungsanleitung

Enable-IT

Enable-IT 865 Bedienungsanleitung

Enable-IT

Enable-IT 865XSC PRO Bedienungsanleitung

Enable-IT

Enable-IT 865 Q PRO Bedienungsanleitung

Enable-IT

Enable-IT 865XC PRO Bedienungsanleitung

Enable-IT

Enable-IT 865XSC PRO Bedienungsanleitung

Enable-IT

Enable-IT 860XSC PRO Bedienungsanleitung

Enable-IT

Enable-IT 820P Pro Bedienungsanleitung

Enable-IT

Enable-IT 865XW PRO Bedienungsanleitung

Enable-IT

Enable-IT Pro 860C Bedienungsanleitung

Enable-IT

Enable-IT 850 Bedienungsanleitung

Beliebte Extender Handbücher anderer Marken

SY HDBT-60T Bedienungsanleitung

Appsys ProAudio

Appsys ProAudio ADX-16 Bedienungsanleitung

Atlona

Atlona RS232 Bedienungsanleitung

IDK

IDK OPF-TH1000-A Bedienungsanleitung

Worx

Worx Landroid RadioLink WA0864 Technisches Datenblatt

TP-Link

TP-Link TL-WA730RE Bedienungsanleitung

Camplex

Camplex CMX-HDMI-SFPL Bedienungsanleitung

SC&T

SC&T HE03-4K Bedienungsanleitung

Marmitek

Marmitek MegaView70 Bedienungsanleitung

Samsung

Samsung SCS-26UC4 Bedienungsanleitung

Foxun

Foxun SX-GES24 Bedienungsanleitung

MuxLab

MuxLab 500771 Bedienungsanleitung

foxunhd

foxunhd SX-AEX01 Bedienungsanleitung

TERK Technologies

TERK Technologies LFIRX2 Bedienungsanleitung

Devolo

Devolo Audio Extender Handbuch

Edimax

Edimax EW-7438RPn V2 Bedienungsanleitung

Shinybow USA

Shinybow USA SB-6335T5 Bedienungsanleitung

SECO-LARM

SECO-LARM ENFORCER EVT-PB1-V1TGQ Bedienungsanleitung
