Enable-IT 860XS PRO Bedienungsanleitung
Enable-IT 860XS PRO
Gigabit Ethernet Extender
Quickstart Guide
Professional Grade Networking
All Rights Reserved © 1982 - 2024 Enable-IT™, Inc.
INSTALLING THE 860XS PRO ETHERNET EXTENDER KIT
The Enable-IT 860XS PRO Gigabit Ethernet Extenders have a distance restriction of 3,000ft (914m) over 1-
pair of copper wiring from device extension to device extension. You can add an additional 328ft (100m) onto
the end of each 860XS PRO LAN output ports for a total distance of 3,656ft (1.1km) from device extension to
device extension. Therefore a site survey of the wiring and installation planning are highly recommended.!
!
For highest performance use 100Mhz or higher rated wiring for the interlink wiring connection.
We highly recommend that you perform a quick out of the box test to ensure the working order of your
Enable-IT 860XS PRO Ethernet Extender units prior to installing. This will also serve to familiarize you
with how easy the process should be. Follow the steps below to perform the Out Of the Box Test.
Step 1 - Attach the 12V DC power adapter to each 860XS PRO unit and power up the units.
Each of the respective Power LEDs will indicate the units are receiving power.
Step 2 - Connect the 860XS PRO RJ-45 Interlink ports together using one of the Ethernet LAN Patch cords
provided – as shown by the green line connecting the ports in the diagram above.
On both units, the green Link LED will blink rapidly when it sees the partner unit and connects
successfully. The LAN Port LEDs will blink as they see passing traffic (data).
Step 3 - Next for a more detailed test and to confirm your LAN Equipment works with the 860XS PRO, connect
your Ethernet LAN to the 860XS PRO Local unit LAN ports and the remote device/s to the 860XS
PRO
Remote 4 LAN ports and test connectivity. Green Blink rapidly when it sees the partner unit –
indicates working connection – Green No LED indicates it cannot see the partner unit.
!
LAN/Power side LEDs
Mode – Green LED (LED On = CO unit, LED Off = CPE unit)
Link – Green Blink rapidly when it sees the partner unit – indicates working connection
– Green No LED indicates it cannot see the partner unit.
Power – Green Solid LED indicates the unit is receiving 12V power.!
!
LAN Sync. – Green LED
Off = No device attached or detected.
On = Solid, indicates the presence of local LAN.
LAN Act. – Yellow LED
Blinking = Indicates the presence of local LAN traffic.
The Green Link LEDs will blink rapidly when it sees the partner unit and connects successfully.
This confirms basic proper operation of the units.!
All Rights Reserved © 1982 - 2024 Enable-IT™, Inc. Page of2 4
Building the 860XS PRO Interlink Wiring
The most important aspect of the installation is the correct wiring of the Interlink cabling.
The 860XS PRO Interlink port (RJ-45 Jack) carries this 1-pair signaling over the RJ-45 (pins 1 &
2) - and is used as the transport for Gigabit data.
For all wiring you will need to crimp a (LAN Standard) RJ-45 Male head to each end of the
contiguous wire run and using the following (pins 1 & 2) straight through. We recommend using
a category rated twisted pair cable as it is optimized for high throughput frequencies isolated
from cross-talk noise. Insert the completed RJ-45 ends into the 860XS PRO Interlink port on
each 860XS PRO unit (CO and CPE).
Cabling Devices to The Enable-IT 860XS PRO Extended Ethernet Kit
Attach your remote LAN device to the 860XS PRO CPE unit LAN ports with Ethernet patch cord
provided. Attach your local LAN to the 860XS PRO CO LAN ports with Ethernet patch cord
provided. Attach the power adapters to both 860XS PRO units.
Attach your local Interlink cabling end to the 860XS PRO CO unit Interlink port – Then do the
same for the remote end and plug into the 860XS PRO CPE unit Interlink port. The Sync LED’s
will flicker in a sequence talking to each other until they go solid. Your equipment should now
be powered up and functioning. LED indicators will provide visual operational status of the
860XS PRO units.
Troubleshooting
First examine the backbone wiring pair and make sure you have solid connections. The Interlink
green Link LED will blink rapidly when it sees the partner unit and connects successfully. If the
Interlink Sync LED Link is off…. Then follow the steps below:
1) Make sure your wiring is straight through and not connected to any Telco punch down
blocks; If so remove from the block and use Telco butt clips to bridge wire.
2) Check for a firm connection of the RJ-45 connections in each 860XS PRO unit, and
power is applied to the 860XS PRO CO & CPE units.
3) You can easily isolate any issue by performing an Out Of The Box Test (OOTBT). This test
will confirm the correct working order of your Enable-IT 860XS PRO Ethernet Extender Kit.
This will point to a possible issue with your long distance Interlink wiring being affected by
possible outside interference.
All Rights Reserved © 1982 - 2024 Enable-IT™, Inc. Page of3 4
860XS PRO CPE
860X PRO CO
RJ-45 Interlink Cabling up to 3,000 feet / 915m
TECHNICAL SUPPORT
Enable-IT, Inc.’s Customer Care Team support is available directly to customers and distributors. All
support requests are processed through the online support portal. This allows us to provide assigned
support ticket numbers in order to bring closure to any technical issues.
Online Technical Services
The Enable-IT Support Portal is available 24/7 to open a ticket or check the status of one. Please use
this support website as your first source for help as it contains an on-line knowledge base of articles,
documentation, FAQ's and other problem-solving resources. This web-based support resource
provides the quickest solution to the most common technical support issues.
Returning Products for Warranty Repair
Enable-IT warrants to the original purchaser of this described Product ("you" or the "End User") that,
for the limited lifetime period commencing on the date the Product was purchased (the “Warranty
Period"), the Product will be substantially free from defects in materials and workmanship under
normal use and conditions. Lifetime Warranty details here: https://warranty.enableit.com
This warranty does not apply to Products, which are resold as used, repaired or reconditioned.
Electrical or water damage is not covered under this warranty, extended warranties or
Advanced Replacement Program (AREP).
In order to obtain an authorized RMA approval, the End User must complete the required information
online located at https://support.enableit.com Ifyouhavequestionsordifficultycompletingthis
information you may contact the Customer Care Team at 888-309-0910 between the hours of 7:00
a.m. and 4:00 p.m. Pacific Time(PST).
Returning Products for Refund
Enable-IT, Inc. offers a generous 45-Day refund on a single Ethernet Extender Kit only, and is
subject to a 20% Restocking Fee. Shipments without a valid or authorized RMA number, or
sent to our corporate Las Vegas address, can be refused and / or billed for additional shipping.
CONTACT US
Sales and Customer Care:
Toll Free US and Canada 888 309-0910
Other International +1 702 924-0402
RMA Support:
https://support.enableit.com
All Rights Reserved © 1982 - 2024 Enable-IT™, Inc. Page of4 4
