Eneo ISM-72F0021W0A Montageanleitung

Full Manual

1/2.8” Network Module Camera,

Day&Night, WDR, H.265, PoE,

12VDC

ISM-72F0021W0A

ISM-72M2713W0A

ISM-78F0021W0A

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

To prevent fire or shock hazard, do not expose the unit to rain or moisture.

To prevent electric shocks and risk of fire hazards, do NOT use other than

specific power source.

Warning :

This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference when the equipment

is operated in a commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at

his own expense.

Caution :

Any changes or modifications in construction of this device which are not expressly

approved by the party responsible for compliance could void the user's authority

to operate the equipment.

Mains power quality should be that of a typical commercial environment. If the user

of the model requires continued operation during power mains interruptions, it is

recommended that the model be powered from an uninterruptible power supply

(UPS) or a battery.

The symbol is intended to alert the user to the presence of important

operating and maintenance(servicing) instructions in the literature

accompanying the unit.

The symbol is intended to alert the user to the presence of uninsulated

"dangerous voltage" within the product's enclosure that may be of

sufficient magnitude to constitute a risk of electric shock to persons.

Safety Precaution

MEGA PIXEL BOARD CAMERA

Contents

MEGA PIXEL BOARD CAMERA

Safety Precaution . . . . . . . . . . . . . . . . . . . . . . . . 03p

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 04p

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 05p

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 06p

Network Menu Control . . . . . . . . . . . . . . . . . 09~12p

. . . . . . . . . . . . . . . . . . . . . . . . . 07~08p

Specifications

2-1. Information

2-2. Video & Image

2-3. Event

2-4. System

1. LIVE VIEW

2. SETUP

Full Menu Setup . . . . . . . . . . . . . . . . . . . . . 13~56p

........................................................ 13p

............................................... 15p

......................................... 15p

Troubleshooting . . . . . . . . . . . . . . . . . . . . . 57~58p

.............................................................. 15p

........................................................ 31p

...................................................... 43p

3. 4 EYES PRINCIPLE ................................. 54~56p

Features

MEGA PIXEL BOARD CAMERA

• Full-HD 2.16Mega Pixel, IP Encoder module

• Ambarella S3L33M SoC platform

• The best low light performance with SONY’s STARVIS sensor

• ONVIF Conformance

• ONVIF Event Mapping

• Zero configuration

• Cross Web Browsing (IE, Edge, Safari, Firefox, Chrome)

• Adaptive web resizing depending on layout & resolution of

display device by RESPONSIVE WEB

• Increased usability for all PC, tablet and mobile

• Simultaneously H.264, H.264+ (Smart Stream),

H.265, H.265+ (Smart Stream), MJPEG (Multi streaming)

• Lens

> f2.1mm / F2.4, Fixed lens

> f2.7~13.5mm / F1.6, Motorized vari-focal lens

• True Day&Night by ICR

• DOL HDR (Digital Overlap High Dynamic Range)

• D-WDR (Digital Wide Dynamic Range)

• Improved noise figure with the enhanced 3DNR

• Smart Video Stream, ROI(Region of Interest)

- Enables to process video data smartly according

to users demand.

- Lowering overall bandwidth and reduce the storage burden

• Privacy Mask, Motion Detection, HLC/ BLC,

Digital Zoom(~x8), Mirror/Flip, Contrast, Brightness,

Hue, Saturation, Sharpness

• Circuit protection against faulty connection in power polarity

• Built-in Cooling Fan & Optimized Heat sink System

• PoE(IEEE Std. 802.3af) & DC12V

MEGA PIXEL BOARD CAMERA

(unit : mm)

Dimension

6350

f2.1mm Fixed lens type

f2.7~13.5mm Motorized vari-focal lens type

ITEM

Imaging Sensor

Effective Pixels

Scanning mode

Video Compression

Video Frame Rate

H.264, H.264+ (Smart Stream), H.265, H.265+ (Smart Stream), MJPEG

Video Resolution

FTP Uploading MJPEG Still Image

Video Streaming

NETWORK SPECIFICATION

Progressive Scan

S/N Ratio

Lens

50dB

Up to 25fps@1920x1080p

Shutter Speed

Control

Gain Control

f2.1mm / F2.4, Fixed lens

Automatic: Min. 1/25,000 sec ~ Max. 1/25 sec

Manual: Min. 1/25,000 sec ~ Max. 1/25 sec

Auto White Balance

mode

Automatic, Outdoor, Light bulb, Fluorescent light, Clear sky,

Shade, Manual

Automatic: ~ Max. 69dB / Manual: ~ Max. 69dB

1/2.8" Sony 2.16 Mega pixel RGB STARVIS CMOS Sensor

1945(H) x 1097(V) approx. 2.13M pixels

1920x1080, 1280x720,1024x576, 768x432, 704x392, 640x360, 384x216

Speciﬁcations

Power Source

PoE(IEEE Std. 802.3af ), DC12V

Dimension

50(W) x 50(H) x 63(L)

Operating Temp.

-20ºC ~ +50 ºC (Humidity : 20%RH ~ 80%RH, Non-condensing)

Day & Night mode

Automatic with ICR, Day, Night

Functions

Privacy Mask, Motion Detection, HLC/ BLC, Digital Zoom(~x8)

Mirror/Flip, Contrast, Brightness, Hue, Saturation, Sharpness

DNR

2D-NR, 3D-NR

HDR

DOL HDR (Digital Overlap High Dynamic Range)

Simultaneously H.264, H.264+ (Smart Stream),

H.265, H.265+ (Smart Stream), MJPEG (Multi streaming)

Independent Frame Rate and Bandwidth Control, VBR/CBR

MEGA PIXEL BOARD CAMERA

50(W) x 50(H) x 93(L)

RC-A2P21 RC-A2P2713M

f2.7~13.5mm / F1.6,

Motorized vari-focal lens

Color

B / W

Sensitivity

0.1 Lux

0.01 Lux

0.02 Lux

0.0008 Lux

Speciﬁcations

Synchronize Computer/NTP Server, ManualNetwork Time Sync.

Protocol

Restart, Reset, Factory Default

Software Reset

Backup, Restore

Auto Recovery

Using Web Browser

Remote Upgrade

Built-In Web, ONVIF Compatible 3rd Party VMS

Client Software

API, ONVIF Profile S/T Compliant

Not Available

SDK Support

SD memory card

Audio & Alarm

(*) Design and specifications are subject to change for product improvements without prior notice.

TCP/IP, UDP, IPv4/v6, HTTP, HTTPS, FTP, UPnP, RTP, RTSP, RTCP,

DHCP, ARP, Zeroconf, Bonjour, SNMP

Security

Multi User Authority, IP Filtering, HTTPS, Video Stream, Export/Import

MEGA PIXEL BOARD CAMERA

Setup Menu table

Category Menu

Configuration

LIVE VIEW

Player Control

Video Stream

Protocol

PTZ Control

Display (Window Fit, Full Screen, Custom)

Stream1, Stream2, Stream3

HTTPS, HTTP, TCP, UDP

Zoom, Focus, Push AF

Pause, Snapshot

SETUP

Information

Video & Image

Source

General, System Information, Open source Information

Stream1/2/3


Privacy Mask

Digital Zoom

Basic Brightness, Contrast, Saturation, Hue,

Sharpness, Enable flip image, Enable

mirror image

Enable text OSD, Enable date&time OSD,

Enable zoom&focus OSD Mode

Mode

Mode, Rotation

WDR(Mode, Level), DWDR(Mode, Level)

BLC(Mode, Level), HLC(Mode, Level)

3DNR(Mode, Level)

OSD

Mode, R Gain, G Gain, B Gain

AWB

Day&Night

WDR

BLC

DNR

LDC

VerticalView

Color, Name

Level

(***)

Mode, Speed, Lens Locking, Locking

Timer, Lens Calibration, Enable Day&

Night sync focus, Lens initialize on boot

Mode, Slow shutter, Luminance compensation,

Auto Iris, Auto Flickerless, Shutter,

Max. Shutter, Gain, Max. Gain

Smart

Video Stream

ROI(Region Of Interest), Dynamic GOP

Mode, Switching time, Threshold (D->N),

Threshold (N->D), Threshold(Current)

Network Menu Control

MEGA PIXEL BOARD CAMERA

Network Menu Control

MEGA PIXEL BOARD CAMERA

(***) Available only with the built-in Motor driven V/F lens version.

SETUP

System User, HTTPS, IP Filter, ONVIF, Video Stream,

Export/Import

Language

Current Time, New Time, Time Zone, Date & Time

Display

TCP/IP, DDNS, RTP, UPnP, Zeroconf, Bonjour

Security

Date & Time

Network

English, Deutsch, Français, 한국어

Maintain (Restart, Reset, Default), Upgrade,

Setup Export, Setup Import

Logs (Database Capacity, Search Condition, Log

List), Log Sever, Report

Maintenance

Logs & Report

Event

E-Mail, FTP, Video Boost, Notification Server

Actions

Triggers

Rules

Event Processing, ONVIF Mapping

Motion, Tamper, System, Manual, Network,

Timer, Day/Night

LOG OUT

Approval #1/2

4 EYES PRINCIPLE
