EnGenius EnStation 6 Bedienungsanleitung

ENH500-AX | EnStation 6

Quick Installation Guide

Outdoor Access Point

ENH500-AX

Waterproof*2

Device*2 PoE Adapter*2 Quick Installation Guide Power Cord*2

Screw Set*2 Pole Mounting Strap*2

Adhesive Label

Quick Installation Guide

Outdoor Access Point / Client Bridge

ENH500-AX | EnStation 6

Outdoor Access Point

Minimum Requirements

Broadband Internet Service

(Cable or DSL Modem)

Internet Browser

(Internet Explorer, Safari, Firefox, Chrome, Edge)

EnStation 6

Device *2

Sealing nut*2

Dynamic Stick*2

PoE Adapter*2

Bracket*2

Screw Set*2

Quick Installation Guide

Power Cord*2

Pole Mounting Strap*2

Outdoor Access Point

1 - Connecting the Device

a. Remove the rear bottom panel.

b. Connect one end of the Ethernet Cable to the LAN(PoE) port

of the AP/Bridge and the other end to the PoE Port on the

PoE Adapter.

c. Connect the Power Cord with the PoE Adapter and plug the

other end into an electrical outlet.

d. Connect the second Ethernet Cable to the LAN port of the

PoE Adapter and the other end to the Ethernet Port on the

computer.

e. Place the panel removed from step A back into the device.

• Note: The device should ONLY be powered via Ethernet Cable

connected to the included PoE Adapter.

ENH500-AX

b) c)

Outdoor Access Point

EnStation 6

a. Remove the rear bottom panel.

b. Connect one end of the Ethernet Cable to the LAN(PoE) port of the CPE and the other end to

the PoE Port on the PoE Adapter.

c. Connect the Power Cord to the PoE Adapter and plug the other end into an electrical outlet.

d. Connect the second Ethernet Cable to the LAN port of the PoE Adapter and the other end to

the Ethernet Port onto the computer.

e. Place the panel removed from step “a” back into the device.

• Note:

• The device should ONLY be powered via Ethernet Cable connected to the included PoE

Adapter, EnStation 6 supports Proprietary 24V/54V PoE input.

• The 2nd Ethernet Port of the device can supply the 802.3af power source when used with

the included PoE Adapter.

Outdoor Access Point

2 - IP Address Configuration

a. Once your computer is on, ensure that your TCP/IP is set to “ON” or “Enabled”. Open Network

Connections and then click Local Area Connection. Select Internet Protocol Version 4 (TCP/IPv4).

b. If your computer is already on a network, ensure that you have set it to a Static IP Address

on the interface. (Example: 192.168.1.10 and the Subnet Mask address as 255.255.255.0).

Outdoor Access Point

3 - Device Setup

a. To configure the device, open a web browser. In the web browser’s address bar enter 192 .168.1.1

and hit enter.

b. A long screen will appear. By default, the device username is “admin,” and the password is

“admin”. Enter the current username and password of the device and then click Login.

• Note: The model name on the login screen depends on the product you are using.

c. You can also use the EnWiFi App and connect to the management SSID ,which is on the device

label and GUI, to configure the device. The defailt Wi-Fi password is 12345678.

Outdoor Access Point

4 - Switching Modes

Configure on GUI

a. The device can operate in the following modes:

• Access Point, Client Bridge, WDS AP or WDS Station.

• Note: The model name on the login screen depends on the product you are using.

Outdoor Access Point

a. Click on the Wireless link under the Network and set up the Operation Mode.

b. Use EnWiFi App, open “Configure Wireless” to set up the Operation Mode.

Configure on EnWiFi App

• It may take up to 90 seconds for the device to initially power up.

Outdoor Access Point

5 - Mounting the Device

Wall Mounting

a. Determine where the Access Point is to be placed and stick the Adhesive label on the surface.

b. Use the appropriate drill bit to drill the 8.1 mm diagram and 26 mm depth holes on the

markings of the label.

c. Remove the label and Screw the anchors unto the holes until they are flush with the wall.

d. Screw the included screws into the anchors and place the Access Point against the wall with

the mounting screw heads.

Wall

Outdoor Access Point

a. Plug the dynamic stick into the bracket.

b. Screw the sealing nut and assembled parts, tighten it with 80kgf.cm.

c. Put the nock washer on the dynamic stick.

d. Assemble the mounting parts to the device.

e. Determine the mounting location. Mark and drill two pilot holes aligning to the screw holes of the bracket.

f. Put wall anchors into the holes and insert the screw into the wall anchor.

g. Screw and secure the bracket in place.

Wall
