Introduction

About Your Network Interface

The EpsonNet 802.11g Wireless Ext. Print Server is a wireless

network interface that connects to the USB port of an Epson device

(such as printer or all-in-one). With this network interface, you

can create a wireless connection between the Epson device and a

local area network using the IEEE 802.11b/g communication

standard.

A radio signal is transmitted over the wireless network when you

send a job to the device. Then the device prints or scans the file

when the network interface receives the radio signal directly from

a computer or from an access point.

This network interface is Wi-Fi certified for interoperability with

other 802.11-compliant products.

Because the network interface supports multiple protocols and

automatically detects protocols on your network, you can print

from Microsoft®Windows®, Apple®Macintosh®, UNIX®, and

IBM®OS/2 applications.

Use EpsonNet EasyInstall to easily configure the network

interface for use on a TCP/IP network. If you are using an

all-in-one, EpsonNet EasyInstall installs the drivers on your

computer. You can use the device on the TCP/IP network at once.

For protocols such as TCP/IP, NetWare, NetBEUI, AppleTalk®,

IPP, and SNMP, you can use EpsonNet Config, the configuration

utility provided with your product, to quickly and easily

configure the network interface to use these protocols.

R4CB860

html.bk Rev. F

INTRO.FM A5 size

10/19/04

LProof Sign-off:

KOW N.Mizuno H.Tomizawa

T.Takahashi

NOC K. Lee

Note:

The EpsonNet Config utility configures the network interface to work

only with protocols that exist on your network. This does not imply that

you can use all of the above-mentioned protocols on your network or

operating system. The protocols that the network interface can use may

vary depending on the operating system and the network configuration.

About This Guide

This Reference Guide contains information about using the

network interface on a network. It includes how to set up the

network interface, install the configuration software, and modify

network settings of your device and computer.

For information about your device, see the manual shipped with

the device.

Note:

❏To read the online guide, you must have Microsoft Internet Explorer

4.0 (or later) or Netscape Navigator 4.0 (or later) installed on your

computer.

❏This guide is written for network administrators, and many of the

steps included here require detailed network knowledge and

administrator rights.

❏The term “network administrator” refers to the person responsible

for maintaining the network. “Administrator” is synonymous with

“Supervisor” in this guide.

❏The term “network interface” refers to the EpsonNet 802.11g

Wireless Ext. Print Server in this guide.

❏The term “device” refers to the printer or all-in-one that is supported

by the network interface.

R4CB860

html.bk Rev. F

INTRO.FM A5 size

10/19/04

Proof Sign-off:

KOW N.Mizuno H.Tomizawa

T.Takahashi

NOC K. Lee

❏Some screen shots in this guide may list a device name other than

your device. This difference does not alter the instructions.

Instructions on Using the Network Interface

Notes on powering on and off

❏Do not turn off the device and the network interface when

changing the settings. This may damage the device and the

network interface.

❏Do not turn off the device and the network interface while

printing is in progress. This may cause operational trouble to

the computer sending the print data and suspend the printing

process.

❏Do not turn off the network interface during a firmware

update. Otherwise, the update cannot be completed correctly

and the network interface may not turn on (may not work)

after the update.

Notes on USB connection

❏Only supported devices can connect to a USB downstream

connector of the network interface. Do not use a USB hub.

❏Only IBM compatible computer or Macintosh equipped with

USB can connect to a USB upstream connector of the network

interface.

Notes on security

❏WEP Key

Set a WEP Key or WPA-PSK to prevent wireless interception

by unauthorized persons. The wireless transmission speed is

reduced when WEP or WPA-PSK is enabled because time is

required for encryption and decryption.

R4CB860

html.bk Rev. F

INTRO.FM A5 size

10/19/04

LProof Sign-off:

KOW N.Mizuno H.Tomizawa

T.Takahashi

NOC K. Lee

❏Security lock

Insert a commercially available theft-prevention cable

through the security lock, which is located on the back panel

of the network interface, to secure the device to a table or

pillar. This network interface is compatible with the

Microsaver Security System manufactured by Kensington.

Notes on radio waves

❏Radio wave interference may occur when there are devices

that use radio waves within the 2.4 GHz ISM band near the

network interface. Therefore, separate the network interface

from these devices as much as possible to prevent radio wave

interference.

❏When using the network interface in the Ad Hoc mode, radio

wave interference may occur if the channel of the network

interface and the other devices are close to each other.

Therefore, separate a few channels from the channel used near

the network interface.

❏Shorten the distance of the network interface and devices that

communicate with the network interface.

Where to locate the network interface

❏The location of the network interface must be considered to

improve the wireless communication. The rotary stand can

provide a good position. The condition of radio wave can be

checked using EpsonNet Config, lights of the network

interface, and the status sheet.

Package Contents

Your network interface package includes the following items.

R4CB860

html.bk Rev. F

INTRO.FM A5 size

10/19/04

Proof Sign-off:

KOW N.Mizuno H.Tomizawa

T.Takahashi

NOC K. Lee

❏Wireless network interface (The Web-based EpsonNet Config

is pre-installed.)

❏AC adapter and power cord

cCaution:

Only use the AC adapter shipped with this package to supply

power to the network interface.

❏USB cable

❏Software CD-ROM containing:

-- EpsonNet Config (for Windows)

-- EpsonNet Config (for Macintosh)

-- EpsonNet Print

-- EpsonNet Internet Print

-- EpsonNet WebManager

-- EpsonNet SetupManager

-- Reference Guide

-- Drivers and utilities for the following Epson devices:

EPSON STYLUS PHOTO RX500

EPSON STYLUS PHOTO RX600

EPSON STYLUS CX4600

EPSON STYLUS CX6400

EPSON STYLUS CX6600

❏Setup sheet

❏AC Adapter sheet

Note:

You need to supply items such as a computer with an 802.11b/g WLAN

compliant network interface card installed, an Epson device with a USB

port, a USB cable, and an access point (required for infrastructure mode

only).

R4CB860

html.bk Rev. F

INTRO.FM A5 size

10/19/04

LProof Sign-off:

KOW N.Mizuno H.Tomizawa

T.Takahashi

NOC K. Lee

Operating Environment

Supported operating systems

The network interface supports the following operating systems.

Printing environments

The network interface receives print jobs in the following

environments.

Supported operating systems Windows XP

Windows Me

Windows 98 Second Edition

Windows Server 2003

Windows 2000

Mac OS X 10.2 or later

Mac OS 9.1 or later

Operating systems Version Protocol

Windows XP

(Home,

Professional)

- TCP/IP (using LPR, Standard

TCP/IP Port, or EpsonNet Print)

IPP

Windows Me - TCP/IP (using EpsonNet Print)

IPP

NetBEUI

Windows 98

Second Edition

- TCP/IP (using EpsonNet Print)

IPP (using EpsonNet Internet

Print)

NetBEUI

R4CB860

html.bk Rev. F

INTRO.FM A5 size

10/19/04

Proof Sign-off:

KOW N.Mizuno H.Tomizawa

T.Takahashi

NOC K. Lee

Windows Server

2003

Windows 2000

(Professional,

Server)

- TCP/IP (using LPR, Standard

TCP/IP Port, or EpsonNet Print)

IPP

Macintosh Mac OS X 10.2.4

or later

AppleTalk

TCP/IP

Rendezvous

Mac OS X 10.2 or

later

AppleTalk

TCP/IP

Mac 9.1 or later AppleTalk

NetWare 3.x Bindery mode

4.x/IntranetWare NDS mode

Bindery emulation mode

5.x/6.0 NDS Queue-based print

system

NDPS

OS/2 (OS/2 Warp

Connect, OS/2

Warp Server)

TCP/IP (lprportd)

NetBEUI

UNIX Sun OS 4.1.4 or

later: SPARC

lpr, ftp

SunSoft Solaris 2.4

or later: SPARC

and x86

SCO UNIX 4.2 or

later

SCO UnixWare

2.01 or later

HP/UX 9.05 or

later

IBM AIX 3.2.5 or

later and 4.1.3 or

later

Operating systems Version Protocol

R4CB860

html.bk Rev. F

INTRO.FM A5 size

10/19/04

LProof Sign-off:

KOW N.Mizuno H.Tomizawa

T.Takahashi

NOC K. Lee

Note:

❏The multi-user environment of Mac OS 9 is not supported.

❏If you use the device in a dial-up router environment, you must set

an IP address for the device. Make sure the IP address is suitable for

the segment; incorrect IP address may generate unexpected dial-up.

❏See the manual shipped with your device for information on the

supported operating system of the device.

Scanning environments

The network interface supports EPSON Scan via TCP/IP and

allows network scanning when it is connected to the all-in-one.

The supported operating systems are Windows XP/Me/98/2000

and Mac OS X/9.

Network Storage environments

The network interface supports sharing memory via SMB when

it is connected to the all-in-one. The supported operating systems

are Windows XP/2000.

Supported Epson Devices

The network interface can be installed for the following Epson

devices (as of May, 2004).

❏Ink Jet Printer:

Stylus C64/C84

Stylus Photo 1280/2200

Stylus Photo R200/R300/R800

R4CB860

html.bk Rev. F

INTRO.FM A5 size

10/19/04

Proof Sign-off:

KOW N.Mizuno H.Tomizawa

T.Takahashi

NOC K. Lee

❏All-in-one:

Stylus Photo RX500/RX600

Stylus CX3600/CX4600/CX6400/CX6600

❏Laser Printer:

EPL-6200

EPL-N2500/N3000/N7000

AL-C1900/C4000/C4100

❏Impact Dot Matrix Printer:

FX-880+/890/1180+/2190

DLQ-3500

PLQ-20

LQ-590/630/2090

Features of the Network Interface

❏Meets the IEEE 802.11b/g (2.4 GHz) communication

standard.

❏Prints or scans via wireless network.

❏Supports the network storage function.

❏Supports both the Infrastructure mode and the Ad Hoc mode.

❏Supports the roaming function.

❏Supports 64-bit/128-bit WEP Key and WPA-PSK(TKIP).

❏Communicates with up to 11 or 13 channels.

❏Communicates with any Wi-Fi certified products.

❏Uses communication speeds at 11/5.5/2/1 Mbps for 802.11b,

54/48/36/24/18/12/9/6 Mbps for 802.11g, or automatically

changes the speed according to the radio waves.

R4CB860

html.bk Rev. F

INTRO.FM A5 size

10/19/04

LProof Sign-off:

KOW N.Mizuno H.Tomizawa

T.Takahashi

NOC K. Lee

❏Supports multiple protocols, such as TCP/IP, NetWare,

NetBEUI, AppleTalk, and IPP.

❏Supports DHCP.

❏Supports Automatic Private IP Addressing (APIPA) that

assigns an IP address automatically to the network interface

even if there is no DHCP server on your network.

❏Supports the Dynamic DNS function.

❏Supports Rendezvous on Mac OS X 2.4 or higher.

❏Supports SNMP and MIB.

❏Supports NTP (Network Time Protocol).

Andere Handbücher für 802.11g

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Epson Druckerzubehör Handbücher

Epson

Epson T408011 Bedienungs- und Wartungsanleitung

Epson

Epson T603C00 Bedienungs- und Wartungsanleitung

Epson

Epson T580300 Bedienungs- und Wartungsanleitung

Epson

Epson R300 - Stylus Photo Color Inkjet Printer Bedienungsanleitung

Epson

Epson T501201 Bedienungs- und Wartungsanleitung

Epson

Epson T545100 Bedienungs- und Wartungsanleitung

Epson

Epson T564900 Bedienungs- und Wartungsanleitung

Epson

Epson Stylus Color C60 Bedienungsanleitung

Epson

Epson T096620 Bedienungs- und Wartungsanleitung

Epson

Epson Stylus Color C60 Handbuch

Epson

Epson T096220 Bedienungs- und Wartungsanleitung

Epson

Epson T603500 Bedienungs- und Wartungsanleitung

Epson

Epson T043120 Betriebsanleitung

Epson

Epson T606400 Bedienungs- und Wartungsanleitung

Epson

Epson MSDS T6244 Betriebsanleitung

Epson

Epson C83202 Bedienungsanleitung

Epson

Epson T407011 Bedienungs- und Wartungsanleitung

Epson

Epson WorkForce 60 Bedienungsanleitung

Epson

Epson T543500 Bedienungs- und Wartungsanleitung

Epson

Epson Platen Grip Pad - L Bedienungsanleitung

Epson

Epson T077220 Betriebsanleitung

Epson

Epson T059420 Bedienungs- und Wartungsanleitung

Epson

Epson C6000P Bedienungsanleitung

Epson

Epson Stylus Photo R290 Bedienungs- und Wartungshandbuch

Beliebte Druckerzubehör Handbücher anderer Marken

Star Micronics

Star Micronics TSP800 Series Bedienungsanleitung

REA

REA JET HR pro 2K Bedienungsanleitung

HP Laserjet,Color Laserjet 4si Bedienungsanleitung

oliser

oliser MS 45 Bedienungsanleitung

Roland

Roland DU2-64 Anleitungen und Rezepte

Xerox

Xerox EFI EXP6000 Bedienungsanleitung

Canon

Canon Finisher-T1 Bedienungsanleitung

Sharp

Sharp FO-1MK Bedienungsanleitung

Labelmate

Labelmate PM-300 Bedienungsanleitung

Canon

Canon TonerRobot EP-27 Bedienungsanleitung

Ricoh

Ricoh LCIT RT5100 Kurzanleitung

GBC

GBC 16 Series Bedienungsanleitung

Canon

Canon INNER 2-WAY TRAY-E1 Bedienungs- und Wartungshandbuch

Develop

Develop SD-509 Bedienungsanleitung

Kyocera

Kyocera KM-6230 Handbuch

Triumph Adler

Triumph Adler DF-710 Handbuch

Citizen

Citizen CBM-202PC Series Bedienungsanleitung

Canon

Canon Color imageCLASS MF8170c Bedienungsanleitung
