Epson ActionLaser 1000 Bedienungsanleitung

EPSON

Connect Your Macintosh

Computer

to Epson Laser Printers

Installation Guide for

ActionLaser™ 1000

ActionLaser 1500

EPL-8000

CPD-1310

Epson

Talk

™

Connect Your Macintosh®Computer to Epson Laser Printers

Epson Talk allows you to use an Epson printer with your

Macintosh computer. Use this Installation Guide to install

Epson Talk quickly. If you require further details, please read

the manuals enclosed, Epson Interface Card for LocalTalk™

C823121 and

Epson PostScript™

Card C826091 User’s Guide,

along with your printer manual.

What You Need for Installation

A minimum of 2.0 MB RAM printer memory

LocalTalk cable (not included)

Interface Card for LocalTalk (C823121)

PostScript Card (C826091)

A cross-head screwdriver

An ActionLaser™ 1000, an ActionLaser 1500, or an EPL-8000

Before You Install Epson Talk

Use your printer’s Setup and Maintenance guide to set up and

test your new printer. Go only as far as test printing; you will

use the procedures in this guide to connect the Macintosh.

Once

you

see that your printer operates properly, install Epson

Talk as described below.

Installing the Interface Card

Make sure that both the printer and computer are turned off

and that all power and interface cables are removed from

the printer.

Caution:

Avoid touching the printer circuits or card circuit board

contacts. Otherwise, you may damage them.

Turn your printer so that its interface cover or shield plate

faces you.

3. Use a screwdriver to remove the screws securing the cover or

shield plate; then lift it off.

ActionLaser 1000/1500 EPL-8000

4. Slide the interface board into the grooves in the interface slot.

Push it in firmly to make sure it connects to the printer’s

internal socket.

ActionLaser 1000/1500

EPL-8000

Secure the interface with the two screws provided with

the card.

Attach your LocalTalk cable to the LocalTalk port (indicated

by the

icon) on the interface card. (Do not use the serial

port.) Then plug the other end of the cable into your

computer.

Plug the power cord into your printer and an electrical outlet.

Installing the PostScript Card

Caution:

Do not insert the card while the printer is turned on.

Do not touch the gold connectors along the card’s edge.

Do not use too muchforce when you insert and remove the

card. Otherwise, you may damage it.

Make sure the printer is turned off.

Hold the card so that the arrow on the card is aligned with

the arrow on slot A. (Do not use slot B.)

ActionLaser 1000/1500 EPL-8000

Gently but firmly slide the card into the slot as far is it can go.

4. Turn on the printer and computer.

Selecting PostScript

You need to change the emulation or mode setting through

SelecType before you can use PostScript.

The SelecType instructions below enable you to assign

PostScript quickly. If you need more detailed instructions on

using SelecType, see your printer manual

Note:

Be sure to install the interface and PostScript cards first. Otherwise,

the PostScript emulation or mode aloes not appear as a SelecType

option on the printer display.

For the ActionLaser 1000 and 1500

Press the

ON LINE

button to take the printer off line.

Press the

SelecType Level 2

button.

Press Vuntil EMULATION appears on the display.

4. Press

Press Vuntil CH O appears.

6. Press

Press Vuntil PS appears.

Press

to set the PS emulation.

9. Press the

EXIT

button twice to return to the READY message.

Note:

The READY message may not show O PS (indicating the

optional interface and PostScript) until after yourfirst print job

is sent from your computer to the printer each time you turn on

your printer.

10. Make sure that AppleTalk is active in the Chooser under the

Apple menu on your Macintosh.

11. Click LaserWriter in the Chooser menu. The name of your

printer appears in the Select a LaserWriter box. Click on the

name of your printer and then close the Chooser.

Note:

If the

LaserWriter printer driver is not yet installed on your

computer, you can find it on one

your Macintosh System disks.

Follow your computer manual instructions to install it on your

Macintosh.

12. begin printing using your application software.

For the EPL-8000

Note:

you have an Epson EPL-8000 printer, you must have aj%mware

version 22.48 or later to use Epson Talk. To find out your printer’s

firmware version, print a status sheet as described in your printer

manual. If you do not have the above firmware version, please call the

Epson Connection at (800) 922-8911.

Press the

ON LINE

button to take the printer off line.

Hold down the

SelecType

button until the

Level 2 light

comes on.

Press

until MODE ASSIGN appears on the display.

Press buntil CH P appears.

Press

until CH O appears.

6. Press

Press

until CH O PS appears.

8. Press

to set the PS setting.

Press

to return to MODE ASSIGN.

10. Press

until P-CONFIG.SAVE appears.

11. Press

twice to save

the CH

PS setting.

12. Press

twice to return to the READY message.

13.

Press the

ON LINE

button.

Note:

The READY message may not show O PS (indicating the

optional interface and

PostScript)

until after your first

job

is sent from your computer to the printer each time you turn on

your

printer.

14. Make sure that AppleTalk is active in the Chooser under the

Apple menu on your Macintosh.

15. Click LaserWriter in the Chooser menu. EPL-8000 appears

in the Select a LaserWriter box. Click on EPL-8000 and then

close the Chooser.

Note:

the LaserWriter printer

driver is not yet installed on your

computer, you can find it on one of your Macintosh System disks.

Use

your computer manual instructions

to install

if on your

Macintosh.

16. Begin printing using your application software.
