Epson F6070 Montage- und Wartungsanleitung

Epson® SureColor®

F-Series

Network Guide

No part of this publication may be reproduced, stored in a retrieval system, or transmitted

in any form or by any means, mechanical, photocopying, recording, or otherwise, without

the prior written permission of Seiko Epson Corporation. No patent liability is assumed with

respect to the use of the information contained herein. Neither is any liability assumed for

damages resulting from the use of the information contained herein.

Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this

product or third parties for damages, losses, costs, or expenses incurred by purchaser or

third parties as a result of: accident, misuse, or abuse of this product or unauthorized

modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly

comply with Seiko Epson Corporation’s operating and maintenance instructions.

Seiko Epson Corporation and its affiliates shall not be liable against any damages or

problems arising from the use of any options or any consumable products other than those

designated as Original Epson Products or Epson Approved Products by Seiko Epson

Corporation.

Microsoft®, Windows®, and Windows Vista®are registered trademarks of Microsoft

Corporation.

Apple®, AppleTalk®, and Bonjour®are registered trademarks of Apple, Inc.

EPSON and EPSON ESC/P are registered trademarks and EPSON AcuLaser and EPSON

ESC/P 2 are trademarks of Seiko Epson Corporation.

HP and HP LaserJet are registered trademarks of the Hewlett-Packard Company.

PCL is a registered trademark of Hewlett-Packard Company.

Adobe, the Adobe logo and PostScript3 are trademarks of Adobe Systems Incorporated,

which may be registered in certain jurisdictions.

CompactFlash is a trademark of SanDisk Corporation, registered in the United States and

other countries.

This product includes RSA BSAFE®Cryptographic software of EMC Corporation.

RSA and BSAFE are registered trademarks or trademarks of EMC Corporation in the

United States and other countries.

This product contains Runtime Modules of IBM Rational Rhapsody, Copyright IBM

General Notice: Other product names used herein are for identification purposes only and

may be trademarks of their respective owners. Epson disclaims any and all rights in those

marks.

This information is subject to change without notice.

2/13

CPD-39090

Safety Instructions

Warning, Caution, Important, and Note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Introduction

About Your Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

About This Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Features of the Network Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Network Interface Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Status light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Network connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

About the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

How To

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Selecting a Printing Method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Printing from Windows. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Features of the Printing Methods. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Installing Components on Your Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

About Installing Components on Your Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Windows 8/7/Vista . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Windows XP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Setting Up the Network Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Connecting the Network Interface to the Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Configuring the Network Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Installing the Printer Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

About Installing the Printer Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Windows 8/7/Vista . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Windows XP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Network Software

EpsonNet Config for Windows. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

About EpsonNet Config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Installing EpsonNet Config. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Accessing the EpsonNet Config User’s Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

EpsonNet Config with Web Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

About EpsonNet Config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Configuring the Network Interface Using EpsonNet Config with Web Browser . . . . . . . 28

Opening Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Troubleshooting

General Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Cannot configure the network interface or cannot print from the network. . . . . . . . . . . 31

Cannot print even if you have assigned the IP address to the computer and the printer.31

Unable to start EpsonNet Config. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

The message “EpsonNet Config cannot be used because no

network is installed.” appears when you start EpsonNet Config.. . . . . . . . . . . . . . . . . . 32

The message “Could not complete communicating configuration

data” appears when you send settings to the network interface.. . . . . . . . . . . . . . . . . . 32

Unable to start EpsonNet Config with Web Browser. . . . . . . . . . . . . . . . . . . . . . . . . . . 32

The Model Name and IP Address do not appear in the EpsonNet Config dialog box. . 33

Printing a Network Status Sheet (Large Format Inkjet Printers) . . . . . . . . . . . . . . . . . . . . . . 33

Tips for Administrator

Setting an IP Address on the Printer’s Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Network Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Software License Terms

Open Source Software Licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Bonjour. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Other Software Licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Info-ZIP copyright and license . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

WPA supplicant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Safety Instructions 6

Safety Instructions

Warning, Caution, Important, and Note

Warning

must be followed carefully to avoid serious bodily injury.

Caution

must be followed carefully to avoid bodily injury.

Important

must be observed to avoid damage to your equipment.

Note

contains important information and useful tips on the operation of your printer.

Introduction 7

Introduction

About Your Printer

Your printer has a built-in Ethernet interface and can connect anywhere on your network

using 10Base-T, 100Base-TX, and 1000Base-T Ethernet. The built-in Ethernet interface,

which is called the network interface in this manual, automatically selects the correct

standard when it connects to a network. In addition, it automatically selects appropriate

network protocols.

Because the network interface supports multiple protocols and automatically detects

protocols on your network, you can print from Microsoft®Windows®applications.

Use the Software Disc to easily configure the network interface for use on the TCP/IP

network and install the printer driver. You can use the printer on the TCP/IP network at

once.

If you want to configure the network interface for protocols such as TCP/IP, WSD, LLTD,

IPP/IPPS, UPnP, Bonjour, MS Network, and SNMP, use EpsonNet Config, the

configuration utility provided with your product, to quickly and easily configure the network

interface to use those protocols.

Note:

The EpsonNet Config utility configures the network interface to work only with protocols that exist

on your network. This does not imply that you can use all of the above-mentioned protocols on your

network or operating system. The protocols that the network interface can use may vary depending

on the operating system and the network configuration.

About This Guide

This Network Guide contains information about using the network interface on a network.

It includes how to set up the network interface, install the configuration software, and

modify network settings of your printer and computers.

For information about your printer, see your User’s Guide.

Note:

OTo read the guide, you must have Adobe Reader or Adobe Acrobat Reader installed on your

computer.

OThis guide is written for network administrators, and many of the steps included here require

detailed network knowledge and administrator rights.

Introduction 8

OThe term “network administrator” refers to the person responsible for maintaining the network.

“Administrator” is synonymous with “Supervisor” in this guide.

OThe term “network interface” refers to the built-in Ethernet interface of the printer in this guide.

OSome screen shots in this guide may list a printer name other than your printer. This difference

does not alter the instructions.

OThe supported operating systems are different depending on the printer. See your printer’s

User’s Guide for the supported operating systems.

Operating Environment

The network interface supports the following environments.

Features of the Network Interface

OConnects your Epson printer using a built-in Ethernet interface, which is called the

network interface in this manual, to the network.

OSupports multiple protocols, such as TCP/IP, WSD, LLTD, IPP/IPPS, UPnP, Bonjour,

MS Network, and SNMP.

OSupports 10Base-T, 100Base-TX, and 1000Base-T Ethernet.

Network Interface Operation

Status light

The indicator lights provide you with important information on the operations of the network

interface.

OS Protocol IPv4 IPv6

Windows 8

Windows 7

Windows Vista

Windows XP (Home,

Professional)

TCP/IP (Standard TCP/IP

port)

supported not supported

TCP/IP supported not supported

Introduction 9

Large format inkjet printers (Models that do not support 1000 Mbps

communication)

Large format inkjet printers (Models that support 1000 Mbps

communication)

Network connector

RJ-45 connector: This connector is used to connect an Ethernet cable to a network. You

can use this cable for 10Base-T, 100Base-TX, and 1000Base-T Ethernet.

Important:

You must use the following shielded twisted-pair cable to connect the network interface to a

network.

OCategory-5 or higher for the 10Base-T or 100Base-TX connection

OCategory-6 or higher for the 1000Base-T connection

About the Software

The Software Disc provided with your printer includes the following network software.

Note:

The software provided varies depending on your printer model.

Status light Data light Network Status

Green Yellow Ready (10 M link)

Green Yellow (Flashing) Receiving packets (10 M link)

Red Yellow Ready (100 M link)

Red Yellow (Flashing) Receiving packets (100 M link)

Status light Data light Network Status

Red Yellow Ready (100 M link)

Red Yellow (Flashing) Receiving packets (100 M link)

Green Yellow Ready (1000 M link)

Green Yellow (Flashing) Receiving packets (1000 M link)

Introduction 10

OEpsonNet Config for Windows is a Windows-based configuration utility for

administrators that allows you to configure the network interface for various protocols

such as TCP/IP, MS Network, AppleTalk, IPP, and SNMP. See “EpsonNet Config for

Windows” on page 26.

OEpsonNet Config with Web Browser is a Web-based configuration utility programs that

allow you to configure a network interface for TCP/IP, MS Network, AppleTalk, IPP, and

SNMP. See “EpsonNet Config with Web Browser” on page 27.

Andere Handbücher für F6070

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Epson Drucker Handbücher

Epson

Epson STYLUS PRO WT7900 Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Epson

Epson SC-F10030H Series Bedienungsanleitung

Epson

Epson SC-F9400H Series Bedienungsanleitung

Epson

Epson Stylus Color 200 Bedienungsanleitung

Epson

Epson DLQ-3000 Minerva+ Bedienungsanleitung

Epson

Epson WorkForce Pro WP-4595 DNF Bedienungsanleitung

Epson

Epson TM T70 Gebrauchs- und Pflegehandbuch

Epson

Epson AcuLaser M4000 Series Kurzanleitung

Epson

Epson Stylus Photo 1270 Handbuch

Epson

Epson Stylus C40UX Bedienungsanleitung

Epson

Epson 11880 - Stylus Pro Color Inkjet Printer Montage- und Wartungsanleitung

Epson

Epson XP-900 Series Bedienungsanleitung

Epson

Epson Stylus Pro 7900 Bedienungsanleitung

Epson

Epson Stylus Photo PX820FWD Benutzerhandbuch

Epson

Epson LQ-1050X Installations- und Betriebshandbuch

Epson

Epson Ecotank ET-2721 Bedienungsanleitung

Epson

Epson Stylus Pro 4880 ColorBurst Edition - Stylus Pro 4880... Gebrauchs- und Wartungshandbuch

Epson

Epson TM-L500A Bedienungsanleitung

Epson

Epson C2800 Bedienungsanleitung

Epson

Epson U295 - TM B/W Dot-matrix Printer Bedienungsanleitung

Epson

Epson Stylus NX105 Bedienungsanleitung

Epson

Epson TM-L90 series Bedienungsanleitung

Epson

Epson Stylus C87 Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung

IRA3D

IRA3D POETRY4 Bedienungsanleitung

Ricoh

Ricoh Aficio AP400 Bedienungsanleitung

BIXOLON

BIXOLON SRP-352plusV Bedienungsanleitung
