Setting Up the Printer

■Setting Up the Printer

❚Unpacking the Printer

Besides this guide, your printer box should include EPSON printer software disk, a

Notice Sheet, and the following items:

Note:

Depending on your printer model, the power cord may be permanently attached to the

printer.Also, theshapeofthepowercordplugvariesdependingonthecountryinwhich

you bought your printer; be sure the plug you have is the right one for your location.

cCaution:

There are several models of the printer designed for different voltages, and

it is not possible to adjust the printer for use with another voltage. If the

label on the back of the printer does not show the correct voltage for your

country, contact your dealer.

You must remove all protective materials packed around and inside your printer before

you set it up and turn on the power. Follow the directions on the Notice Sheet (packed

with the printer) to remove these materials. A screwdriver has been provided for

removing the transportation screw.

screwdriver ribbon cartridge

printer

power cord

paper separator

paper guide

PapU

booklet.fm Rev. A

A5-Format BookletENew.fm

4/28/99 Durchlauf 2

LProof-Abzeichnung:

K. Nishi _______

N.Nomoto _______

J.Hoadley _______

8Setting Up the Printer

Save all packing and protective materials, including the transportation screw and the

protective locking clips on the paper tension unit, in case you need to ship the printer

in the future. It should always be transported in its original packaging or equivalent

materials.

❚Choosing a Place for the Printer

Follow the guidelines below when selecting a location for your printer.

■Place the printer on a flat, stable surface. The printer will not operate properly if it

is tilted or at an angle.

■Place the printer where you can easily connect it to a network interface cable, if

necessary.

■Leave adequate room around the printer for easy operation and maintenance.

■Avoid using or storing the printer in places subject to rapid changes in temperature

and humidity. Also keep it away from direct sunlight, strong light, heat sources, or

excessive moisture or dust.

■Avoid places subject to shocks and vibrations.

■Place the printer near a wall outlet where you can easily unplug the power cord.

■Avoid electrical outlets controlled by wall switches or automatic timers. An

interruption in power can erase information in the memory of your printer or

computer.

Also avoid outlets on the same circuit as large motors or other appliances that can

cause voltage fluctuations.

■Keep the entire computer system away from potential sources of electromagnetic

interference, such as loudspeakers or the base units of cordless telephones.

■Use a grounded power outlet; do not use an adapter plug.

■Make sure the paper path is clear and unobstructed before you print on continuous

paper.

■If you plan to use a printer stand, follow these guidelines:

■Use a stand that supports at least 26 kg (57.8 lb).

■Never use a stand that tilts the printer. The printer should always be kept level.

■Position your printer’s power cord and interface cable so they do not interfere with

paper feeding. If possible, secure the cables to a leg of the printer stand.

PapU

booklet.fm Rev. A

A5-Format BookletENew.fm

4/28/99 Durchlauf 2

Proof-Abzeichnung:

K. Nishi _______

N.Nomoto _______

J.Hoadley _______

Setting Up the Printer

❚Positioning the continuous paper supply

Beforeusingcontinuouspaper,makesureyou lineupyourpapersupply withthetractor

feeder so the paper feeds smoothly into the printer, as shown below.

❚Installing or Replacing the Ribbon Cartridge

EPSONrecommendsusinggenuine EPSON ribboncartridges(S015086).Products not

manufactured by EPSON may cause damage to your printer not covered by EPSON’s

warranties.

1. Make sure the printer is turned off. The printer is off when the surface of the

Operate button is even with the button protectors as shown.

cCaution:

Moving the print head while the printer is on may damage the printer.

2. If the printer is connected to an electrical outlet, unplug it from the outlet.

When using the option When using the option

PapU

booklet.fm Rev. A

A5-Format BookletENew.fm

4/28/99 Durchlauf 2

LProof-Abzeichnung:

K. Nishi _______

N.Nomoto _______

J.Hoadley _______

10 Setting Up the Printer

3. Lift the printer cover by its back edge and then pull it straight up and off.

4. Slide the print head to the ribbon installation position (the indented portion of the

paper tension unit) by hand.

Note:

When the pull tractor is installed, you can replace the ribbon cartridge when

the print head is not in the ribbon installation position.

Andere Handbücher für LQ-2080

Inhaltsverzeichnis

Andere Epson Drucker Handbücher

Epson

Epson PM-525 Bedienungsanleitung

Epson

Epson Stylus PHOTO 1290 Bedienungsanleitung

Epson

Epson LQ-2090IIN Montage- und Wartungsanleitung

Epson

Epson PictureMate Flash - PM 280 - PictureMate Flash Compact Photo... Bedienungsanleitung

Epson

Epson FX-1050+ Bedienungsanleitung

Epson

Epson AcuLaser C4000 Bedienungsanleitung

Epson

Epson Stylus C84 Bedienungsanleitung

Epson

Epson WorkForce Pro WP-M4015 Bedienungsanleitung

Epson

Epson NX515 - Stylus Color Inkjet Bedienungs- und Wartungshandbuch

Epson

Epson CW-C6000A Gebrauchs- und Pflegehandbuch

Epson

Epson SureColor P800 Bedienungsanleitung

Epson

Epson T88IIIP - TM B/W Thermal Line Printer Gebrauchs- und Pflegehandbuch

Epson

Epson CANON i9100 Leitfaden

Epson

Epson Stylus Pro 7700 Series Bedienungsanleitung

Epson

Epson U375 - TM B/W Dot-matrix Printer Bedienungsanleitung

Epson

Epson EPI-4000 Abmessungen

Epson

Epson SureColor F2270 Bedienungsanleitung

Epson

Epson ColorPage EPL-C8000 Bedienungsanleitung

Epson

Epson DFX-5000+ Bedienungsanleitung

Epson

Epson TM-U200D series Bedienungsanleitung

Epson

Epson MX-80 IIIF/T Bedienungsanleitung

Epson

Epson 3880 - Stylus Pro Color Inkjet Printer Montage- und Wartungsanleitung

Epson

Epson ET-16650U Bedienungsanleitung

Epson

Epson ET-4800 Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung

IRA3D

IRA3D POETRY4 Bedienungsanleitung

Ricoh

Ricoh Aficio AP400 Bedienungsanleitung

BIXOLON

BIXOLON SRP-352plusV Bedienungsanleitung
