Epson PictureMate Leitfaden

Snap. Print. Enjoy.

CPD-19367R1

Printed in XXXXXX XX.XX-XX XXX

Using PictureMate

Without a Computer

Contents

Welcome! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Prepare to Print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Choose Photos to Print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Do More With Your Photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Save Your Photos to a Computer or an External Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Print From a Computer or an External Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Replace Ink and Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Take Your PictureMate With You . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Set PictureMate Preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Printer Care and Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

PictureMate®Deluxe Viewer Edition is your easy-to-

use, personal photo lab. Just insert a digital camera

memory card and you’re ready to print brilliant, long-

lasting photos. Because PictureMate is light and

portable, you can print whenever and wherever you

take pictures. Plus, your PictureMate photos are

archival; generations from now your PictureMate prints

will be as vibrant as they are today.

A Quick Introduction to the Digital

Photography Process

With film cameras, the process was

simple; buy film, take pictures, leave

the film at the photo lab, and come

back later for your photos and

negatives. Since you had negatives,

you could take them back later if you

wanted reprints.

The digital process is simple too, and it gives you

complete control. Just follow the basic steps shown on

the right.

1. Review and Delete

After you finish taking your photos, review

them on your digital camera’s screen.

Delete the photos you don’t want.

2. Print

Insert your camera’s memory card in

PictureMate, choose your photos, and

print.

3. Save

To preserve your digital photo files

(just like film negatives), save them to

a CD, flash drive, or your computer.

Then you can reprint them any time.

4. Clear the Memory Card

After you save your photo files, use your camera to

delete them from your memory card so you have

space for more photos.

Welcome!

Special Features

Printing with your PictureMate becomes even easier

with these special features:

From the PictureMate photo

selection menu, you can print all

your photos by simply pressing

the Print button. Or you can

select just the ones you want.

(See page 10.)

You can crop photos right from

PictureMate—no computer required.

(See page 17.)

If your camera supports DPOF (Digital

Print Order Format), you can pre-select

which photos to print while the memory

card is still in your camera. Then, when

you insert the card into PictureMate, it

knows which photos you chose; just

press OK, and then Print. (See page 16.)

You can add Disney®character frames to

your photos and see them on the

PictureMate screen before you print.

(See page 14.)

If you have a PictBridge®- or USB DP

(USB Direct Print)-enabled camera, you

can connect the camera to PictureMate and control

printing right from your camera. (See page 31.)

If you have a Bluetooth®-enabled PDA, cell

phone, or computer, you can send photos

wirelessly to PictureMate for printing. You

just need the optional Epson®Bluetooth Photo Print

Adapter. (See page 32.)

If you want to print outdoors or in other

places without convenient electrical outlets,

you can buy the optional PictureMate battery.

(See page 40.)

Note: PictureMate also supports P.I.M. (PRINT Image

MatchingTM) and Exif Print image enhancement standards that

are built into many cameras. To see if your camera is P.I.M.-

enabled, check www.printimagematching.com or see your

camera manual.

Photo selection menu

Crop

DPOF

Supported Photo Formats

Make sure your photos meet these requirements for

printing with your PictureMate (without a computer):

●JPEG files or uncompressed TIFF files only

●Resolutions ranging from 80 ×80 to

4600 ×4600 pixels

PictureMate recognizes and prints the first 999 photos

on your memory card.

Where to Find Information

See your Start Here poster to unpack,

set up, and use your PictureMate.

Using PictureMate Without a

Computer (this book) explains how to

print photos directly from your memory

card. It also covers how to print from

other devices, replace the Photo

Cartridge, and solve problems.

To use PictureMate with your

Macintosh®or Windows®PC, see

Using PictureMate With a Computer.

It explains how to install the software

and connect to your computer.

The on-screen User’s Guide

on the CD provides

comprehensive information

and instructions for using

PictureMate.

Where to Get Ink and Paper

See page 34 for information on where

to buy the PictureMate Print Pack.

Where to Get PictureMate Accessories

To order the optional battery, carrying case, and other

accessories, check your PictureMate retailer or go to

www.MyPictureMate.com. See page 40 for more

information about the battery.

JPEG TIFF

Before you can print, you need to load paper and

insert your memory card in PictureMate.

Loading Paper

Follow these steps to load PictureMate Photo Paper:

Caution: Don’t load plain paper; this may damage PictureMate.

1Move the handle to the back and down. Then tilt

up the photo viewer screen.

2Open the paper support and output tray.

Note: Keep the handle all the way down when printing,

to allow paper to feed through.

3Slide the top part of the paper support up gently

until it clicks into place.

Prepare to Print

Open output tray

Open paper support

4Place your paper against the right edge, with the

glossy side up.

Note: Make sure paper is glossy side up to prevent

smearing.

5Slide the left edge guide against the paper. Make

sure it is snug, but not so tight that paper can’t

move.

Note: When you need more paper, order a PictureMate Print

Pack. See page 34 for more information.

Inserting Your Memory Card

1Press the On button to turn on PictureMate.

2Open the memory card door.

3Insert the memory card into the correct slot, as

shown on page 7.

Push the card in carefully until it stops (it won’t go

in all the way).

Insert just one card at a time.

When it is in, the card light

comes on.

4Close the memory card

door.

Edge

guide

Load glossy

side up

button

Card

light

Now you are ready to choose your photos and start

printing (see page 9).

Removing Your Memory Card

When you are ready to remove a memory card, make

sure the card light is not flashing, then pull the card

straight out of the slot.

Caution: Do not remove a card while the card light is flashing;

you may lose photos on your card.

Saving Power

If you are not using PictureMate, the screen goes dark

after 13 minutes. Press any button to turn it back on.

If you are running PictureMate with the optional

battery, the printer turns off automatically after 15

minutes if it is not being used. Press the On button

to turn it back on.

MicrodriveTM

CompactFlash® (Type I + II)

Sony Memory Stick®

Memory Stick DuoTM *

Memory Stick PROTM

Memory Stick PRO DuoTM *

MagicGateTM Memory Stick

MagicGate Memory Stick DuoTM

SD (Secure Digital)

miniSDTM card **

MMCTM (MultiMediaCardTM)

xD Picture CardTM

xD Picture Card Type M

SmartMediaTM

Top:

Middle:

Bottom:

* Requires Memory Stick

Duo adapter

** Requires miniSD adapter

PictureMate’s photo viewer screen makes it easy to

select the photos you want to print.

You can choose from the following options for

selecting photos:

●Print all the photos on your card (see page 9)

●Select individual photos to print (see page 10)

●Select a range of photos to print (see page 11)

●Print photos taken on specific dates (see page 13)

●Print photos with fun Disney character frames (see

page 14)

●View a slideshow of all your photos (see page 15)

If your camera supports DPOF (Digital Print Order

Format), you can use it to pre-select which photos and

how many copies you want to print. PictureMate will

read the information on the card and automatically

print the selected photos. See page 16 for more

information.

By pressing the Menu button, you can choose from a

variety of layouts, add the time or date, fix photos that

are too light or dark, and control many other aspects of

printing. You can also use the and buttons to

crop your photos. See the section beginning on

page 17 for more information about these features.

Note: When you press the Print button, PictureMate shows you

a screen confirming the number of copies and layout. If you

don’t want to see the print confirmation each time you print,

you can turn it off. See page 45 for instructions.

Choose Photos to Print

Printing All Photos

When you turn on PictureMate, you see the photo

selection menu on the photo viewer screen. The red or

orange bar at the top of the screen indicates the

currently selected option.

1Make sure Print All is highlighted, then press OK.

2If you want more than 1 copy of each picture,

press the or button to select the number of

copies.

You can also press the Menu button to adjust

settings if necessary. See page 17 for more

information.

3Press the Print button. You see the Print

Confirmation:

You can press or to review your photos. If you

change your mind, press the Back button.

4Make sure you have enough paper loaded, then

press Print again to start printing.

Andere Handbücher für PictureMate

Inhaltsverzeichnis

Andere Epson Drucker Handbücher

Epson

Epson AcuLaser MX20DN series Bedienungsanleitung

Epson

Epson C117001-N - DFX 5000+ B/W Dot-matrix Printer Bedienungsanleitung

Epson

Epson SureColor T3000 Bedienungsanleitung

Epson

Epson WorkForce Pro WF-C878RB Bedienungsanleitung

Epson

Epson WorkForce Pro WF-R5690DTWF Bedienungsanleitung

Epson

Epson B-300 - Business Color Ink Jet Printer Betriebsanleitung

Epson

Epson EPL-8000 Bedienungsanleitung

Epson

Epson R2400 - Stylus Photo Color Inkjet Printer Bedienungsanleitung

Epson

Epson C11CA19201 - WorkForce 30 Color Inkjet... Bedienungsanleitung

Epson

Epson Stylus Color 800 Technisches Datenblatt

Epson

Epson EPL-6000 Bedienungsanleitung

Epson

Epson SureColor F571 Bedienungsanleitung

Epson

Epson LQ 670 - B/W Dot-matrix Printer Bedienungsanleitung

Epson

Epson L110 Bedienungsanleitung

Epson

Epson WorkForce WF-2540 Bedienungsanleitung

Epson

Epson XP-640 small-in-one Bedienungsanleitung

Epson

Epson Printer Bedienungsanleitung

Epson

Epson C11C417001 - Stylus Photo 820 Color Inkjet... Abmessungen

Epson

Epson Stylus Color Stylus Color IIs Bedienungsanleitung

Epson

Epson AcuLaser CX16 Bedienungsanleitung

Epson

Epson EPL-N1200 Bedienungsanleitung

Epson

Epson WorkForce Pro WP-4015 DN Bedienungsanleitung

Epson

Epson LQ-1500 Abmessungen

Epson

Epson U295 - TM B/W Dot-matrix Printer Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung

IRA3D

IRA3D POETRY4 Bedienungsanleitung

Ricoh

Ricoh Aficio AP400 Bedienungsanleitung

BIXOLON

BIXOLON SRP-352plusV Bedienungsanleitung
