Estes Sky Writer Bedienungsanleitung

SHOCK CORD

MOUNT

SECTION 3

SECTION 2

SECTION 1

ESTES® INDUSTRIES

1295 H Street

Penrose, CO 81240

PRINTED IN CHINA

www.estesrockets.com

SUPPLIES REQUIRED:

ALL GLUED AREAS ARE SHADED IN GRAY

HOBBY KNIFE PLASTIC

CEMENT CARPENTER’S

GLUE PENCIL RULER SCISSORS FINE

SAND PAPER

(#400-600 GRIT)

MASKING

TAPE

FLYING MODEL ROCKET KIT INSTRUCTIONS

HELPFUL HINT:

IF NOSE CONE/COUPLER FIT IS. . .

TOO

TIGHT

TOO

LOOSE

ADD

MASKING TAPE. SAND FOR FIT.

Black Engine

Holder Ring (1)

(30120-3)

Blue Engine

Mount Tube (1)

(30326-1)

Fin Unit (1)

72614

Launch Lug (1)

(38175)

Red Tube

Coupler (1)

(30174-5)

Decal Sheet (1)

(60160)

Assembled 12” (30 cm) Parachute

(35801)

Lower Body Tube - BT-50 (1)

(60158) Upper Body Tube - BT-50 (1)

(30349)

Nose Cone (1)

(71027)

Green Engine

Block (1)

(30162-2)

PARTS:

Locate the parts shown below and lay them out on the table in front

of you. DO NOT USETHIS DRAWINGTOASSEMBLE YOUR ROCKET.

KEEP FOR FUTURE REFERENCE.

SPRAY CLEAR

COAT

(OPTIONAL)

NO.2

Green Adaptor

Ring (1)

(30165-2)

ASSEMBLY TIP

Read all instructions before beginning work on your model.Make sure

you have all parts and supplies. TEST-FITALL PARTS TOGETHER

BEFORE APPLYING ANY GLUE. If any parts don’t fit properly, sand

as required for precision assembly.

FOR KITS:

EST 1235

EST 1260

Engine Hook (1)

(35021)

Shock Cord (1)

(38374)

1”

(25 mm)

B. Cut a 1/8” (3 mm) wide

slit with Hobby Knife at

the 2 1/2” (63.5 mm)

mark.

C. Position Engine Hook.

D. Apply glue just

in front of 1"

(25 mm) mark.

1/8”

(3 mm)

GLUE

E. Slide Black Retainer

Ring onto Engine

Mount Tube to the

1” (25 mm) mark.

F. Apply glue inside front of

Engine Mount Tube.

GLUE

G. Insert Green Engine Block inside

Engine Mount Tube until it contacts

Engine Hook. Let Dry. Finished Assembly

1/2”

(13 mm) REDTUBE

COUPLER

C. Hold Engine Mount Assembly

in place with thumb. In one

continuous movement slide

Green Adapter Ring onto

Engine Mount until it touches

Fin Unit. Let glue dry.

C. Apply glue band inside forward end

of Lower Body Tube Assembly.

B. Lightly scratch a 1" x 1/8" (25 mm x 3 mm) area

of the Body Tube with a hobby knife.

C. Glue Launch Lug onto Body Tube.

Let glue set. D. Apply glue fillet on each side of Launch

Lug. Smooth with finger and let dry.

page 2

ENGINE MOUNT ASSEMBLY

Blue Engine

Mount Tube

A. Locate slot in the Fin Unit. Align Engine

Hook of Engine Mount Assembly with slot

in Fin Unit and slide in place until it stops.

3/8” (10 mm)

GLUE

D. Apply glue inside Lower Body Tube

as shown. Push Body Tube over

Green Adaptor Ring in one

continuous motion, until Body Tube

touches Fin Unit.

B.Apply glue band around inside of Upper Body

Tube and insert Red Tube Coupler up

to 1/2” (13 mm) mark Let glue set.

ATTACHING

LAUNCH LUG

A. Use a ruler to reference a straight line up from

the Engine Hook. Make a small mark on body

tube 5-1/2” (14 cm) up from end of Fin Unit.

GREEN

ADAPTER

RING

2 1/2”

(63.5 mm)

MARK

FIN UNIT ASSEMBLY

SLOT

B.Apply glue around Engine

Mount Assembly as shown.

1/2” (13 mm)

GLUE

BODYTUBE

ASSEMBLY

1/2” (13 mm) mark

ENDS

EVEN

D. Slide over Red Tube Coupler.

Let Dry.

GLUE

REDTUBE

COUPLER

GLUE

ALIGNWITH

ENGINE HOOK

5 1/2”

(14 cm)

A. Cut out Shock Cord

Mount from front page.

SHOCK CORD

MOUNT

SECTION

Glue Mount inside BodyTube.Hold

until glue sets.Let glue dry

completely.

Squeeze

Tightly. E.

Fold

Forward.

Shock Cord

D. Pass Parachute

through loop.

C. Push loop through

eyelet of Nose

Cone.

A. Remove FLASH from

eyelet of Nose Cone.

SHOCK CORD

ROCKET PREFLIGHT

B. Spike.

A. Insert 3-4 loosely crumpled

squares of RecoveryWadding. E. Wrap lines loosely, insert

Parachute, Shock Cord and

Nose Cone.

C. Fold.

D. Roll.

CAUTION:

DO NOT CUT OFF

EYELET OF NOSE CONE.

page 3

ATTACHING SHOCK CORD

C. 3

Smear Glue.

ATTACHING PARACHUTE & SHOCK CORD

7. DECAL APPLICATION

OPTIONAL: Clear coat entire rocket after applying decal.

Carefully remove Decal from sheet and apply where

shown.Rub down to remove bubbles.

B. Form loop with

Shroud Lines.

DOUBLE

KNOT

DECAL

PULL

TIGHT

E. Pull Parachute tight.Tie Shock

Cord to eyelet of Nose Cone with

a double knot.

2”

(51 mm)

YES

COUNTDOWN AND LAUNCH

NAR Safety Code

NO DRY GRASS

OR WEEDS

PRECAUTIONS

HOLD KEY DOWN AND PRESS LAUNCH

BUTTON UNTIL LIFT-OFF!

15 FT. (5 M)

MASKING

TAPE

INSERT KEY.

PUSH DOWN

AND HOLD.

FLYINGYOUR ROCKET

Choose a large field (500 ft. [152 m] square) free of dry weeds and

brown grass.The larger the launch area, the better your chance of

recovering your rocket. Football fields and playgrounds are great.

Launch only with little or no wind and good visibility.

Always follow the National Association of Rocketry (NAR)

SAFETY CODE.

MISFIRES

TAKE THE KEY OUT OF THE CONTROLLER. WAIT ONE MINUTE

BEFORE GOING NEAR THE ROCKET! Disconnect the igniter clips and

remove the engine. Take the plug and igniter out of the engine. If the igniter

has burned, it worked but did not ignite the engine because it was not

touching the propellant inside the engine. Put a new igniter all the way

inside the engine without bending it. Push the plug in place. Repeat the

steps under Countdown and Launch.

4...

1...

1... 3...

3...

LAUNCH SUPPLIES

•Estes® Porta Pad® II Launch

Pad and Electron Beam® Controller

•Recovery Wadding

•Igniters (with Engines)

•Igniter Plugs (with Engines)

•Estes® Recommended Engines:

A8-3, B4-2, B4-4, B6-4, C6-5

(Sold Separately)

ENGINE PREP

A. B. Tip must touch

propellant. F. Insert Engine.

C. E.

page 4

4”(10.1 cm)

KEY ALWAYS OUT

UNTIL FINAL

COUNTDOWN!

2...

4... 3...2...1...

5...

LAUNCH

BUTTON
