Etac Turner PRO Gebrauchsanweisung

Turner PRO

Wheels / Wheel axles

Rotating mechanism

If turner rotates porly:

• Unscrew bolt (5).

• Clean Low friction disc (2) and ﬂoor plate (1).

• If deep groves or damages in (1) or (2), replace

(1,2,3,4,5).

• Apply loctite 243 or simular on bolt (5), tighten bolt

ﬁrmly (approx 20Nm).

If antislip knobs are missing or worn down:

• Flip out old knobs (3).

• Clean holes and push in new knobs.

Washing

• Lay the Turner PRO on the ﬂoor in an angeled position

after washing, so the water runs out of the rotating

mechanism.

• You may also use copressed air to blow dry inside

rotating mechanism.

• Controls wheel and shaft for wear.

• Check if the wheels turn easily, remove hair and dirt.

If wheels are worn out, or still rotates porly after

cleaning:

• Use a solvent-free detergent with a pH level bet-

ween 5 and 9.

• Can be washed at 70° C for 10 minutes.

• Flip out starlock with

an screwdriver or

simular (1).

• Remove bolt and

wheel.

• Replace 1,2,3.

• Place wheel between

forks.

• Insert bolt and knock

.starlock in place.

Reconditioning

Turner PRO

Leg Support

Main plate/outer pole

• Check bracket on leg support for cracks and

wear. If cracs, replace coplete leg support.

• Check cushion for wear, should be tight and ﬁrm

around the pipe. If loose or damaged, replace

cushion.

Original spare parts from Etac should always be used.

Handle/inner pole

• Check for cracs and dents, if cracs or dents

replace inner pole.

If complete leg support needs to be replaced:

• Unscrew bolts and remove outer pole.

• Pull leg support out of pole.

If cushion need to be replaced:

• Flip out knob (3) and remove cushion.

• Clean pipe, insert new cushion and knock knob in

place.

• Insert leg support with kneepads pointing upwards

• Make sure both knobs are on the same side (1).

• Tighten knob by turning knob clockwise (2).

• Place the base plate on an even surface. Insert

pole with knee pads facing away from

the wheels.(1)

• Insert all three screws into holes in the base

plate. Use allen key to screw in bolts. Apply

loctite 243 or simular on bolts, tighten

bolt ﬁrmly, (approx 20Nm). (2)

• Check for cracks and wear on main plate and

outer pole. If cracks, replace complete Turner-

PRO.

• Check bolted conection between pole and

main plate (3 bolts), if loose bolts tighten all

bolts.

Reconditioning
