EverFocus EVS410 Betriebsanleitung
www.everfocus.com
Ordering Info
Dimensions: mm/in
2012 EverFocus Product Catalog Vs 1.1 - Models vary in different countries. Visit www.everfocus.com and select your country for additional ordering and specication information.
EverFocus is not responsible for typographical errors. Product specications are subject to change without notice.
IP Solutions
EVS410
Features
• High quality H.264/ and MJPEG
• Dual stream (per channel) for simultaneous live monitoring and high
resolution recording
• Smart Wizard setting for varies event and schedule recording
• Built-in SD memory card slot for local storage
• Supports SD high capacity
• Space saving with ultra compact design
EVS410: 4 Ch., Video Server Encoder
31
Web Viewer
Smart Event
Wizard
Two-Way
Audio
SD
Card
Slot
Specications
Channels 4
Recording/Playback
Rate up to 30 FPS per channel
Total Recording Rate up to 120FPS (4 channels up to 30 FPS each)
Recording Resolution 4CIF, VGA, CIF, QVGA, QCIF
Compression Supported H.264/M-JPEG
Compression Method IMA ADPCM (Pulse Code Modulation)
Audio Two-way audio
Video Storage (Excludes
O/S and system software on
HDD 1)
SD card interface for local storage, supports SDHC
Network Interface 10Base-T/100Base-TX auto-negotiation, RJ-45 socket. Supports
MDI/MDI-X auto crossover function.
Max Client Limit 32 simultaneous clients
Pre/Post Alarm Buffer Unsure, as no mention is technical specs, advisable to leave it as “”
Alarm I/O 4 in/ 2 out
Event Trigger Alarm Input, Manual Trigger, Motion Detection and Schedule
Recording
Notication Trigger alarm output, send email notication, upload video to FTP,
record video to SD card, record video to PC and network alarm
PTZ Supports PTZ control
Remote Video Access
Method Internet Explorer 8
Power 12VDC
Power Consumption 36W (12VDC)
Temperature 0°C ~50°C /
32°F~122°F
Housing Compact
Dimensions 5.2”(W) x 1.5”(H) x 6.5” (D)
Weight 1.47 lbs
Certications CE, FCC
