EverFocus ED200 Series Bedienungsanleitung
ED200
INSTRUCTION
MANUAL
Important Safeguards
?Read all of these instructions.
?Save these instructions for later use.
?All warnings on the products and in the operating instructions
should be adhered to.
?Unplug this appliance system from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners, use a
damp cloth for cleaning.
?Do not use attachments not recommended by the appliance
manufacturer as they may cause hazards.
?Do not use this appliance near water, for example, near a
bathtub, washbowl, kitchen sink, or laundry tub, in a wet
basement,or near a swimming pool,etc.
?Do not allow anything to rest on the power cord. Do not
locate this appliance where the cord will be abused by persons
walking on it. 1
?Follow all warnings and instructions marked on the appliance.
?Do not overload wall outlets and extension cords as this
can result in fire or electric shock.
?Never push objects of any kind into his appliance through
cabinet slots as they mat touch dangerous voltage points or short
out parts that could result in fire or electric shock.
?Do not place this appliance on an unstable cart, stand,or table.
?The appliance may fall, causing serious injury to a child or
adult, and serious damage to the appliance.Use only with a cart
or stand recommended by the manufacturer,or sold with the
appliance.Wall or shelf mounting should follow the
manufacturer’s instructions, and should use a mounting kit
approved by the manufacturer. An appliance and cart combination
should be moved with care, Quick stops, excessive force,
2
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER ( OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERRSONNEL.
The lightning flash with an arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the presence
of non-insulated ”dangerousvoltage”within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric
shock to persons.
This symbol is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature
accompanying the appliance.
3
Note:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection. This equipment generates,
uses and can radiated radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interferenceto
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which canbe
determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase these paration between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
The changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
4
I. General
The ED200 Series Camera is a compact, full functioned CCD
Camera. Their stylish appearance can be applied as per installer's
ideal locations. These dome cameras can be mounted either on the
ceiling or on the wall easily. ED200 uses high sensitive 1/3" color
interline transfer CCD sensor with DSP. The sensor is featured
with Auto Electronic Shutter, Automatic Gain Control, and Auto
White Balance function.
II. Precautions
•Do not expose the camera to humidity and dust. Outdoor
application without shielding is not recommended.
•Handle with care. This camera consists of sensitive high
precision parts. Do not disassemble or install it on an
unstable base.
•Operate on DC +12V. Use a regulated power source only.
•The external adapter is optional.
•Never face the camera toward the sun directly.
5
III. Lens Available
IV. Installation Instructions
1. Remove the plastic dome cover.
2. Loosen the two screws of the supporting bracket to
remove the camera body.
3. Using four screws to fix the camera base on the ceiling.
4. Put the camera body back to the supporting bracket, the
connector of the back panel should always be placed to
camera’s left lower corner, in order to obtain the image of
best quality. Tighten the 2 screws to fix the camera. Please
refer to the back panel diagram shows as below:
* Standard board lens f=3.6 mm, F=2.0 mm.
* Other available lens : -2 Lens f=2.5 mm, F=2.0 mm
-4 Lens f=4.3 mm, F=2.0 mm
-6 Lens f=6.0 mm, F=2.0 mm
-8 Lens f=8.0 mm, F=2.0 mm
-3P Pinhole lens f=3.7 mm, F=3.0 mm
6
5. Connect the BNC connector of the camera to a color
monitor, or other video device through a 75 ohm
type coaxial cable with BNC female connector at
cable extension.
a. Floor Mount b. Ceiling Mount
c. Wall mount,
aim to the right d. Wall mount,
aim to the left
7
6. Connect the DC +12V regulated power source
of the camera (DC Jack) to the DC 12V Power-
in jack with 2 mm, center+, outer-plug.
7. Once the image appears on the monitor, loosen
the fixing screw located at the lens mount then
adjust the focus and diaphragm of the lens to
obtain the best picture. When the ideal picture is
obtained, secure the lens mount by fixing screw
firmly again.
8. Put the plastic cover back on the Dome Camera.
8
V. Specifications
Pickup device: 1/3“interline transfer CCD
Picture element: 510 x 492 (NTSC)
500 x 582 (PAL)
Horizontal resolution: 380 TV Lines
Sensitivity: 0.3 Lux/F=1.2
S/N ratio: Over 48 dB
Electronic shutter: Up to 1/100,000
Auto white balance: Yes
Gamma correction: 0.45
Video output: 1.0Vp -p, 75 ohm
Power source: 12V DC ?10%
Sync. Mode: Internal Sync.
Lens mount: M12 x P0.5
Dimension: 106 mm (D) x 85 mm (H)
Operating temperature:-10°C to +50°C
Power consumption: 3W
9
