USER MANUAL

Video Borescope

Wireless Inspection Camera

Models BR200, BR250, and KITS

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

2BR200-BR250-KITS_en-GB_v9.1 3/20

Introduction

Thank you for selecting the Extech Video Borescope Model BR200 (17mm camera), BR250 (9mm

camera), BR250-4 (4.5mm camera), or BR250-5 (5.2mm).

Cameras provide a glare-free close-up field of view. They include a 3.5" color TFT LCD wireless

monitor that can be detached from the base and viewed from a remote location up to 10m (33

ft.) from the measurement point. Capture images and videos (with date/time stamp) on the SD

card and view them on the supplied Monitor, an alternate monitor (video out jack), or a PC (USB

connection). This device is ideal for home inspections (mold, insect infestation, electrical wire or

water pipe location), HVAC (inspect ducts, behind motors and compressors), and automotive

applications (view inside and around engines and transmissions). We ship these devices fully

tested and, with proper use, will provide years of reliable service.

Features

17mm (BR200), 9mm (BR250), 4.5mm (BR250-4), or 5.2mm (BR250-5) diameter water-proof

(IP67) camera head with 1m (39") flexible cable

Bright LED lamps on camera head with dimmer to illuminate viewed object

Glare-free close-up field of view

Detachable color TFT monitor wirelessly displays video remotely from the camera, to a

distance of 10m (33 ft.) maximum

Micro SD memory card (included) stores images and video

Captured video and still images with date/time stamp can be viewed on the supplied

wireless monitor, an additional monitor (via video out jack), or a PC (USB connection)

Video and images can also be transferred to your PC via the micro SD card (included SD

adaptor)

Menus in 10 languages: English, Chinese, German, French, Spanish, Portuguese, Italian,

Japanese, Dutch, and Russian

Includes four (4) AA batteries for camera controller, rechargeable battery for monitor, micro

SD memory card with SD adaptor, USB cable, video connect cable, AC adaptor (100-240Vac,

50/60Hz, adapters for US, UK, EU, AUS), magnetic mount for monitor, and hard case. BR200

and BR250 also include hook, mirror, and magnet attachment accessories

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

4BR200-BR250-KITS_en-GB_v9.1 3/20

Description

1 Monitor mount (signal output)

2 Camera controller power indicator

3 Camera controller power ON/OFF switch and LED dimmer

4 Flexible cable

5 Camera head and LEDs

6 OK button

7 Up arrow and video/image button

8 Menu button

9 Down arrow button

10 Monitor power ON/OFF button

11 Monitor power indicator

12 USB jack for PC connection

13 Video output jack for alternate monitor

14 SD card slot

15 AC power adaptor jack

16 Reset button

17 Monitor mount (input signal)

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

5BR200-BR250-KITS_en-GB_v9.1 3/20

Preparation for use

Camera controller power

Insert t (supplied) into the battery carrier located in the camera

handle as illustrated in accompanying diagrams. Observe correct polarity when

installing batteries.

Never dispose of used batteries or rechargeable batteries in household waste. As consumers, users are legally

required to take used batteries to appropriate collection sites, the retail store where the batteries were

purchased, or wherever batteries are sold.

Disposal: Do not dispose of this instrument in household waste. The user is obligated to take end-of-life devices

to a designated collection point for the disposal of electrical and electronic equipment.

Monitor power

The monitor uses a rechargeable battery. To charge the battery, plug the supplied AC adaptor

into an AC power source and then connect the other end of the adaptor cable to the power jack

on the monitor. The battery capacity icon on the monitor screen and the red LED power

indicator on the side of the monitor will blink while the battery is charging.

Connect the flexible cable to the camera controller

Align the flexible cable with the camera controller, noting the keyed pairing; and then tighten the

knurled collar to hold the connection firmly in place.

Warning: Damage to the flexible cable can occur if it is forcibly bent into too narrow a radius.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

6BR200-BR250-KITS_en-GB_v9.1 3/20

Inserting the micro SD card

Insert card with arrow pointing toward slot. Gently apply

pressure until the card locks into the spring loaded slot. To

remove, gently push the card inward and then release to eject it

from the card slot. Please use a Class 6 or better TF Flash

memory card.

Attaching the monitor to the camera controller

Insert the monitor plug into the jack at the back of the camera

controller and slide the monitor downward to lock it into position.

See accompanying diagram.

Remotely mounting the monitor

The supplied magnetic bracket slides onto the rear of the monitor. Mount the monitor on a

magnetic surface for convenient remote viewing. See diagrams below. The wireless feature of

this system allows you to place the monitor up to 10m (33 ft.) from the measurement location.

Operation

1. Turn the ON/OFF dial switch on the cameral controller to power the camera. The power

indicator on the controller will switch on. The ON/OFF switch then acts as a dimmer for the

LEDs on the camera head.

2. Press and hold the monitor power button for at least 2 seconds to power the monitor; the

power indicator will illuminate and a Welcome screen will appear on the monitor.

3. Remove the protective cap from the camera lens and store it safely in the carry case.

4. The real-time image will then appear on the display LCD monitor.

Note: If the picture does not properly synchronize or has poor color, check that the

NTSC/PAL setting is correct. See the Settings Menu section.

5. Use the up arrow button on the monitor to select video or still image mode.

6. Turn the dimmer dial on the camera controller to adjust the LED light intensity.

7. Bend the flexible cable into the desired position. The cable can be bent into the shape of

most examination areas, but please do not bend the cable excessively as this can cause

damage to the system.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

7BR200-BR250-KITS_en-GB_v9.1 3/20

8. Use the supplied accessories to help locate and retrieve small items (BR200 and BR250

only). Refer to the separate section in this manual for connecting the attachment

accessories.

Capturing still images

Use the up arrow button on the Monitor to select the Image mode, and then press OK to

capture a still image. The image will automatically save to the SD card.

Recording video

Use the up arrow button on the Monitor to select Video mode, and then press OK to begin

recording; refer to the following diagram for display icon descriptions:

1. Battery capacity

2. Function icon (video/image)

3. Recording in progress

4. ZOOM level

5. Date and Time

6. Recording time remaining

7. SD card status

Playback: Viewing images and video on the monitor

1. Press to display a list of playback folders sorted by date

2. Use the buttons to select a folder

3. Press OK to open the selected folder and view the list of

images and/or video files contained in the folder

4. Files are sorted by time of day; image files are in JPG format

and video files are in MP4 format

5. Use the buttons to select a file

6. Press OK to display the selected image or video.

For video files: Press OK to pause and resume

Fast Forwards the video; Rewinds the video

Press to stop video

7. Press to return to menu

8. Press again to exit

Note: Video automatically saves to a file on the SD card every 30 minutes. When the SD card is

Fimages or video can be recorded if the SD

card is not inserted in the slot or if the SD card has reached maximum capacity.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

8BR200-BR250-KITS_en-GB_v9.1 3/20

Delete a single video or image

1. Press to display the list of available file folders

2. Use the buttons to select a folder

3. Press OK to open the selected folder to see the list of image and/or video files

4. Use the buttons to select a file

5. Long press the button and DELETE CURRENT FILE?

6. Use the arrow buttons to select YES or NO

7. Press OK to confirm

8. Press twice to exit the Delete screen

Delete an empty file folder

To delete an empty folder, use the same instructions for deleting a single video or image.

Folders that are not emptied cannot be deleted. Delete the contents of a folder before

attempting to delete a folder. If you attempt to delete a folder that is not empty, the following

message will appear: FOLDER NOT EMPTY.

Using SD card to view and transfer images and video

There are two ways to use the SD card:

1. SD card adaptor: Insert the SD card into the SD adaptor and then insert the adaptor into

the PC SD card slot (if available)

2. USB adaptor: Insert the SD card into a USB adaptor and plug the adaptor into a USB port

on the PC

Once the PC recognizes the SD card, you can view the images and video that are stored on the

card using a PC multimedia player. In addition, you can transfer image and video files from the

SD card to the PC as you would with any external storage medium (memory stick, hard drive,

etc.).

Using a PC (USB connection) to transfer video and images

Connect the monitor to a PC using the supplied USB cable. When the PC recognizes the

connection, you can use the monitor as you would any external storage drive (moving

images and videos to and from the drive). If the PC does not recognize the monitor,

please contact our technical support staff.

Using an additional video monitor

If you wish to use an additional video monitor, connect the supplied video cable to the

VIDEO OUT jack on the Extech monitor and then connect the other end of the cable to the

VIDEO IN jack of the additional monitor. The Extech monitor will output a high quality

video image to the additional monitor.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

10 BR200-BR250-KITS_en-GB_v9.1 3/20

Settings Menu

Long press this button to enter the Settings Menu. Four icons will appear. The System

settings icon (green) is on the upper left, the Date/Time settings icon (yellow) is on the upper

right, the Recorder settings icon (red) is on the lower left, and the Playback* icon (blue) is on the

lower right. Use the arrow buttons to step through the icons and use the OK button to open

one of the setting modes. Short press to back out of menus as needed. Refer to the

instructions below for modifying the settings.

Language Settings

1. In the Settings Menu, use buttons to select the System setting (green icon)

2. Press OK to call up the System icon list

3. Use the arrows to highlight the Language icon (globe)

4. Press OK and the Language icon list will appear (flags)

5. Use the arrows to highlight the desired language

6. Press OK to select the highlighted language and exit

7. Press the button to return to the main Settings Menu or use the arrows to move to

another icon in the System settings menu

Video System Settings

1. In the Settings Menu, use buttons to select the System setting (green icon)

2. Press OK to call up the System icon list

3. Use the arrows to highlight the Video System icon (yellow)

4. Press OK and the Video format selections will appear (NTSC, PAL)

5. Use the arrows to highlight NTSC

6. Press OK to select the highlighted format and exit

7. Press the button to return to the main Settings Menu or use the arrows to move to

another icon in the System settings menu

Format/Erase SD Card Media

1. In the Settings Menu, use buttons to select the System setting (green icon)

2. Press OK to call up the System icon list

3. Use the arrows to highlight the FORMAT icon (blue)

4. Press OK and the FORMAT selection screen will appear (YES, NO)

5. Use the arrows to highlight YES (format/erase) or NO (leave unchanged)

6. Press OK to accept the selection and exit

7. Press the button to return to the main Settings Menu or use the arrows to move to

another icon in the System settings menu

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Andere Handbücher für BR200

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Extech Instruments Analytisches Instrument Handbücher

Extech Instruments

Extech Instruments HDV7C-A2-45-15 Bedienungsanleitung

Extech Instruments

Extech Instruments HDV7C-P28-30 Bedienungsanleitung

Extech Instruments

Extech Instruments HDV600 Bedienungsanleitung

Extech Instruments

Extech Instruments BR200 Bedienungsanleitung

Extech Instruments

Extech Instruments HDV-TX2L Abmessungen

Extech Instruments

Extech Instruments HDV-WTX1L Abmessungen

Extech Instruments

Extech Instruments BR80 Bedienungsanleitung

Extech Instruments

Extech Instruments PQ34-30 Bedienungsanleitung

Extech Instruments

Extech Instruments BR100 Bedienungsanleitung

Extech Instruments

Extech Instruments HDV-WTX2L Bedienungsanleitung

Extech Instruments

Extech Instruments BR300 Bedienungsanleitung

Extech Instruments

Extech Instruments BR70 Bedienungsanleitung

Extech Instruments

Extech Instruments HDV-WTX2L Abmessungen

Extech Instruments

Extech Instruments BR150 Bedienungsanleitung

Extech Instruments

Extech Instruments HDV-WTX1L Abmessungen

Extech Instruments

Extech Instruments HDV-TX1L Abmessungen

Extech Instruments

Extech Instruments HDV600 Bedienungsanleitung

Extech Instruments

Extech Instruments HDV-WTX2L Abmessungen

Extech Instruments

Extech Instruments CO210 Bedienungsanleitung

Extech Instruments

Extech Instruments HDV-WTX1L Abmessungen

Extech Instruments

Extech Instruments BR200 Bedienungsanleitung

Extech Instruments

Extech Instruments BR200 Bedienungsanleitung

Extech Instruments

Extech Instruments HDV WTX2L Abmessungen

Extech Instruments

Extech Instruments DT100 Bedienungsanleitung

Beliebte Analytisches Instrument Handbücher anderer Marken

Cocraft

Cocraft NLT04 Bedienungsanleitung

M&C

M&C GENTWO PMA1000 Bedienungsanleitung

MICRO-EPSILON

MICRO-EPSILON optoncdt 1700 Bedienungsanleitung

CONDTROL

CONDTROL XP4 PRO Bedienungsanleitung

Dewetron

Dewetron DEWE-30-16 Produkthandbuch

EXTOL PREMIUM

EXTOL PREMIUM 8820043 Montage- und Bedienungsanleitung

RIDGID

RIDGID SeeSnake Compact Bedienungsanleitung

Teledyne

Teledyne 3000PA Bedienungsanleitung

YDLIDAR

YDLIDAR TIA Bedienungsanleitung

Olympus

Olympus IPLEX FX Series Bedienungsanleitung

Bosch

Bosch GLM 50 C Professional Bedienungsanleitung

Reflecta

Reflecta DigiEndoscope Bedienungsanleitung

Chinavision

Chinavision CVACZ-G696 Montageanleitung

Fuji Electric

Fuji Electric ZKMA Bedienungsanleitung

Teledyne

Teledyne 3300TA Bedienungsanleitung

VOLTCRAFT

VOLTCRAFT IC-100HD Bedienungsanleitung

RIDGID

RIDGID micro CA-25 Bedienungsanleitung

Würth

Würth MASTERVISION MINI REC Bedienungsanleitung
