User’s Manual

1200A 3-Phase Power Analyzer/Datalogger

MODEL 382100

Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com (603) 746-5524

382100-EU-EN v2.2 07/13

Table of Contents

1.0 INTRODUCTION

1-1 Features.................................................................................................. 3

1-2 Safety...................................................................................................... .4

2.0 SPECIFICATIONS

2-1 General Specifications ................................................................................ .5

2-2 Electrical Specifications ....................................................................................5

3.0 METER DESCRIPTION

.................................................................................9

4.0 MEASUREMENT PREPARATION

4-1 The original screen...................................................................................................... .10

4-2 Entering the measurement Screen..................................................................... 10

4-3 Keypad Description Summary ........................................................................... .10

4-4 SETUP Key .................................................................................................................. .11

4-5 Meter Setup Functions (SD Card, PT/CT, Audible Beeper, Decimal Point, Clamp

Type, RS-232, Time/Date, Reset Key) ................................................................ .12

5.0 MEASUREMENT PROCEDURES

5-1 1Φ2W (single phase two wires) measurement ........................................ .25

5-2 1Φ3W (single phase three wires) measurement...................................... .26

5-3 3Φ3W (three phase three wires) measurement ....................................... .27

5-4 3Φ4W (three phase four wires) measurement ......................................... .28

5-5 CT and PT measurement .......................................................................................... .29

5-6 Data Logger ....................................................................................................................... 30

5-7 Data Hold.........................................................................................................31

5-8 Display Backlight key......................................................................................32

5-9 A (Current) Range key ............................................................................................... .33

5-10 LOWBAT (Low Battery) screen ...................................................................34

5-11 Appendix - Measurement Definitions.............................................................. .35

6.0 MAINTENANCE

6-1 Cleaning ................................................................................................................ .35

6-2 Battery Replacement........................................................................................... .35

7.0 PC INTERFACE

7-1 RS-232 Protocol ............................................................................. .36

7-2 Download Data from SD Card ......................................................... 37

Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com (603) 746-5524

382100-EU-EN v2.2 07/13

1.0 Introduction

Congratulations on your purchase of the Model 382100 Power Analyzer. This instrument is fully

tested and calibrated prior to delivery; proper use and care of this meter will provide years of reliable

service.

1.1 Features

Large dot-matrix, numerical, backlit LCD

Full system analysis with up to 35 parameters:

- V (phase-to-phase), V (phase-to-ground)

- A (phase-to-ground)

- KW / KVA / KVAR / PF (phase)

- KW / KVA / KVAR / PF (system)

- KWH / KVAH / KVARH / PFH (system)

- Phase angle

High accuracy Auto-ranging current clamps (0.2A to 1200.0A)

600.0VAC input with CAT III-600V safety rating

Adjustable Current Transformer (CT) and Voltage Transformer (VT) ratio for high power

distribution systems

Log up to 60,000 reading on removable SD memory card in Excel® format

Wide sampling rate range (from 2 seconds up to 2 hours)

Captured measurements imported directly into Excel via the SD memory card

Easy-to-use onscreen menu

Easy-to-grab rugged over-molded housing

Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com (603) 746-5524

382100-EU-EN v2.2 07/13

1.2 Safety

CAUTION: Risk of electric shock. Do not attempt to open or disassemble the meter while

taking measurements

CAUTION: Do not attempt to measure Voltage or Current that exceeds specified limits

Remove the test leads from the meter before opening the battery compartment cover

When cleaning, use only a dry cloth to wipe the meter housing. Do not use liquids of any kind

to clean the meter

Safety Symbols:

CAUTION RISK OF ELECTRIC SHOCK

Environmental Conditions

Installation Category III 600V

Pollution Degree 2

Altitude limit: 2000m

Indoor use only

Relative Humidity maximum: 80%

Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com (603) 746-5524

382100-EU-EN v2.2 07/13

2.0 Specifications

2.1 General Specifications

Circuit

Custom one-chip microprocessor LSI circuit

Display

LCD Size: 81.4 X 61 mm (3.2 X 2.4”)

Dot Matrix backlit LCD (320 X 240 pixels)

Measurements

ACV / A C A / AC Watts (True Power)

AC Watts (Apparent Power)

AC Watts (Reactive Power)

Power factor

Phase angle

Frequency

Wire connections

1P/2W, 1P/3W, 3P/3W, 3P/4W.

Voltage ranges

10 ACV to 600 ACV (Auto Range)

Current ranges

0.2 ACA to 1200 ACA (Auto / Manual Range)

Safety standard

IEC1010 CAT III 600 V

ACV input impedance

10M ohms

Range select

ACV

Auto Range

ACA

Auto / Manual Range

Clamp frequency

response

40 Hz to 1 KHz

Tested frequency

45 to 65 Hz

Over load protection

ACV

720 ACV RMS

ACA

1300 ACA with clamp probe

Over-range indicator

"OL"

Under-range indicator

"UR"

Data Hold

Freezes displayed reading

Data Recording

SD memory card

Sampling Time

Approx. 1 second

Datalogger

Real time data logger saves data to SD memory card for download to

PC (data file opens directly to spreadsheet)

Sampling rate: 2 seconds to 7200 seconds

Data Output

Serial or USB connection (cable supplied)

Operating Temp.

0 to 50

C (0 to 122

)

Operating R.H.

80% Relative Humidity max.

Power Supply

Eight (8) ‘AA’ 1.5VDC batteries or AC - DC 9V power adapter

Power Consumption

Meter: 300 mA DC; Clamp: 20 mA DC

Max. Conductor size

Clamp can accommodate up to 86 mm (3.4” ) diameter

Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com (603) 746-5524

382100-EU-EN v2.2 07/13

Weight Meter: 1049g (2.3 lbs.) (with batteries); Clamp: 522g (1.2 lbs)

Dimensions Meter: 225 X 125 X 64 mm (8.86 X 4.92 X 2.52“)

Clamp: 210 X 64 X 33mm (8.3 X 2.5 X 1.3”)

Clamp Jaw: 86 mm (3.4”)

Accessories Included Instruction manual

Test Leads: 1 Set (4 pieces)

Alligator clips: 1 Set (4 pieces)

Clamp Probe (3)

AC to DC 9V adapter

SD card (2G)

Carrying case

2.1 Electrical Specifications

ACV

Range Resolution Accuracy

10.0V to 600.0V

Phase to neutral line

0.1V ± (0.5%+0.5V)

10.0V to 600.0V

Phase to phase

ACA

Range Resolution Accuracy

20A 0.001A/0.01A ± (0.5%+0.1A)

200A 0.01A/0.1A ± (0.5%+0.5A)

1200A 0.1A/1A ±(0.5%+5A)

Power Factor

Range Resolution Accuracy

0.00 to 1.00 0.01 ± 0.04

PFH (Power Factor Hours): Long Term Power Factor

For three phase/four wire and three phase/three wire configurations:

PF = (PF1 + PF2 + PF3) / 3

For single phase three wire configurations:

PF = (PF1 + PF2) / 2

Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com (603) 746-5524

382100-EU-EN v2.2 07/13

Phase Angle

Range Resolution Accuracy

-180° to 180° 0.1° ± 1°

Frequency

Range Resolution Accuracy

45 to 65 Hz 0.1 Hz 0.1 Hz

Active (Real) Power

Range Resolution Accuracy

0.000 to 9.999 KW 0.001 KW ± (1%+0.008KW)

10.00 to 99.99 KW 0.01 KW ± (1%+0.08KW)

100.0 to 999.9 KW 0.1 KW ± (1%+0.8KW)

0.000 to 9.999 MW 0.001 MW ± (1%+0.008MW)

Apparent Power

Range Resolution Accuracy

0.000 to 9.999 KVA 0.001 KVA ± (1%+0.008KVA)

10.00 to 99.99 KVA 0.01 KVA ± (1%+0.08KVA)

100.0 to 999.9 KVA 0.1 KVA ± (1%+0.8KVA)

0.000 to 9.999 MVA 0.001 MVA ± (1%+0.008MVA)

Reactive Power

Range Resolution Accuracy

0.000 to 9.999 KVAR 0.001 KVAR ± (1%+0.008 KVAR)

10.00 to 99.99 KVAR 0.01 KVAR ± (1%+0.08 KVAR)

100.0 to 999.9 KVAR 0.1 KVAR ± (1%+0.8 KVAR)

0.000 to 9.999 MVAR 0.001 MVAR ± (1%+0.008 MVAR)

Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com (603) 746-5524

382100-EU-EN v2.2 07/13

Watt Hour (Active Power Hour): WH

Range Resolution Accuracy

0.000 to 9.999 KWH 0.001 KWH ± (2%+0.008 KWH)

10.00 to 99.99 KWH 0.01 KWH ± (2%+0.08 KWH)

100.0 to 999.9 KWH 0.1 KWH ± (2%+0.8 KWH)

0.000 to 9.999 MWHR 0.001 MWH ± (2%+0.008 MWH)

VA Hour (Apparent Power Hour): SH

Range Resolution Accuracy

0.000 to 9.999 KVAH 0.001 KVAH ± (2%+0.008 KVAH)

10.00 to 99.99 KVAH 0.01 KVAH ± (2%+0.08 KVAH)

100.0 to 999.9 KVAH 0.1 KVAH ± (2%+0.8 KVAH)

0.000 to 9.999 MVAH 0.001 MVAH ± (2%+0.008 MVAH)

VAR (Reactive Power Hour): QH

Range Resolution

Accuracy

0.000 to 9.999 KVARH 0.001 KVARH ± (2%+0.008 KVARH)

10.00 to 99.99 KVARH 0.01 KVARH ± (2%+0.08 KVARH)

100.0 to 999.9 KVARH 0.1 KVARH ± (2%+0.8 KVARH)

0.000 to 9.999 MVARH 0.001 MVARH ± (2%+0.008 MVARH)

Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com (603) 746-5524

382100-EU-EN v2.2 07/13

3.0 Meter Description

3-1 Display

3-2 Phase/Wire button

3-3

▲

button

3-4

▼

button

3-5 Hold button

3-6 Backlight button

3-7 Power button

3-8 Exit button

3-9 REC button

3-10 Amp range button

3-11 Shift button

3-12 Setup button

3-13 Volt input terminals

3-14 Probe input sockets

3-15 SD card socket

3-16 RS232 socket

3-17 Reset button

3-18 9V adapter socket

3-19 Battery compartment

3-20 Stand

3-21 Current Sense Jaw

3-22 Trigger

3-23 Plug for current probe

Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com (603) 746-5524

382100-EU-EN v2.2 07/13

4.0 Measurement Preparation

4-1 Opening Screen

1. When the meter is powered up the initialization screen appears asking the user to “please wait”.

2. The meter will also check for an inserted SD memory card. ‘SD check’ will appear on the screen.

If an SD card is inserted, the blinking display will switch off after several seconds. When no card

is inserted the display will show ‘No disk’.

4-2 Main Screen

The main screen displays all of the power measurement data.

Figure 4-2: Main Screen

4.3 Keypad layout

1. POWER KEY (3-7, Fig. 1): Press to turn the instrument ON/OFF

2. 1Φ3Φ(phase/wire) KEY (3-2, Fig. 1): Press to select (1P/2W, 1P/3W, 3P/3W, 3P/4W)

measurement function

3. A (current) RANGE KEY (3-10, Fig. 1): Press to change from AUTO RANGE to MANUAL

RANGE mode for current

4. REC KEY (3-9, Fig. 1): The data record key for the SD Memory Card

5. HOLD KEY (3-5, Fig. 1): Press to freeze the displayed reading

6. BACKLIGHT KEY (3-6, Fig. 1): Press to switch LCD backlight ON/OFF

7. SETUP KEY (3-12, Fig. 1): Press to setup a function before measuring

8. EXIT KEY (3-8, Fig. 1): Press to exit the set-up screen

9. SHIFT KEY (3-11, Fig. 1): Used for programming the functions on the set-up screen

10. UP (▲) KEY (3-3, Fig. 1): Press to move the cursor up

11. DOWN (▼) KEY (3-4, Fig. 1): Press to move the cursor down

Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com (603) 746-5524

Andere Handbücher für 382100

Inhaltsverzeichnis

Andere Extech Instruments Multimeter Handbücher

Extech Instruments

Extech Instruments EX710 Bedienungsanleitung

Extech Instruments

Extech Instruments EX310 Bedienungsanleitung

Extech Instruments

Extech Instruments MN16A Bedienungsanleitung

Extech Instruments

Extech Instruments EX520-S Bedienungsanleitung

Extech Instruments

Extech Instruments EX310 Bedienungsanleitung

Extech Instruments

Extech Instruments 410 Bedienungsanleitung

Extech Instruments

Extech Instruments 407227 Bedienungsanleitung

Extech Instruments

Extech Instruments 380946 Bedienungsanleitung

Extech Instruments

Extech Instruments EX420-NIST Bedienungsanleitung

Extech Instruments

Extech Instruments EX350 Bedienungsanleitung

Extech Instruments

Extech Instruments MiniTec Series Bedienungsanleitung

Extech Instruments

Extech Instruments SDL900 Bedienungsanleitung

Extech Instruments

Extech Instruments DM220 Bedienungsanleitung

Extech Instruments

Extech Instruments EX530 Bedienungsanleitung

Extech Instruments

Extech Instruments 412355A Oyster Series Bedienungsanleitung

Extech Instruments

Extech Instruments 407303 Bedienungsanleitung

Extech Instruments

Extech Instruments 420 Bedienungsanleitung

Extech Instruments

Extech Instruments MultiTec MT310 Bedienungsanleitung

Extech Instruments

Extech Instruments MN26 Bedienungsanleitung

Extech Instruments

Extech Instruments MultiMaster MM560A Bedienungsanleitung

Extech Instruments

Extech Instruments MN47 Bedienungsanleitung

Extech Instruments

Extech Instruments 45170CM Bedienungsanleitung

Extech Instruments

Extech Instruments Extech 470 Bedienungsanleitung

Extech Instruments

Extech Instruments EX410 Bedienungsanleitung

Beliebte Multimeter Handbücher anderer Marken

Agilent Technologies

Agilent Technologies 34420A Bedienungsanleitung

Fluke

Fluke 83 Bedienungsanleitung

Hameg

Hameg HM 8012 Bedienungsanleitung

Mastech

Mastech MY70 Bedienungsanleitung

Steren

Steren MUL-300 Bedienungsanleitung

Somogyi Elektronic

Somogyi Elektronic home SMA 92 Bedienungsanleitung

Gossen MetraWatt

Gossen MetraWatt METRAmax 6 Bedienungsanleitung

PeakTech

PeakTech 4000 Gebrauchs- und Pflegehandbuch

YOKOGAWA

YOKOGAWA 90050B Bedienungsanleitung

Gossen MetraWatt

Gossen MetraWatt METRALINE DMM16 Bedienungsanleitung

Fluke

Fluke 8846A Bedienungs- und Wartungshandbuch

Tempo Communications

Tempo Communications MM200 Bedienungsanleitung

Elenco Electronics

Elenco Electronics CM-1555 Bedienungsanleitung

Mastech

Mastech MS8238C Bedienungsanleitung

SDAR

SDAR 830A, 830B, 830D, 830C Bedienungsanleitung

RS PRO

RS PRO RS-9519BT Bedienungsanleitung

BGS technic

BGS technic 8890 Bedienungsanleitung

Amprobe

Amprobe Hexagon 60 Bedienungsanleitung
