Specifications — SVDA 6 A MX Distribution Amplifier

Video

Gain ................................................ Unity

Bandwidth ..................................... 30 MHz (-3 dB)

Frequency response .................... < ± 0.1 dB @ 15 MHz

Differential phase error .............. 0.03° at 3.58 MHz and 4.43 MHz

Differential gain error ................. 0.05% at 3.58 MHz and 4.43 MHz

Crosstalk ....................................... -60 dB @ 3.58 MHz

Video input

Number/signal type ................... 1 S-video

Connectors ................................... (1) 4-pin mini DIN female

Nominal level ............................... 1 Vp-p for Y of S-video

0.3 Vp-p for C of S-video

Minimum/maximum levels ....... Analog: 0.4 V to 1.4 Vp-p with no offset at unity gain

Impedance .................................... 75 ohms

Return loss .................................... <-30 dB @ 5 MHz

Video output

Number/signal type ................... 6 S-video

Connectors ................................... (6) 4-pin mini DIN

Nominal level ............................... 1 Vp-p for Y of S-video

0.3 Vp-p for C of S-video

Minimum/maximum levels ....... 0.4 V to 1.4 Vp-p

Impedance ....................................

Return loss ....................................

DC offset .......................................

Sync

Standards ......................................

Audio

Gain ................................................

Frequency response ....................

THD + Noise .................................

75 ohms

<-30 dB @ 5 MHz

±5 mV with input at 0 offset

NTSC 3.58, NTSC 4.43, PAL, SECAM

Unbalanced output: 0 dB; balanced output: +6 dB

20 Hz to 20 kHz, ±0.05 dB

0.03% @ 1 kHz at nominal level

S/N ................................................ >90 dB, output 21 dB, balanced, at maximum output (unweighted)

Stereo channel separation .......... >80 dB @ 1 kHz; >60 dB @ 20 kHz

CMRR ............................................ >75 dB @ 20 Hz to 20 kHz

Audio input

Number/signal type ................... 1, 2, or 4 stereo balanced (Hi Z or 600 ohms), unbalanced (Hi Z)

Connectors ................................... (1, 2, or 4) 3.5 mm captive screw connector, 5 pole

Impedance .................................... >25k ohms balanced, 50k ohms unbalanced, DC coupled

Maximum level ............................ +24 dBu (balanced or unbalanced) at 1%THD+N

0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV 2 dBu

Audio output

Number/signal type ................... 6, 12, or 24 stereo, balanced/unbalanced

Connectors ...................................

Impedance ....................................

Gain error .....................................

Maximum level (Hi-Z) ................

Maximum level (600 ohm) .........

(6, 12, or 24) 3.5 mm captive screw connector, 5 pole

50 ohms unbalanced, 100 ohms balanced

±0.1 dB channel to channel

>+24 dBu, balanced or unbalanced at 1%THD+N

>+15 dBm, balanced or unbalanced at 1%THD+N

1-2 SVDA 6 A MX Distribution Amplifier • Specifications

General

Power ............................................ 100 VAC to 240 VAC, 50/60 Hz, 10 watts, internal, autoswitchable

Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Rack mount .................................. Yes, with optional 1U rack shelf, part #60-190-01 or 60-604-01

Enclosure type .............................. Metal

Enclosure dimensions ................. 1.75" H x 8.7" W x 9.4" D (1U high, half rack wide)

4.4 cm H x 22.1 cm W x 23.9 cm D

(Depth excludes connectors.)

Product weight ............................. 2.5 lbs (1.1 kg)

Shipping weight ........................... 5 lbs (3 kg)

Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)

Listings .......................................... UL, CUL

Compliances ................................. CE, FCC Class A

MTBF ............................................. 30,000 hours

Warranty ....................................... 3 years parts and labor

All nominal levels are at ±10%.

Specificationsaresubjecttochangewithoutnotice.

(7.51-081904-D3)

SVDA 6 A MX Distribution Amplifier • Specifications 1-3
