APPLICATION NOTE AN # 352002

Industrial Plasma Display Panels – Introduction to the Extron IPL M PDP-ES Card

Pioneer Electronics (USA) Inc. (310) 952-2000 Released: 22 Dec 2006

OVERVIEW:

Extron is leading manufacturer of professional A/V system products for video signal manipulation,

Ethernet control interfaces, and high resolution connectors. Along with other add-on products, Extron

developed the IPL M PDP-ES expansion card that is an IP Link®Interface module for Pioneer’s

industrial (CMX series) plasma display monitor panels. This card, a compact Ethernet controller

featuring an integral Web server that enables remote, proactive monitoring, control and

troubleshooting, is certified by Pioneer for use in 5th generation or later industrial (CMX Series)

panels.

The type of businesses currently employing Pioneer industrial panels with the Extron IPL M PDP-ES

card are as follows:

•Digital Signage

•Military & Government Facilities

•Businesses that share office resources

•Small Colleges & Trade Schools

•Large Universities & Corporate Facilities

TECHNICAL DETAILS:

This compact Ethernet control card enables IP based remote control, proactive monitoring, and

troubleshooting for the plasma display. In addition to an RJ-45 Ethernet connector, the IPL M PDP-

ES features a 9-pin D-sub serial port that can be configured to pass through Pioneer command codes

from an external control system.

The card includes an Integral WEB server with 1.25 MB of flash memory for storing the Global Viewer

(Extron’s intuitive Microsoft Windows® based configuration and management utility) and any user-

customized web pages. GlobalViewer provides a range of A/V asset management functions including

scheduled events such as power ON/OFF, proactive maintenance alerts, remote tech support, and

theft alerts via e-mail. This application extends the asset management functionality of the IPL M PDP-

ES to allow status information for multiple Pioneer plasmas to appear directly in a single

GlobalViewer screen along with the data for other IP Link-enabled products.

There are multiple levels of security with password protection: User access level authorizes limited

entry to only pre-designated functions while administrator access level permits full access to

advanced settings.

Home & Business Group of America (800) 872-4159 Page 1of 2

AN #352002

Pioneer Electronics (USA) Inc. (310) 952-2000 Released: 22 Dec 2006

Home & Business Group of America (800) 872-4159 Page 2of 2

The Extron IPL M PDP-ES card for Pioneer industrial plasma panels provides the following support:

•10/100Base-T, half/full duplex with auto detect

•Preloaded control and scheduling Web pages

•Bi-directional serial port with pass-through

•Supports industry standard Ethernet protocols

•Integral high performance Web server

•Simultaneous multi-user support

•Multiple levels of access with password protection

ADDITIONAL INFORMATION:

For more information on the Extron IPL M PDP-ES expansion card, please contact.

Extron (http://www.extron.com/)

(714) 491-1500

For questions not answered here or for other information about the plasma panels, refer to the

Pioneer Electronics website (www.pioneerelectronics.com). For assistance please contact your

Pioneer representative or Pioneer Service at (800) 872-4159 or via email

[email protected]
