Extron electronics MTP 15HD A Series Bedienungsanleitung

User Guide

MTP 15HD A Series

Twisted Pair

High Resolution Video and Serial Link

MTP Transmitters and Receivers

68-2206-01 Rev. B

03 13

Safety Instructions • English

WARNING:This symbol, , when used on the product, is intended to

alert the user of the presence of uninsulated dangerous voltage within

the product’s enclosure that may present a risk of electric shock.

ATTENTION: This symbol, , when used on the product, is intended

to alert the user of important operating and maintenance (servicing)

instructions in the literature provided with the equipment.

For information on safety guidelines, regulatory compliances, EMI/EMF

compatibility, accessibility, and related topics, see the Extron Safety and

Regulatory Compliance Guide, part number 68-290-01, on the Extron

website, www.extron.com.

Instructions de sécurité • Français

AVERTISSEMENT: Ce pictogramme, , lorsqu’il est utilisé sur

le produit, signale à l’utilisateur la présence à l’intérieur du boîtier

du produit d’une tension électrique dangereuse susceptible de

provoquer un choc électrique.

ATTENTION: Ce pictogramme, , lorsqu’il est utilisé sur le produit,

signale à l’utilisateur des instructions d’utilisation ou de maintenance

importantes qui se trouvent dans la documentation fournie avec le

matériel.

Pour en savoir plus sur les règles de sécurité, la conformité à la

réglementation, la compatibilité EMI/EMF, l’accessibilité, et autres sujets

connexes, lisez les informations de sécurité et de conformité Extron, réf. 68-

290-01, sur le site Extron, www.extron.fr.

Sicherheitsanweisungen • Deutsch

WARNUNG: Dieses Symbol auf dem Produkt soll den Benutzer

darauf aufmerksam machen, dass im Inneren des Gehäuses dieses

Produktes gefährliche Spannungen herrschen, die nicht isoliert sind

und die einen elektrischen Schlag verursachen können.

VORSICHT: Dieses Symbol auf dem Produkt soll dem Benutzer in

der im Lieferumfang enthaltenen Dokumentation besonders wichtige

Hinweise zur Bedienung und Wartung (Instandhaltung) geben.

Weitere Informationen über die Sicherheitsrichtlinien, Produkthandhabung,

EMI/EMF-Kompatibilität, Zugänglichkeit und verwandte Themen finden Sie in

den Extron-Richtlinien für Sicherheit und Handhabung (Artikelnummer

68-290-01) auf der Extron-Website, www.extron.de.

Instrucciones de seguridad • Español

ADVERTENCIA: Este símbolo, , cuando se utiliza en el producto,

avisa al usuario de la presencia de voltaje peligroso sin aislar dentro

del producto, lo que puede representar un riesgo de descarga

eléctrica.

ATENCIÓN: Este símbolo, , cuando se utiliza en el producto, avisa

al usuario de la presencia de importantes instrucciones de uso y

mantenimiento recogidas en la documentación proporcionada con

el equipo.

Para obtener información sobre directrices de seguridad, cumplimiento

de normativas, compatibilidad electromagnética, accesibilidad y temas

relacionados, consulte la Guía de cumplimiento de normativas y seguridad

de Extron, referencia 68-290-01, en el sitio Web de Extron, www.extron.es.

Chinese Simplified（简体中文）

警告：产品上的这个标志意在警告用户该产品机壳内有暴露的危险

电压，有触电危险。

注意：产品上的这个标志意在提示用户设备随附的用户手册中有

重要的操作和维护(维修）说明。

关于我们产品的安全指南、遵循的规范、EMI/EMF 的兼容性、无障碍

使用的特性等相关内容，敬请访问 Extron 网站 www.extron.cn，参见 Extron

安全规范指南，产品编号 68-290-01。

Chinese Traditional（繁體中文）

警告: 若產品上使用此符號，是為了提醒使用者，產品機殼內存在著

可能會導致觸電之風險的未絕緣危險電壓。

注意 若產品上使用此符號，是為了提醒使用者。

有關安全性指導方針、法規遵守、EMI/EMF 相容性、存取範圍和相關主題的詳細

資訊，請瀏覽 Extron 網站：www.extron.cn，然後參閱《Extron 安全性與法規遵

守手冊》，準則編號 68-290-01。

Japanese

警告:この記号が製品上に表示されている場合は、筐体内に絶縁されて

いない高電圧が流れ、感電の危険があることを示しています。

注意:この記号が製品上に表示されている場合は、本機の取扱説明書に

記載されている重要な操作と保守(整備)の指示についてユーザーの

  注意を喚起するものです。

安全上のご注意、法規厳守、EMI/EMF適合性、その他の関連項目に

ついては、エクストロンのウェブサイト www.extron.jpより

『Extron Safety and Regulatory Compliance Guide』 (P/N 68-290-01) をご覧ください。

Korean

경고: 이 기호 , 가 제품에 사용될 경우, 제품의 인클로저 내에 있는

접지되지 않은 위험한 전류로 인해 사용자가 감전될 위험이 있음을

경고합니다.

주의: 이 기호 , 가 제품에 사용될 경우, 장비와 함께 제공된 책자에 나와

있는 주요 운영 및 유지보수(정비) 지침을 경고합니다.

안전 가이드라인, 규제 준수, EMI/EMF 호환성, 접근성, 그리고 관련

항목에 대한 자세한 내용은 Extron 웹 사이트(www.extron.co.kr)의

Extron 안전 및 규제 준수 안내서, 68-290-01 조항을 참조하십시오.

Safety Instructions

iii

FCC Class A Notice

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part15 of the FCC rules. The ClassA limits provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and,

if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is

likely to cause interference; the user must correct the interference at his own expense.

NOTE: This unit was tested with shielded I/O cables on the peripheral devices.

Shielded cables must be used to ensure compliance with FCC emissions limits.

For more information on safety guidelines, regulatory compliances, EMI/EMF

compatibility, accessibility, and related topics, see the “Extron Safety and Regulatory

Compliance Guide” on the Extron website.

Trademarks

All trademarks mentioned in this guide are the properties of their respective owners.

The following registered trademarks(R), registered service marks(SM), and trademarks(TM) are the property of

RGBSystems, Inc. or Extron Electronics:

Registered Trademarks (®)

AVTrac, Cable Cubby, CrossPoint, eBUS, EDID Manager, EDID Minder, Extron, Flat Field,GlobalViewer, Hideaway, Inline, IP Intercom, IP Link,

Key Minder, LockIt, MediaLink, PoleVault, PowerCage, PURE3, Quantum, SoundField, System Integrator, TouchLink, V-Lock, VersaTools,

VN-Matrix, VoiceLift, WallVault, WindoWall

Registered Service Mark (SM) : S3 Service Support Solutions

Trademarks (™)

AAP, AFL (Accu-Rate Frame Lock), ADSP (Advanced Digital Sync Processing), AIS (Advanced Instruction Set), Auto-Image, CDRS (Class D

Ripple Suppression), DDSP (Digital Display Sync Processing), DMI (Dynamic Motion Interpolation), Driver Configurator, DSP Configurator, DSVP

(Digital Sync Validation Processing), FastBite, FOXBOX, IP Intercom HelpDesk, MAAP, MicroDigital, ProDSP, QS-FPC (QuickSwitch Front Panel

Controller), Scope-Trigger, SIS, Simple Instruction Set, Skew-Free, SpeedMount, SpeedNav, SpeedSwitch, Triple-Action Switching, XTP, XTP

Systems, XTRA, ZipCaddy, ZipClip

Conventions Used in this Guide

Notiﬁcations

The following notiﬁcations are used in this guide:

WARNING: A warning indicates a situation that has the potential to result in death or

severe injury.

ATTENTION: Attention indicates a situation that may damage or destroy the product or

associated equipment.

NOTE: A note draws attention to important information.

Speciﬁcations Availability

Product speciﬁcations are available on the Extron website, www.extron.com.

Contents

Introduction ............................................ 1

About this Guide.............................................. 1

About the MTP Transmitters and Receivers ..... 2

Twisted Pair Cable Advantages.................... 2

Transmission Distance..................................... 3

Installation

and Operation......................................... 5

Installation Overview........................................ 5

Front Panel Features........................................ 6

Transmitter Rear Panel Features ...................... 9

Receiver Rear Panel Features........................ 11

Power Supply Wiring and Grounding ............. 12

Twisted Pair Cable Termination ...................... 14

Skew Delay Compensation............................ 15

SEQ Receiver Skew Compensation........... 15

Non-SEQ Receiver Skew Compensation ... 15

EDID Conﬁguration........................................ 16

Recording a Display EDID.......................... 16

Using a Pre-Programmed or

User-Recorded EDID ................................ 16

Reference Information.......................... 17

Part Numbers, Optional Accessories,

Cables, and Connectors............................... 17

Part Numbers............................................ 17

Optional Accessories................................. 17

Cables....................................................... 18

Connectors................................................ 18

Mounting............................................... 19

Tabletop Placement....................................... 19

Under Desk and Furniture Mounting .............. 19

Rack Mounting.............................................. 19

UL Guidelines for Rack Mounting............... 19

Rack Mounting Procedure ......................... 20

Back of the Rack Mounting Procedure ...... 20

Projector Mounting........................................ 20

MTP 15HD A Series • Contents v

Introduction

This section gives an overview of the user guide. This section also describes the

MTP 15HD A Series of transmitters and receivers. Covered topics are:

•About this Guide

•About the MTP Transmitters and Receivers

•Transmission Distance

About this Guide

This guide contains installation, conﬁguration, and operation information for two families of

Extron MTP transmitters and receivers.

•MTP products that are compatible with:

••Extron Enhanced Skew-Free™AV UTP cable

••Category (CAT) 5, 5e, and 6 shielded twisted pair (STP), unshielded twisted pair

(UTP), or foil shielded twisted pair (FTP) cable.

•MTP C7 [CAT 7, C7] products that are compatible with Shielded Twisted Pair 201

(STP201) or CAT 7 cable only.

In this guide, any reference to these products refers to either family, unless explicitly stated.

NOTE: For clarity and where applicable, in this guide, the CAT 5, 5e, 6 versions are

referred to as non-C7 MTPs.

This guide details the installation and operation of the following products:

•MTP T 15HD A twisted pair (TP) transmitter

•MTP RL 15HD A receiver with loop-through

•MTP RL 15HD A SEQ receiver with loop-through and skew equalization

In this guide:

•The term "transmitter" refers speciﬁcally to the MTP T 15HD A transmitter.

•The term "receiver" refers to either of the receiver models — the MTP RL 15HD A or

MTP RL 15HD A SEQ.

•The term "SEQ receiver" refers speciﬁcally to the MTP RL 15HD A SEQ receiver with

skew equalization capabilities.

MTP 15HD A Series • Introduction 1

About the MTP Transmitters and Receivers

The Extron MTP T 15HD A transmitter and MTP RL 15HD A and MTP RL 15HD A SEQ

receivers are a system for long-distance distribution of VGA or other high resolution video

and audio.

The MTPs are a part of the Extron compact line of basic distribution ampliﬁers, switchers,

transmitters and receivers, and associated video accessories.

High resolution video on a 15-pin HD connector as well as stereo audio on a 3.5 mm stereo

jack is sent to the MTP transmitter. The transmitter sums the left and right audio channels

to convert the audio to mono (L+R) format. The MTP T then converts the input video and

mono audio signals to proprietary signals and outputs them to the compatible MTP receiver

on an RJ-45 connector. A pre-peaking control allows you to boost the transmission distance

of the proprietary signal. The transmitter also makes the input video available for local use

on a 15-pin HD connector.

The transmitted proprietary signal is sent to the receiver on an RJ-45 connector and

converts the signal back into its high resolution video and mono audio components. The

receiver outputs the video on a 15-pin HD connector and the two sets of identical mono

audio signals on a single 3.5 mm captive screw connector (A series only; RS series outputs

on a RS-232 connection).

The receiver also buffers the proprietary input signal and sends it to another compatible

MTP receiver or to a daisy chain of receivers.

NOTES:

• The transmitter provides pre-peaking, which boosts the signal before it is

transmitted. The buffered output on the receiver does not provide any

pre-peaking control. The total recommended distance (see the table on page 4)

for an entire daisy chain is the same as for a single transmitter and receiver. The

Pre-Peak switch on the transmitter has the same effect on the recommended

transmission distance for a daisy chain as for a single transmitter and receiver.

• Up to eight receivers can be connected in series using Buffered Output connectors,

provided that the total distance from the twisted pair output of the transmitter to

the last receiver in the chain does not exceed the recommended distance for the

resolution being used.

The SEQ receiver also corrects the skew delay commonly encountered when CAT 5, 5e, 6,

7, or STP201 cables are used for RGB video, component video, and S-video transmission.

NOTE: An SEQ receiver should not be necessary when Extron Enhanced Skew-Free AV

UTP cable and non-C7 transmitters and receivers are used.

Each MTP transmitter and receiver model is shipped with an external desktop 12 V power

supply that accepts 100 VAC to 240 VAC, 50-60 Hz input.

Twisted Pair Cable Advantages

Twisted pair cable is smaller, lighter, more ﬂexible, and less expensive than coaxial cable.

Termination of the cable with RJ-45 connectors is simple, quick, and economical.

MTP 15HD A Series • Introduction 2

Transmission Distance

The maximum distance is determined by the frequency and resolution of the signal that

is input to the transmitter. The table on page 4 speciﬁes the recommended maximum

transmission distances and transmitter Pre-Peak switch positions (see ﬁgure 3, eon page

9) using Extron Enhanced Skew-Free AV UTP cable, STP201 cable, or CAT 5, 5e, 6, or 7

cable, terminated with RJ-45 connectors.

NOTES:

• The transmitter and receiver are designed for and perform best with

Extron Enhanced Skew-Free AV UTP cable terminated in accordance with the

TIA/EIA T 568 A wiring standard. CAT 5, 5e, and 6 cables are acceptable, but less

preferable. We also recommend the use of pre-terminated and tested cables. Cables

terminated on site should be tested before use to ensure that they comply with

Category 5 speciﬁcations.

• The recommendations shown in the table on page 4 apply for a single transmitter

and receiver and for a daisy chain. For example, the maximum suggested range for

1024 x 768 video is 300 feet (90 m) with the Pre-Peak switch off and 500 feet

(150 m) with the Pre-Peak switch on, whether the system consists of one transmitter

and one receiver or a transmitter and three daisy-chained receivers.

• Extron recommends using at least 25 feet of twisted pair cable between the

transmitter and the ﬁrst receiver.

• For daisy-chained units, the ﬁrst receiver in the chain must be at least

100 feet (30 m) from the transmitter when the Pre-Peak switch is on.

• For daisy-chained units, any receiver in the chain closer than 350 feet (105 m) may

experience some form of over-peaking when the Pre-Peak switch is on.

An over-peaked image may appear bloomed.

MTP 15HD A Series • Introduction 3

Video

Format

Pre-

Peak off

Pre-Peak

Max. distance

(high quality)

Max. distance

(variable quality)

Composite,

S-video,

Component

800'

(245 m)

1000'

(300 m)

640 x 480 <300'

(90 m)

>350'

(105 m)

700'

(215 m)

750'

(240 m)

800 x 600 <300'

(90 m)

>350'

(105 m)

550'

(165 m)

650'

(200 m)

1024 x 768* <300'

(90 m)

>350'

(105 m)

500'

(150 m)

600'

(185 m)

1280 x 960* <300'

(90 m)

>350'

(105 m)

400'

(120 m)

500'

(150 m)

1280 x 1024* <250'

(75 m)

>300'

(90 m)

350'

(105 m)

450'

(135 m)

1360 x 765 <250'

(75 m)

>300'

(90 m)

400'

(120 m)

500'

(150 m)

1365 x 768 <250'

(75 m)

>300'

(90 m)

400'

(120 m)

450'

(135 m)

1366 x 768 <250'

(75 m)

>300'

(90 m)

400'

(120 m)

450'

(135 m)

1400 x 1050 <250'

(75 m)

>300'

(90 m)

350'

(105 m)

400'

(120 m)

1440 x 900 <250'

(75 m)

>300'

(90 m)

350'

(105 m)

400'

(120 m)

1600 x 1200* <250'

(75 m)

>300'

(90 m)

300'

(90 m)

450'

(135 m)

1920 x 1200 <250'

(75 m)

>300'

(90 m)

300'

(90 m)

400'

(120 m)

2048 x 1080 <250'

(75 m)

>300'

(90 m)

300'

(90 m)

400'

(120 m)

HDTV 720p <250'

(75 m)

>300'

(90 m)

400'

(120 m)

500'

(150 m)

HDTV 1080i <250'

(75 m)

>300'

(90 m)

300'

(90 m)

400'

(120 m)

HDTV 1080p <250'

(75 m)

>300'

(90 m)

300'

(90 m)

400'

(120 m)

Figure 1. Recommended Pre-Peak Switch Positions and Transmission Distances

at 60 Hz

NOTES:

• Resolutions marked with an asterisk (*) in the table above have the same range

speciﬁcations at 75 Hz.

• It is possible to exceed the recommended distance; however, image quality may be

reduced.

MTP 15HD A Series • Introduction 4

Installation

and Operation

This section provides information on:

•Installation Overview

•Front Panel Features

•Transmitter Rear Panel Features

•Receiver Rear Panel Features

•Power Supply Wiring and Grounding

•Twisted Pair Cable Termination

•Skew Delay Compensation

•EDID Conﬁguration

Installation Overview

Follow the steps below to properly install and operate any of the Extron

MTP 15HD A transmitters and receivers.

ATTENTION: Potential damage to property.

Do not connect these devices to a computer data or telecommunications network.

1. Turn off all MTPs and devices. Make sure that the input sources, the MTP, and

the output sources are all turned off and all power sources and signal cables are

disconnected.

2. Connect the transmitter inputs (see Transmitter Rear Panel Features on page 9).

3. Connect twisted pair (TP) cables between the MTP units (see Transmitter Rear Panel

Features on page 9 and Receiver Rear Panel Features on page 11).

4. Connect the receiver outputs (see Receiver Rear Panel Features on page 11).

5. Conﬁgure the receiver DIP switches (see Receiver Rear Panel Features on page 11).

6. Conﬁgure the EDID (see Front Panel Features on page 6 and EDID Conﬁguration

on page 16)

7. Connect the power supply and turn on all devices (see Power Supply Wiring on

page 12).

8. Adjust the level and peaking (see Front Panel Features on page 6).

9. Adjust the skew delay control (see Front Panel Features on page 6).

10. If applicable, mount the MTPs (see Mounting on page 19).

MTP 15HD A Series • Installation and Operation 5

Andere Handbücher für MTP 15HD A Series

Inhaltsverzeichnis

Andere Extron electronics Empfänger Handbücher

Extron electronics

Extron electronics DTP DVI 230 Bedienungsanleitung

Extron electronics

Extron electronics MTP R 15HD RSA D Bedienungsanleitung

Extron electronics

Extron electronics MTP/HDMI U R Bedienungsanleitung

Extron electronics

Extron electronics MTP A/V Series Bedienungsanleitung

Extron electronics

Extron electronics XTP T HD 4K Bedienungsanleitung

Extron electronics

Extron electronics FOX 2G Tx AV Bedienungsanleitung

Extron electronics

Extron electronics Receivers TP Series Bedienungsanleitung

Extron electronics

Extron electronics VersaTools MTP T SV Bedienungsanleitung

Extron electronics

Extron electronics XTP SR HDMI Bedienungsanleitung

Extron electronics

Extron electronics XTP SFR HD 4K Bedienungsanleitung

Extron electronics

Extron electronics Fiber Optic Transmitter-Receiver Pair FOX 500 DVI... Bedienungsanleitung

Extron electronics

Extron electronics Twisted Pair Transmitter VTT001 Bedienungsanleitung

Extron electronics

Extron electronics TP Receiver Bedienungsanleitung

Extron electronics

Extron electronics XTP SFR HD 4K Bedienungsanleitung

Extron electronics

Extron electronics FOX3 SR 301 Bedienungsanleitung

Extron electronics

Extron electronics XTP SR HDMI Bedienungsanleitung

Extron electronics

Extron electronics XTP SR HDMI Bedienungsanleitung

Extron electronics

Extron electronics Fiber Optic Transmitters-Receivers FOX 2G Rx... Bedienungsanleitung

Extron electronics

Extron electronics MTP T AV Bedienungsanleitung

Extron electronics

Extron electronics IN1124 Bedienungsanleitung

Extron electronics

Extron electronics Dual Link DVI Transmitter and Receiver DVI DL 201... Bedienungsanleitung

Extron electronics

Extron electronics MTP C7 T 15HD RS Bedienungsanleitung

Extron electronics

Extron electronics MTP C7 T 15HD RS Bedienungsanleitung

Extron electronics

Extron electronics MTP R 15HD RSA D Bedienungsanleitung

Beliebte Empfänger Handbücher anderer Marken

Garmin

Garmin GA 23 Bedienungsanleitung

Aiphone

Aiphone PS-12F Bedienungsanleitung

IMES

IMES TCS-01CA-PMI Bedienungsanleitung

BWI Eagle

BWI Eagle AIR-EAGLE SR Handbuch

AMIMON

AMIMON AMN12310 WHDI Bedienungsanleitung

Dual

Dual DMCPA79BT Betriebsanleitung

Sound Associates

Sound Associates SA652P Bedienungsanleitung

Sherwood

Sherwood NewCastle R-772 Bedienungsanleitung

Audio

Audio A10-RX Series Bedienungsanleitung

AllSee

AllSee PushShare PSRV1.1 Bedienungsanleitung

DEMAG

DEMAG DRC-DR D2 Bedienungsanleitung

Teleco

Teleco TVRCL868A02 Bedienungsanleitung

Bosch

Bosch RF3222E Bedienungsanleitung

Kramer

Kramer 631R Bedienungsanleitung

Xpress

Xpress xmc10 Bedienungsanleitung

JVC

JVC KD-MR1BTS Bedienungsanleitung

Omega Engineering

Omega Engineering UWTC-REC3 Bedienungsanleitung

e-survey

e-survey E300 Pro Bedienungsanleitung
