1-2 MLS 306, MLS 506, MLS 506MA, MLS 506SA • Specifications

Specifications — MediaLink Switchers (MLS)

Video

Gain ............................................... Unity

Bandwidth

MLS 306 ............................. 280 MHz (-3dB), fully loaded

All other models .............. 350 MHz (-3dB), fully loaded

Frequency response..................... < ± 0.1dB @ 30 MHz

Differential phase error .............. 1.5º, 0 to 10 MHz

Differential gain error ................. 1.5%, 0 to 10 MHz

Crosstalk ....................................... -50dB @ 5 MHz

Video input

Number/signal type

MLS 306 ............................. 3 RGBHV, RGBS, RGsB, or RsGsBs

3 S-video, composite video

MLS 506 Series ................. 3 RGBHV, RGBS, RGsB, or RsGsBs

3 component video, S-video, or composite video

Connectors

MLS 306 ............................. 3 female 15-pin HD (RGB computer video)

3 female 4-pin mini-DIN (S-video)

3 female BNC (composite video)

MLS 506 Series ................. Female BNCs

Minimum/maximum levels ...... Analog ....... 0.0V to 2.0V p-p with no offset

Impedance .................................... 75 ohms

Horizontal frequency .................. 15 kHz to 150 kHz

Vertical frequency ....................... 30 Hz to 150 Hz

Return loss .................................... -45dB @ 5 MHz

Maximum DC offset .................... 1.5V

Video output

Number/signal type

MLS 306 ............................. 2 RGBHV, RGBS, RGsB, or RsGsBs

1 S-video

1 composite video

MLS 506 Series ................. 1 RGBHV, RGBS, RGsB, or RsGsBs

1 component video

1 S-video

1 composite video

Connectors

MLS 306 ............................. 1 female 15-pin HD (RGB computer video output 1)

5 female BNC (RGB output 2)

2 female BNC (S-video)

1 female BNC (composite video)

MLS 506 Series ................. Female BNCs

Minimum/maximum levels ...... Analog ....... 0.0V to 2.0V p-p with no offset

Impedance .................................... 75 ohms

Return loss .................................... -45dB @ 5 MHz

DC offset ....................................... ± 5mV maximum

Switching type ............................. Triple-Action for RGB

Sync

Input/output type ....................... RGBHV, RGBS, RGsB, RsGsBs

Standards ...................................... NTSC 3.58, NTSC 4.43, PAL, SECAM

Input level ..................................... 2V to 5V p-p

Output level.................................. TTL ............. 5.0V p-p

1-3MLS 306, MLS 506, MLS 506MA, MLS 506SA • Specifications

Input impedance .......................... >1 kohms

Output impedance ...................... 75 ohms

Max input voltage ....................... 5V p-p

Max propagation delay… ........... 30 ns

Polarity .......................................... Positive or negative (follows input)

Audio

Frequency response

MLS 306, MLS 506 ........... 20 Hz to 20 kHz, +0dB/-3dB

MLS 506MA ...................... 50 Hz to 15 kHz, +0dB/-1dB; 20 Hz to 20 kHz, +0dB/-3dB

MLS 506SA ....................... 20 Hz to 20 kHz, +0dB/-1dB at 30 W into 8 ohms

THD + Noise

MLS 306, MLS 506 ........... <0.2% @ 50 Hz to 22 kHz at rated maximum output drive

MLS 506MA ...................... <0.8% @ 50 Hz to 22 kHz at rated maximum output drive

MLS 506SA ....................... <0.5% @ 1 kHz at 30 W into 8 ohms

S/N ................................................ >90dB at 22 Hz to 22 kHz

Crosstalk ....................................... <-65dB @ 20 Hz to 20 kHz, <-80dB @ 1kHz and below 60 Hz, fully loaded

Stereo channel separation

MLS 506SA ....................... >80dB @ 1 kHz

All other models .............. >90dB @ 1 kHz

CMRR ............................................ >90dB @ 20 Hz to 200 Hz, >60dB @ 20 Hz to 20 kHz

Audio input

Number/signal type

MLS 306, MLS 506 ........... 6 stereo, balanced/unbalanced

MLS 506MA/SA .............. 7 stereo, balanced/unbalanced

Connectors

MLS 306 ............................. Inputs 1 to 3 .............. 3.5 mm captive screw connectors, 5-pole

Inputs 4 to 6 .............. 3.5 mm captive screw connectors, 5-pole or

female 3.5 mm mini stereo jacks (unbalanced)

MLS 506 ............................. 6 3.5 mm captive screw connectors, 5-pole

MLS 506MA/SA .............. 7 3.5 mm captive screw connectors, 5-pole

Impedance .................................... >18 kohms unbalanced/balanced

Maximum level ............................ +21dBu (balanced or unbalanced) at stated % THD + N

Input gain adjustment................. MLS 306, MLS 506 .................. -15dB to +9dB, adjustable per input

Input level adjustment ................ MLS 506MA, MLS 506SA ...... -78dB to +24dB (in 1 to 100 steps), adjustable per

input

Audio — effects return (MLS 506MA & MLS 506SA)

Number/signal type ................... 1 stereo, unbalanced

Connectors .................................... 1 3.5 mm captive screw connector, 3-pole

Impedance .................................... >10 kohms unbalanced

Level .............................................. +4dBu, unbalanced

Audio — effects send (MLS 506MA & MLS 506SA)

Number/signal type ................... 1 stereo, unbalanced

Connectors .................................... 1 3.5 mm captive screw connector, 3-pole

Impedance .................................... 50 ohms, unbalanced

Level .............................................. +4dBu, unbalanced

1-4 MLS 306, MLS 506, MLS 506MA, MLS 506SA • Specifications

Specifications — MediaLink Switchers (cont’d)

Audio output — line level (all models)

Number/signal type ................... 2 stereo/mono (selectable), balanced/unbalanced (1 fixed, 1 variable)

Connectors .................................... 2 3.5 mm captive screw connectors, 5 pole

Impedance .................................... 50 ohms unbalanced, 100 ohms balanced

Gain — fixed output

MLS 306, MLS 506

Unbalanced ............... 0dB

Balanced .................... +6dB

MLS 506MA, MLS 506SA

Unbalanced ............... 0dB

Balanced .................... +6dB

Gain — variable output only ..... Selectable output level

MLS 306, MLS 506

Unbalanced ............... 0dB (jumper selectable), or

-6dB (jumper selectable, default)

Balanced .................... +6dB (jumper selectable), or

0dB (jumper selectable, default)

MLS 506MA, MLS 506SA

Unbalanced ............... 0dB (jumper selectable), or

-6dB (jumper selectable, default)

Balanced .................... +6dB (jumper selectable), or

0dB (jumper selectable, default)

Gain error...................................... ±0.1dB channel to channel

Maximum level (Hi-Z) ................ >+21dBu, balanced at stated %THD+N

Maximum level (600 ohm) ......... >+15dBm, balanced at stated %THD+N

0dBu = 0.775 volts (RMS).

Audio output — power amp (MLS 506MA & MLS 506SA)

Number/ signal type

MLS 506MA ...................... 1 mono

MLS 506SA ....................... 1 stereo

Connectors .................................... 4 position screw terminal

Sensitivity ..................................... -20dBu (100mV) for 30 watts output

Drive/power (full power out) ... At less than 0.5% THD from 20 Hz to 20 kHz:

MLS 506MA (70V, mono) 30 watts (RMS); 4 ohm, 8 ohm, or 70V output taps with common/ground,

transformer coupled

MLS 506MA (100V, mono) 30 watts (RMS); 4 ohm, 8 ohm, or 100V output taps with common/ground,

transformer coupled

MLS 506SA (stereo) ......... 60 watts; 30 watts (RMS) per channel, 4 ohm or 8 ohm load

Protection

MLS 506MA ...................... Input limiting, thermal, short circuit

MLS 506SA ....................... Input limiting (user specifies 4 ohm or 8 ohm load), thermal, short circuit

Indication

MLS 506MA ...................... Clip LED indicates the onset of 30 watt power limiting

MLS 506SA ....................... Clip LED indicates the onset of 30 watt power limiting on left or right

0dBu = 0.775 volts (RMS).

Control/remote — switcher

Serial control port ........................ 1 RS-232, female 9-pin D connector (shared with contact closure port)

1 3.5 mm captive screw connector, 5 pole (for control via MLC 206; shared with IR

control port)

Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity

Serial control pin configurations 2 = TX, 3 = RX, 5 = GND

1-5MLS 306, MLS 506, MLS 506MA, MLS 506SA • Specifications

Contact closure ............................ 1 female 9-pin D connector (shared with serial control port)

Contact closure pin configuration… pin 1 = input 1, pin 4 = input 2, pin 5 = ground, pin 6 = input 3,

pin 7 = input 4, pin 8 = input 5, pin 9 = input 6

IR control port .............................. 1 3.5 mm captive screw connector, 5 pole (shared with the MLC/IR serial control

port) for 38 kHz IR signals

Program control ........................... Extron’s control program for Windows®

Extron’s Simple Instruction Set™ – SIS™

General

Power............................................. 100VAC to 240VAC, 50/60 Hz, internal, autoswitchable

MLS 306, MLS 506 ........... 20 watts

MLS 506MA ...................... 60 watts

MLS 506SA ....................... 100 watts

Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing

Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing

Rack mount................................... Yes, with included brackets

Enclosure type .............................. Metal

Enclosure dimensions

MLS 306 ............................. 1.75” H x 17.5" W x 9.4" D (1U high, full rack width)

4.4 cm H x 44.4 cm W x 23.9 cm D

(Depth excludes connectors and knobs. Width excludes rack ears.)

MLS 506 Series ................. 3.5” H x 17.5" W x 9.4" D (2U high, full rack width)

8.9 cm H x 44.4 cm W x 23.9 cm D

(Depth excludes connectors and knobs. Width excludes rack ears.)

Product weight

MLS 306 ............................. 5.5 lbs (2.5 kg)

MLS 506 ............................. 7.0 lbs (3.2 kg)

MLS 506MA ...................... 10.2 lbs (4.6 kg)

MLS 506SA ....................... 8.6 lbs (3.9 kg)

Shipping weight

MLS 306 ............................. 9 lbs (4.1 kg)

MLS 506 ............................. 14 lbs (6.4 kg)

MLS 506MA ...................... 17 lbs (7.7 kg)

MLS 506 SA ...................... 16 lbs (7.3 kg)

Vibration ....................................... ISTA/NSTA 1A in carton (International Safe Transit Association)

Listings .......................................... UL, CUL

Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES

MTBF ............................................. 30,000 hours

Warranty ....................................... 3 years parts and labor

Specifications are subject to change without notice.

(7.32-04302-D5)

Andere Handbücher für MLS 306

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Extron electronics Schalten Handbücher

Extron electronics

Extron electronics System 5 IP Series Bedienungsanleitung

Extron electronics

Extron electronics SW6 AV MX AS Bedienungsanleitung

Extron electronics

Extron electronics YCS SW2 A Bedienungsanleitung

Extron electronics

Extron electronics FOX SW8 Bedienungsanleitung

Extron electronics

Extron electronics SW2 DP Bedienungsanleitung

Extron electronics

Extron electronics Extron SW 2 VGAcc Bedienungsanleitung

Extron electronics

Extron electronics MMX 62 AV RCA Bedienungsanleitung

Extron electronics

Extron electronics YCS SW6 MX Bedienungsanleitung

Extron electronics

Extron electronics FOX 4G Matrix 3200 Bedienungsanleitung

Extron electronics

Extron electronics SW 4 AR MX HV Bedienungsanleitung

Extron electronics

Extron electronics FOX SW8 Bedienungsanleitung

Extron electronics

Extron electronics SW RGBHV Series Bedienungsanleitung

Extron electronics

Extron electronics VGA MATRIX SWITCHERS MVX PLUS 128 Bedienungsanleitung

Extron electronics

Extron electronics DTP T USW 333 Bedienungsanleitung

Extron electronics

Extron electronics VersaTools MSW 4SV Bedienungsanleitung

Extron electronics

Extron electronics RGB 580xi CCSI AAP Bedienungsanleitung

Extron electronics

Extron electronics SW HD 4K PLUS Series Bedienungsanleitung

Extron electronics

Extron electronics MLS 608 D SA Bedienungsanleitung

Extron electronics

Extron electronics IN1604 DT Bedienungsanleitung

Extron electronics

Extron electronics System 8 Plus Bedienungsanleitung

Extron electronics

Extron electronics SW2 VGA DA2 AF R Bedienungsanleitung

Extron electronics

Extron electronics SW6 AV MX AS Bedienungsanleitung

Extron electronics

Extron electronics System 5 IP Series Bedienungsanleitung

Extron electronics

Extron electronics USB HUB4 Series Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
