TLP Pro 720M and TLP Pro 1020M • Setup Guide

Overview

The Extron TLP Pro 720M is a 7-inch wall mount touchpanel with a high resolution 800x480 LCD screen. The TLP Pro 1020M is

a 10-inch wall mount touchpanel with a high resolution 1024x600 LCD screen. They are ideal for any AV applications requiring

medium or large touchpanels with exible mounting options and fully customizable interfaces. This guide provides instructions for

experienced installers to mount and install a TLPPro 720M or TLP Pro 1020M touchpanel. For more complete instructions, see the

TLPPro720Series and TLPPro 1020 Series User Guide, at www.extron.com.

Setup Checklist

Get Ready

Download and install the latest version of the following software:

Global Configurator Professional or Global Configurator Plus — for setting up and conguring the control processor and

touchpanel.

GUI Designer — for designing layouts for Extron TouchLink®Pro touchpanels and third party touch interfaces.

Both software programs are available from www.extron.com.

Obtain the following network information from your network administrator:

DHCP status (on or off). If DHCP is off, you will also require

IP address Subnet mask Gateway

User name — by default these are either admin or user.

Passwords — by default these are either extron (for admin) or the eld is left blank (for user).

Make a note of the touchpanel MAC address.

Mount and Cable All Devices

ATTENTION:

• Do not power on the touchpanels or control processors until you have read the Attention in the Power Supply section

of the TLP Pro 720 Series and TLP Pro 1020 Series User Guide or the IPL Pro User Guide.

• Ne branchez pas les écrans tactiles ou les contrôleurs avant d’avoir lu la mise en garde dans la section «sources

d’alimentation» du TLP Pro 720 Series and TLP Pro 1020 Series UserGuide ou du IPLProUserGuide.

Mount the units. There are several mounting options for TouchLink Pro touchpanels (see Mounting below).

Connect cables to the touchpanels.

Connect the power cords and power on all devices.

Set up the Touchpanels for Network Communication

Connect the PC that you will use for setup, the control processor, and touchpanel to the same Ethernet subnetwork.

Use the Setup Menu (see page 4) or the Toolbelt feature of Global Congurator Professional or Global Congurator Plus to set

the DHCP status and, if necessary, the IP address, subnet mask, gateway, and related settings for the touchpanel.

Conﬁgure the Touchpanels

The Global Conﬁgurator Professional Help File, the Global Conﬁgurator Plus Help File, and the GUI Designer Help File provide step-by-

step instructions and more detailed information. The Global Congurator Professional and Global Congurator Plus help les include

an introduction to the software and sections on how to start a project and conguration.

Mounting

The following optional mounting kits are available for the touchpanels. The kits must be purchased separately. Follow the instructions

provided with the kit.

zRack mounting — RM 710M for the TLP Pro 720M or RM 1000M for the TLP Pro 1020M.

zBack Box wall mounting — BB 710 or EWB 710 for the TLP Pro 720M or BB 1000 or the EWB 1000 for the TLP Pro 1020M.

TLP PRO 720M and TLP PRO 1020M • Setup Guide (Continued)

Wall-Mounting or Furniture-Mounting

The TLP Pro 720M or TLP Pro 1020M can be mounted directly to the wall or directly into furniture without a kit.

ATTENTION:

• Do not install the TLP Pro 720M or TLP Pro 1020M in a re resistant rated wall or partition assembly.

• Ne pas installer le TLP Pro 720M or TLP Pro 1020M dans un mur résistant au feu ou une cloison.

To mount either touchpanel into drywall, follow these steps. The steps are similar for mounting the unit in furniture (such as a podium

or table). Figure 1 shows the TLP Pro 720M, but the instructions for the TLP Pro 1020M are the same.

1. Use the provided cut-out template as a guide to mark the wall at a suitable location.

2. Use a wallboard saw or jigsaw to cut away the material within the guidelines drawn in step 1.

ATTENTION:

• Cut inside the guidelines to maximize the contact between the wallplate adapter and the drywall.

• Couper en suivant le marquage an d’optimiser le contact entre la plaque murale d’adaptation et la cloison.

3. If there is insulation inside the drywall, remove at least 6 inches of insulation in all directions around the opening. If the opening is

less than 6 inches from a wall stud, remove all the insulation between the opening and the wall stud.

4. If necessary, separate the bezel from the touchpanel, using the provided removal tool. Insert the tool into the notches on the

bottom surface of the bezel and gently separate the bezel from the touch panel.

5. Ensure all the locking arms are ush with the unit and check the size of the opening by inserting the touchpanel into it. If

necessary, use a saw, le, or sandpaper to enlarge the hole.

CAUTION: Smooth the edges of the opening to avoid personal injury during installation and to avoid damage to the

touchpanel or cables.

ATTENTION: Limez les bords de l’ouverture an d’éviter toute blessure lors de l’installation et éviter d’endommager la

plaque murale d’adaptation ou les câbles.

6. Remove the touchpanel from the hole and run the cables inside the wall to the hole, leaving enough slack in the cables to connect

them to the back of the touchpanel.

7. Plug the cables into the rear panel connectors (see page 4).

zConnect the LAN port to the PoE power injector or a PoE enabled switch.

zIf you use the LAN port only as a network connection, connect a 12 VDC,

1.0 A power supply to the 2-pole captive screw power input connector.

8. Push excess cables into the wall cavity.

9. Use a Phillips head screwdriver to tighten the locking arm screws. As the

screws tighten, the locking arms rotate behind the

wall and hold the adapter in place.

ATTENTION:

• Do not overtighten the screws as

this can damage the catches or the

wall.

• Ne serrez pas trop les vis au risque

d’endommager les attaches ou le

mur.

zThe TLP Pro 720M has four locking arms,

two at the top and two at the bottom.

zThe TLP Pro 1020M has ve locking arms,

three at the top and two at the bottom.

10. If required, perform the initial conguration, using

the setup menu (see page 4).

11. Press the bezel onto the touchpanel by pushing

the catches on the bezel into the corresponding

holes on the front of the panel.

Bezel snaps to unit

(2 tabs on each side).

Tighten screws to

rotate locking arms.

Locking arm (4)

Insert Pry T

ool

into slots to

emove bezel.

Figure 1. Mounting the TLP Pro 720M

Product Category

Front Panel Features

The TLP Pro 720M and TLP Pro 1020M ship with the bezels attached

(see the diagram to the right).

Extron

TLP Pro 720M TLP Pro 1020M

FH IJ

E E

E I H

Figure 2. TLP Pro 720M (left) and TLP Pro 1020M (right) Front Panels

AStatus lights — one on each top corner can be congured to provide system feedback. They can light red or green and they can

blink or light continuously

BAmbient light sensor — monitors ambient light level and adjusts screen brightness, based on the settings congured using the

setup menu (see page 4).

CBezel attachment points — The TLP Pro 720M has eight attachment points (two on each side, two on the top edge, and two on

the bottom edge); the TLP Pro 1020M has ten attachment points (three on each side, two on the top edge, and two on the bottom

edge). Use the Extron removal tool to separate the front bezel from the touchpanel. Insert the tool into one of the slots found on

the bottom surface of the unit and pry the bezel away from the touchpanel.

DLCD screen — TLP Pro 720M: 7-inch screen with 800x480 resolution. TLP Pro 1020M: 10-inch screen with 1024x600 resolution.

ESpeakers — provide audible feedback for the user. The TLP Pro 720M has one on the left side of the panel, under the screen.

The TLP Pro 1020M has two, placed under the screen, one on each side.

FMotion sensor — detects motion between three to ve feet from the touchpanel, and at least 15° from the center axis. When no

motion has been detected for a user-dened period of time, the touchpanel enters into sleep mode. When motion is detected by

the sensor, the screen display is restored and active.

GCommunication LED — shows the conguration and connection status of the touchpanel. The LED is unlit during normal

operation (the touchpanel is congured and connected to an IP Link Pro control processor). It blinks red if the touchpanel has

been congured but is not connected to an IP Link Pro control processor. It is permanently lit if the touchpanel has not been

congured and is not connected to an IP Link Pro control processor. The indicator can be toggled between enabled and disabled,

using the setup menu (see page 4)

HMenu button — activates the setup menu and calibration screen (see page4).

IReset button — pressing the reset button allows the unit to be reset in any of three different modes (see below).

JReset LED — provides feedback about the reset status when the user presses the reset button.

Reset Modes: a Brief Summary

The TLP Pro 720M and TLP Pro 1020M offer the following reset modes (see the TLP Pro 720 Series and TLP Pro 1020 Series User

Guide. for complete information):

• Use factory firmware: Press and hold the Reset button (gure 2, I) while applying power to the unit. Use this

mode to replace rmware in the event of rmware failure.

• Reset All IP Settings: Press and hold the Reset button for 6 seconds. After the Reset LED (gure 2, J) ashes

twice, release and momentarily press the Reset button. Use this mode to reset all network

settings without affecting user-loaded les.

• Reset to Factory

Defaults:

Press and hold the Reset button for 9 seconds. After the Reset LED ashes three times,

release and momentarily press the Reset button. Use this mode to return the interface to

factory default settings.

68-2405-51 Rev. B

05 14

Extron Headquarters

+1.800.633.9876 (Inside USA/Canada Only)

Extron USA - West Extron USA - East

+1.714.491.1500 +1.919.850.1000

+1.714.491.1517 FAX +1.919.850.1001 FAX

Extron Europe

+800.3987.6673

(Inside Europe Only)

+31.33.453.4040

+31.33.453.4050 FAX

Extron Asia

+65.6383.4400

+65.6383.4664 FAX

Extron Japan

+81.3.3511.7655

+81.3.3511.7656 FAX

Extron China

+86.21.3760.1568

+86.21.3760.1566 FAX

Extron Middle East

+971.4.299.1800

+971.4.299.1880 FAX

Extron Korea

+82.2.3444.1571

+82.2.3444.1575 FAX

Extron India

1800.3070.3777

(Inside India Only)

+91.80.3055.3777

+91.80.3055.3737 FAX

TLP PRO 720M and TLP PRO 1020M • Setup Guide (Continued)

Rear Panel Features

Extron

Figure 3. TLP Pro 720M (left) and TLP Pro 1020M (right) Rear Panels

APower connector — Connect a 12 VDC, 1.0 A power supply (not included) to this 2-pole captive screw connector.

ATTENTION:

• The TLP Pro 720M and TLP Pro 1020M can use a 12 VDC desktop power supply and is also Power over Ethernet

(PoE 802.3af, class3) compliant. Do not connect either power supply before reading the Attention in the Power

Supply section of the TLP Pro 720 Series and TLP Pro 1020 Series User Guide.

• Le TLP Pro 720M et le TLP Pro 1020M peut utiliser une source d’alimentation externe 12 Vcc, et est également

compatible avec l’alimentation POE via Ethernet (PoE 802.3af, classe 3). Ne branchez pas de sources

d’alimentation externes avant d’avoir lu les mises en garde dans la section «PowerSupply» du TLP Pro 720

Series and TLPPro 1020 Series User Guide.

NOTES:

• The TLP Pro 720M and TLP Pro 1020M ship without a power supply. Either the 12 VDC, 1.0 A power supply or the

power injector must be purchased separately.

• If a 12 VDC and a PoE power injector are both connected to the TLP Pro 720M or TLP Pro 1020M, the power

injector takes precedence. If a PoE power loss is detected, the touchpanel switches seamlessly to the 12 VDC

supply without needing a system reboot.

BNetwork and Power over Ethernet connector — for the TLP Pro 720M, this is in the top surface of the recessed area (see the

arrow). Connect the touchpanel to the LAN using a twisted pair cable, terminated with an RJ-45 connector. The connector can

also be used with a PoE power injector (not provided).

An Extron IP Link Pro control processor must also be connected to the same network as the TouchLink Pro touchpanel.

Setup Menu

Press the menu button (Hin gure 2, on the previous page) to open the

setup menu. Select any of the ve available screens (Status, Network,

Display, Audio, and Advanced) by pressing the appropriate button in

the navigation bar at the top of the screen (for more information, see the

TLPPro 720 Series and TLP Pro 1020 Series User Guide).

Figure 4 shows the setup menu for the TLP Pro 720M. The setup menu for

the TLP Pro 1020M is almost identical.

Press the menu button for at least 3 seconds to open the calibration

screen. Follow the on-screen instructions.

Status DisplayAudioAdvanced Exit

Network

Info

Model: TLP Pro 720M

Part Number: 60-1394-02

Firmware

Version: 1.00

PoE Status:On

Network

IP Address:

DHCP:

Host Name:

Off

192.168.254.251

TLP-AB-CD-EF

Display

Resolution:

Project:

Sleep Timer:

800x480

N/A

5 Minutes

Audio

Master Volume:

Master Mute:Off

Advanced

Controller IP:N/A

Project Size:N/A

Figure 4. Setup Menu: Status page for TLP Pro 720M

Andere Handbücher für TLP Pro 720M

Inhaltsverzeichnis

Andere Extron electronics Touchscreen Handbücher

Extron electronics

Extron electronics TLP Pro 1220TG Bedienungsanleitung

Extron electronics

Extron electronics TLP 710MV Bedienungsanleitung

Extron electronics

Extron electronics TLP Pro 1230WTG Bedienungsanleitung

Extron electronics

Extron electronics TouchLink TLP Pro 1025T Series Bedienungsanleitung

Extron electronics

Extron electronics TLP 350MV Bedienungsanleitung

Extron electronics

Extron electronics TLP Pro 720M Bedienungsanleitung

Extron electronics

Extron electronics TouchLink TLP Pro 520M Bedienungsanleitung

Extron electronics

Extron electronics TLP 700MV Bedienungsanleitung

Extron electronics

Extron electronics TouchLink TLP Pro 1220 Series Bedienungsanleitung

Extron electronics

Extron electronics TLP 700MV Bedienungsanleitung

Extron electronics

Extron electronics TLP Pro 720C Bedienungsanleitung

Extron electronics

Extron electronics TLP Pro 1725TG Bedienungsanleitung

Extron electronics

Extron electronics TLP Pro 1020T Bedienungsanleitung

Extron electronics

Extron electronics TouchLink TLP 350CV Bedienungsanleitung

Extron electronics

Extron electronics Scan Rate Indicator SRI 200 Bedienungsanleitung

Extron electronics

Extron electronics TouchLink Series Gebrauchsanweisung

Extron electronics

Extron electronics TLP Pro 720M Bedienungsanleitung

Extron electronics

Extron electronics TLP 1000MV Bedienungsanleitung

Extron electronics

Extron electronics TLP Pro 1220TG Bedienungsanleitung

Extron electronics

Extron electronics ZRTP Series Bedienungsanleitung

Extron electronics

Extron electronics TLP 700TV Bedienungsanleitung

Extron electronics

Extron electronics TLP Pro 725T Bedienungsanleitung

Extron electronics

Extron electronics TLP Pro 1220MG Bedienungsanleitung

Extron electronics

Extron electronics BB 1000M Bedienungsanleitung

Beliebte Touchscreen Handbücher anderer Marken

FlowLine

FlowLine Data loop Bedienungsanleitung

ALPEX

ALPEX AEx-8 P Series Bedienungsanleitung

Ltech

Ltech E5S Bedienungsanleitung

Harman

Harman AMX MODERO S MSD-701-L2 Bedienungsanleitung

Acnodes

Acnodes PC 1150 Bedienungsanleitung

AIS

AIS IP10IA99 series Bedienungsanleitung

IBASE Technology

IBASE Technology ASTUT-152-RE1S Bedienungsanleitung

YASKAWA

YASKAWA TP 610C Bedienungsanleitung

B&R

B&R Power Panel C Series Bedienungsanleitung

Beijer Electronics

Beijer Electronics X2 control Bedienungsanleitung

AXIOMTEK

AXIOMTEK GOT321W-521 Bedienungsanleitung

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Bedienungsanleitung

Qomo

Qomo QIT1386 Bedienungsanleitung

DFI

DFI KS104-CD Bedienungsanleitung

AMX

AMX AXP-PPC Leitfaden

Sartorius

Sartorius X3 PR 5410 Bedienungsanleitung

AMX

AMX Modero X Series Bedienungsanleitung

Advantech

Advantech TPC-30 Series Bedienungsanleitung
