FCC BBQ CHES'S Special 4.1 Technisches Datenblatt

Sare  u  cookin!

FCC-G-19000-41 / K104BGD1

MANUAL

Installation, use, maintenance and safety

! OUTDOORUSEONLY

READTHEMANUAL, FOLLOWTHE

ASSEMBLYINSTRUCTIONSSTEPBY

STEP. GETTOKNOWYOURGRILL

ANDTHESAFETYINSTRUCTIONS

BEFOREUSINGTHEAPPLIANCE!

EXTENDED WARRANTY:

WATCH BBQ ASSEMBLY

ON VIDEO HERE:

Contents

Warnings ..........................................................................................................................................3

Technical Data ...............................................................................................................................4

Read before assembly .............................................................................................................5

Parts list ............................................................................................................................................6

Exploded Drawing .......................................................................................................................7

Hardware ..........................................................................................................................................7

Assembly instructions ..............................................................................................................8

Connecting gas ........................................................................................................................16

Gas leak test - To be done before using the grill .....................................................17

Last check ......................................................................................................................................18

Lighting instructions ................................................................................................................19

Maintenance ..............................................................................................................................20

Advice, tips and safety ....................................................................................................22

Troubleshooting .........................................................................................................................23

Consumer Contact ..................................................................................................................24

WARNINGS!

●ACCESSIBLE PARTS OF THE GRILL BECOME VERY HOT

DURING USE. KEEP CHILDREN AND OTHERS WHO NEED

SUPERVISION AT A SAFE DISTANCE.

●THE GRILL IS INTENDED FOR OUTDOOR USE ONLY IN WELL-

VENTILATED AREAS.

●LEAK TESTS (SEE PAGE 17) MUST ALWAYS BE CARRIED OUT

BEFORE THE GRILL IS USED AND WHEN REPLACING THE

GAS CONTAINER. ALSO PERFORM A LEAK TEST IF THE

PRODUCT HAS NOT BEEN IN USE FOR A LONG TIME AND IN

ADVANCE OF A NEW BARBECUE SEASON. ALWAYS CHECK

THE GAS HOSE FOR DAMAGE AND CRACKS BEFORE USING

THE BARBECUE.

●NEVER BARBECUE IN CLOSED ROOMS OR UNDER ROOFS,

AS THIS MAY LEAD TO A LACK OF OXYGEN.

●FAILURE TO FOLLOW THE INSTRUCTIONS PROVIDED CAN

IMPLY A RISK OF SERIOUS INJURY TO PERSONNEL AND

FIXED INSTALLATIONS.

●REBUILDING / MODIFYING THE BARBECUE CAN CAUSE

DANGER AND WILL INVALIDATE THE WARRANTY.

●ALWAYS SUPERVISE THE BARBECUE DURING USE AND KEEP

SUITABLE EXTINGUISHING EQUIPMENT WITHIN REACH.

THE GRILL SHOULD NOT BE OPERATED BY INTOXICATED

PERSONS.

●THE BARBECUE MUST NOT BE USED IN PLACES THAT ARE

BELOW NORMAL GROUND LEVEL. GAS CAN ACCUMULATE

AND REPRESENT A DANGER OF EXPLOSION. GAS

ACCUMULATION CAN ALSO CAUSE OXYGEN DEFICIENCY.

●THE BARBECUE MUST BE CLEANED REGULARLY AND

THOROUGHLY TO PREVENT UNCONTROLLED GREASE FIRE.

READ MORE ABOUT GREASE FIRE ON PAGE 22.

ALSO READ PAGE 24 FOR MORE ADVICE AND TIPS ON GRILLING AND SAFETY.

WARNINGS!

3fccbbq.com

Tekniske data

Total Heat input: 17 kW

Gas consumption: 1238 gram/hour

Gascylinder (not included): Use standard cylinder approved for use in the Nordic Region.

Even though butane and propane gas can be used, we recommend propane for use in the

Nordic Region. Approved hoses and regulators are available from most outlets selling gas

equipment.

Perform the gas leak test as instructed on page 17 before using the product.

NB! Gas hoses used for this product must not exceed 120 cm in length.

Technical Data

CY, CZ, DK, EE, FI, FR,

HU, LT, IT, NO, NL, SE, SI,

SK, RO, HR, TR, BG, IS,

LU, MT

Ø 0.92 mm main burner

Ø 0.88 mm side burner

G30(Butane

G31(Propane)

and their mixtures

I3B/P(30)

The product is manufactured in accordance with European Gas Appliances Regulation (EU) 2016/426

ONLY THE GAS TYPE AND GAS CATEGORY LISTED IN

THE RATING LABEL IS TO BE USED ON YOUR APPLIANCE.

DESTINATION OF

COUNTRIES TO USE

GAS TYPEVALVE SIZE GAS CATEGORY

h: 116 cm

w: 138cm d: 60 cm

Read before assenbly

A screwdriver and adjustable/allen wrench (not provided)

is necessary when assembling the BBQ.

The BBQ should be assembled by two persons.

Make sure that all parts and screws are included and that they are

undamaged before assembling the product.

If the grill is damaged during transport, do not assemble the grill

before contacting your dealer or support@fccbbq.com.

Transport damage to parts, varnish or enamel must be reported to

the dealer or support@fccbbq.com before the grill is installed and

used.

Please note that some parts may be located in the Styrofoam to

protect the part during transport. If parts are missing, ﬁrst check

the packaging carefully.

Compare the parts list with the contents of the box. Do not

assemble this grill if there is damages or parts are missing, contact

your dealer or [email protected]om.

Remove all remnants of packaging material and any plastic wrap

from the grill.

●FOLLOW THE ORDER IN THIS MANUAL TO AVOID INCORRECT ASSEMBLY.

PARTS OF THE ASSEMBLY WILL REQUIRE HEAVY LIFTING WHICH

SHOULD BE PERFORMED BY TWO PEOPLE TOGETHER, TO AVOID

PERSONAL INJURY AND DAMAGE TO THE GRILL. SOME METAL PARTS

MAY BE SHARP, WEAR PROTECTIVE GLOVES.

●POWER TOOLS SHOULD NOT BE USED TO ASSEMBLE THE GRILL.

TOOLS WITH TOO MUCH FORCE CAN DAMAGE THE SURFACE

TREATMENT ON SCREWS, DAMAGE ENAMELLED / LACQUERED PARTS

OF THE GRILL, AS WELL AS LOOSEN PRE-ASSEMBLED NUTS.

●IF THE PRODUCT'S VARNISH OR ENAMEL IS DAMAGED DURING

ASSEMBLY, WE RECOMMEND THAT THE DAMAGE BE TREATED

IMMEDIATELY TO AVOID LATER RUST DAMAGE. SUITABLE HEAT-

RESISTANT VARNISH CAN BE ORDERED FROM SUPPORT@FCCBBQ.COM.

FOLLOW THESE INSTRUCTIONS CAREFULLY TO AVOID

SERIOUS PERSON INJURY OR DAMAGE TO YOUR BARBECUE.

5fccbbq.com

Parts list

CODE DESCRIPTION QTY

LID 

THERMOMETER 

THERMOMETERBEZEL 

LIDSCREW 

LIDHANDLE 

LIDBUFFER 

WARMINGRACK 

CASTIRONGRID 195MM 

HEATDISTRIBUTIONPANEL 

 BURNERCLIP 

 MAINTUBEBURNER 4

 FIREBOXBACKCOVER 

 GREASECUPHOLDER 

 GREASETRAYCUP 

 GREASETRAY 

 SIDEBURNERLIDAXIS 

 SIDEBURNERLID 

 SIDEBURNERCOOKINGGRID 

 SIDEBURNERASSEMBLY 

 SIDEBURNERBASE 

 SIDEBURNERCONNECTIONBAR 

 SIDEBURNERIGNITIONNEEDLE 

 SIDEBURNERNOZZLE 

 SIDEBURNERCONNECTIONPIPE 

 SIDEBURNERTABLE 

 SIDELOWPANELLEFT 

 DOORMAGNET 

 CART FRONT BEAM 

CODE DESCRIPTION QTY

 REAR LOW PANEL 

 BOTTOM PANEL 

 SIDE LOW PANEL RIGHT 

 DOORSPINDLE 

 DOORSTOPPER 

 CARTTRIANGURSUPPORTBRACKET 

 WHEELPLUG 

 WHEELCASTOR 

 DOOR 

 DOORHANDLE 

 SIDEBURNERKNOB 

 MAIN BURNER KNOB 

 DOORHINGE 

 CONTROLPANEL 

 CONTROLPANELORNAMENT 

 GASCONNECTIONNOZZLE 

 GASCONNECTIONFIXATION 

 GASCONNECTIONPIPE 

 GASPIPEASSEMBLY 

 MAINBURNERGASVALVE 

 SIDEBURNERGASVALVE 

 INNERCONTROLPANEL 

 CONTROLPANELLEFTCONNECTION

BAR 

 CONTROLPANELRIGHTCONNECTION

BAR 

 BARRIERSTRIPFORCASTIRONGRIDS 

 LEFTSIDETABLE 

 INSERTSYSTEMBASICGRILLMGS 

 INSERTSYSTEMROUNDGRILLØ 305MM 

 GASCONNECTIONNOZZLEADAPTOR 

Exploded drawing

7fccbbq.com

Assembly

4 x B4 x B

9fccbbq.com

Assembly
