WG2 Gimbal Firmware Upgrade Manual

● Please do not operate any other function button except the ones indicated

by the instructions during upgrade.

● The firmware upgrade software is compatible with Windows operation

system provisionally,including Window XP / 7 / 8 / 8.1 / 10.

● If you want to upgrade it in Mac, Please kindly download the upgrade

software and USB driver for Mac from our official website.

● If you want to get the current version of the gimbal, please do the operations

step 1~7.

1. Download the USB driver from FeiyuTech official website

http://www.feyu-tech.com andinstallit.Thendownloadtheupgrade

software and the firmware for WG2.

2. Please refer the following connection diagram, connect the USB cable

with USB port of the computer and the gimbal. please make sure the

gimbal is powered off until step 7.

Attention

Steps

Guilin Feiyu Technology Incorporated Company

Guilin Feiyu Technology Incorporated Company www.feiyu-tech.com ser[email protected]

-2-

3. Check the port number in device manager .If the port number is more

than COM10 , please modify it to available number which is within

COM10 .

4. Run the software ---“Gimbal-Update-3AXIS” directly if you have a PC

with Windows XP/7/8/8.1 .

If you have a PC with windows10 operation system, please right click the

icon of the software ,choose “Trouble shoot compatibility”---”Try the

recommended settings”---”test program”, Run the upgrade software in

compatibility mode.

5. Software interface is shown in following picture:

Guilin Feiyu Technology Incorporated Company

Guilin Feiyu Technology Incorporated Company www.feiyu-tech.com ser[email protected]

-3-

6. Choose correct port number and correct baud rate as 115200, then click

on OPEN button to open COM port.(The serial port number should

bethesameasstep3).

7. Long press the function button, The connection between the gimbal and

the computer will be established automatically, The connection status

and the current version show up(For example, “LINK OK! VERSION 1.

52”) , Keep holding the function button for 2~3 seconds after“LINK OK”

showing up.

Release it, the indicator will alternately flashing blue and red，Which

means the power is ready and the connection is done.

(Tips: if you can’t see that the indicator alternately flashing blue and red,

please long press the function button for 2 seconds again.)

Guilin Feiyu Technology Incorporated Company

Guilin Feiyu Technology Incorporated Company www.feiyu-tech.com ser[email protected]

-4-

8. Click on OPEN FILE button and choose the correct firmware for the

WG2

9. Click on UPDATE button to start upgrading, the process will display

on the software.

10. After all the blocks of the firmware are completely sent , please click on

Confirm button to finish the upgrade. Close the software then unplug

the USB cable. Long press the function button of the gimbal to power off.

All the upgrade is done.

Guilin Feiyu Technology Incorporated Company

Guilin Feiyu Technology Incorporated Company www.feiyu-tech.com ser[email protected]

-5-

FAQ

NO.1 “Link OK ”didn’t show up when pressing the function button.

①Please check whether tightly plug in USB cable with USB port, and the USB

cable is right cable from our standard accesseries.

② Please check whether keep the gimbal off until step7.

③ Please check whether choose the right USB port and the baudate as 115200.

④ Please check whether press the function button after clicking on “OPEN

COM“ button.

If you did all the things above right, please replace a new USB cable and try

again.

NO.2 When”LINK OK”and the version of current firmware showing up, click on

“UPDATE START”, but no luck, ”SEND FAIL” just show up to remind me the

update don’t work.

A: It happened because you didn’t hold the function button for enough time,

and the power didn ’ t start well. When the power is ready , the indicator

alternately flashes blue and red, if not, please keep holding the function button

for 2 seconds.

NO.3 After clicking on “UPDATE START”, “send block 10...” show up in the

interface , but ”SEND FAIL” happen during the update.

A: If ”SEND FAIL” shows up during the update, there may be something wrong

with the connection between control boards.

Please try to start update again, if the same issue happen, please kindly send

back to us for repair.

Check more details in tutorial video of G5(The same operation except

the battery as G5): https://youtu.be/yDHTLYQtnbc

–––– END ––––

Note: We reserve the right to change this manual at any time! And the newest

edition will be shown on our official website www.feiyu-tech.com.
