Fema Electronica LAP Series Bedienungsanleitung

Series LAP

Loop powered panel meters

Panel meter for mA current loop signals mA, with LCD display, loop powered

from the signal loop. Reading scalable to engineering units. Reading slope

congurable to be direct or inverse. Reading up to 1999 and down to -1999 with

selectable decimal point position.

Model LAP-35 for mA current loop signals

loop powered

Panel Meters

FEMA ELECTRÓNICA

USER’S MANUAL

(1202R02)

User’s Manual LAP-35

FEMA ELECTRÓNICA - Page 2

Panel Meter LAP-35

Panel meter 96x48mm for mA current loop signals

loop powered from the signal loop

Panel meter for mAcurrent loop signals. Instrument self pow-

ered from the mA signal loop. LCD display. Reading scalable

to engineering units.

Standard 96x48mm size, with 12.7mm digit height, and

resolution from 1999 to -199, with decimal point selection.

Connections via plug-in screw terminals and conguration

via internal jumpers for range selection and span and offset

potentiometers at the rear of the instrument. For application

on industrial environments.

LAP 35 (4/20mA

Model Input

- 4/20mA

- 10/50mA

- 1/5mA

-= 0/100.0)

Reading

- 0/100.0

- 0/345

- 10/1999

Order Reference

Mechanical dimensions (mm)

92,5

44,5

Panel cut-out

13 102 15

5 max

Technical specications

Digits 3 1/2

Type LCD, 7 segments

Height 12.7 mm

Reading max./min. 1999 / -1999

Decimal point selectable 1.8.8.8

Overrange 1___ (“_”= digits powered off)

Underrange -1___ (“_” = digits powered off)

Signals accepted mA

Ranges selectable 4/20mA, 10/50mA, 1/5mA

Connection 2 wires

Type active signal

Overcurrents max. 200mA

Power loop powered

Voltage drop 5.3V maximum

Conguration internal jumpers and span and off-

set potentiometers at the rear of

the instrument

Accuracy at 25ºC 0.1% FS ±1 digit

Display update 2.5 samples/second

Mechanical

Mounting panel

Connections plug-in screw clamp

Weight <150 grams

Housing material ABS

Front size 96x48mm

Panel cut-out 92.5x44.5mm

Deep from panel 117mm (including terminal)

Protection IP20

Operating temp. de 0 a 50ºC

Storage temp. de –20 a +70ºC

Warm-up 15 minutes

User’s Manual LAP-35

FEMA ELECTRÓNICA - Page 3

Front and rear view

Offset

mA signal loop

(polarity autodetected) Span

SELECTOR S3

SELECTOR S2

SELECTOR S1

F E D C B A

Internal jumpers

Decimal point selection

1.XXX S1-C

1X.XX S1-A

1XX.X S1-B

Select the jumpers for the desired decimal point position.

Signal range selection

4/20mA S2-B

10/50mA S2-A

1/5mA (Abrir S2-A y S2-B)

Select the jumpers for the desired input signal range.

Slope reading selection

Direct S2-D, S2-E, S3-E, S3-F

Inverse S2-C, S2-F

Select the jumpers for the desired reading slope.

As standard, the direct slope is used (reading increases

when signal increases). The inverse slope congures the

reading to decrease when reading increases.

Span and offset range selection

Low range S3-A, S3-G Span from 385 to 785

Offset from -160 to 100

Middle range S3-B, S3-G Span from 750 to 1500

Offset from -260 to 200

High range S3-G Span from 1090 to 1999

Offset from -380 to 560

Select the jumpers for the desired span and offset range.

Manufacturer FEMA ELECTRÓNICA, S.A.

Pol. Ind. Santiga - Altimira 14, E08210 - Barberà del Vallès

-BARCELONA, ESPAÑA-SPAIN, www.fema.es

Products : LAP-35. The manufacturer declares that the

instruments indicated comply with the directives and rules

indicated below. Directive of electromagnetic compatibility

2004/108/CEE. Directive of low voltage 73/23/CEE. Safety

rules 61010-1, Equipment “Fixed”, Pollution degree 1, CAT-

I. 61000-6-4 Generic rules of emission. 61000-6-2 Generic

rules of immunity

Barberà del Vallès October 2002

Daniel Juncà - Quality Manager

CE Declaration of conformity

Readjustment procedure

1- Take all jumpers out

2- Select appropriate signal range jumpers

3- Select appropriate slope reading jumpers

4-Select appropriate spanandoffsetjumpers.Calculate span

and offset values according to the example below. Example

given for an adjustment of 4/20mA = 0/1000

IL (input signal low) = 4mA RL (reading low)=0

IH (input signal high)= 20mA RH (reading high)=1000

G = ( RH - RL ) / ( IH - IL )

Offset = RL - ( IL x G )

Span = RH

If value obtained for G is higher than 125 or values for span

and offset do not t into any of the three available ranges,

then the adjustment is out of the capabilities of the instrument.

5- Select appropriate decimal point jumpers

6- Connect a signal generator to the input terminals

7- Generate the input signal low (4mA)

Operate Offset potentiometer until the value for reading

low is reached (0)

8- Generate the input signal high (20mA)

Operate Span potentiometer, until the value for reading

high is reached (1000)

9- Repeat steps 7 and 8, until desired accuracy is obtained

Offset

Span

FEMA ELECTRÓNICA, S.A.

Pol. Ind. Santiga - Altimira 14

E08210 Barberà del Vallès - BARCELONA

ESPAÑA - SPAIN

Tel. (+34) 93.729.6004 - www.fema.es

Fax (+34) 93.729.6003 - [email protected]

Large Displays

60&100mm digit

Signal Converters

& Isolators

Panel Meters

Standard 96x48mm

other products

ELECTRONIC INSTRUMENTATION FOR INDUSTRY

www.fema.es
