Fieldmann FZV 4001-E Bedienungsanleitung

FZV 4001-E

FZV 4001 E

English .......................................................................................................................................................... 9

Čeština ...................................................................................................................................................... 21

Slovenčina .............................................................................................................................................. 33

Magyarul ................................................................................................................................................. 45

Polski ........................................................................................................................................................... 57

Deutsch .................................................................................................................................................... 69

Español ..................................................................................................................................................... 81

Français .................................................................................................................................................... 93

Italiano .................................................................................................................................................... 105

Lietuvių .................................................................................................................................................... 117

Русский ..................................................................................................................................................... 129

FZV 4001 E

USER‘S MANUALVERTICUTTER

ENTable of contents

Verticutter

OPERATION MANUAL

Thank you for purchasing this garden verticutter. Before you start using it, please read

carefully this operating manual and keep it for future reference.

TABLE OF CONTENTS

APPENDIX OF FIGURES ................................................................................................................. 3

GENERAL SAFETY INSTRUCTIONS .......................................................................................... 10

Important safety warnings

Packaging

Instructions for use

SYMBOLS ........................................................................................................................................... 11

MACHINE DESCRIPTION AND PACKAGE CONTENT .................................................. 12

SAFETY INSTRUCTIONS .............................................................................................................. 13

PURPOSE OF USE ......................................................................................................................... 15

MACHINE ASSEMBLY ................................................................................................................. 15

OPERATION .................................................................................................................................... 16

MAINTENANCE ............................................................................................................................. 16

CYLINDER REPLACEMENT / TROUBLESHOOTING ........................................................ 17

MOWING ........................................................................................................................................ 18

TECHNICAL DATA ........................................................................................................................ 18

DISPOSAL ........................................................................................................................................ 19

DECLARATION OF CONFORMITY ..................................................................................... 142

WARRANTY CERTIFICATE ........................................................................................... 154 - 159

WARRANTY TERMS ........................................................................................................ 154 - 159

10.

11.

12.

FZV 4001 E

10EN

General safety instructions

1. GENERAL SAFETY INSTRUCTIONS

Important safety warnings

Unpack the product carefully and be sure not to throw away any part of the package before

having found all components of the product.

Keep the product in a dry place out of reach of children.

Read all cautions and instructions. The failure to adhere to warning cautions and instructions

may result in an accident, ﬁre and/or a serious injury.

Packaging

The product is placed in a package preventing damage during transport. This package is a raw

material therefore it can be handed-over for recycling.

Instructions for use

Before beginning to work with the machine, read the following safety rules and instructions for

use. Familiarize with operating elements and the proper use of the device. Keep the manual in a

safe place for future reference. We recommend keeping the original package including the inner

packaging materials, cash voucher and guarantee card for a period of warranty at minimum.

For a case of transportation, pack the machine into the original box from the manufacturer,

thus ensuring a maximum protection of the product during a possible transport (e.g. moving or

sending into a service station).

Note: If you hand the machine over to next persons, hand it over together with the manual.

Adherence to the attached instructions for use is a precondition for the proper use of the

machine. The operation manual includes also instructions for operation, maintenance and

repairs.

The manufacturer does not take any responsibility for accidents or

damages resulting from the failure to adhere to this manual.
