Fisher & Paykel E16B Bedienungsanleitung

Electronic 680

Refrigerator / Freezer

Models

E16B E16T E440T

E442B

Series

517701

MANUAL 517701 April 1997 Reprinted 18 August, 2000

Fisher & Paykel Customer Services

PO Box 798

19 Enterprise St

Cleveland, Queensland 4163

Australia

Tel: (07) 3826 9122

Fax: (07) 3826 9164

Email: parts@fp.com.au

A.C.N 003 335 171

Fisher & Paykel Ltd

Whiteware Spare Parts

PO Box 14-148, Panmure.

80 Springs Rd, East Tamaki

New Zealand

Tel: (09) 272 0261

Fax: (09) 272 0219

Email: parts@fp.co.nz

PRODUCTS

Brand Fisher & Paykel

Voltage 220-240V 50Hz, 110V 60Hz*

Model Code

E16B 10915A

E16T 10914A

E440T 10627 10859 10896* 10904 10906 10914 11358

E442B 10626 10860 10897* 10905 10907 10915 11357

MANUAL 517701

CONTENTS

DOOR ASSEMBLIES TOP FREEZER .....................................................................................................................................4

DOOR ASSEMBLIES BOTTOM FREEZER............................................................................................................................8

CABINET TOP FREEZER.......................................................................................................................................................12

CABINET BOTTOM FREEZER .............................................................................................................................................16

FRONT AND REAR CABINET ROLLERS ...........................................................................................................................20

FAN AND EVAPORATOR ASSEMBLIES............................................................................................................................22

ELECTRONIC MODULE AND DUCT COVERS..................................................................................................................26

COMPRESSOR AND POWER MODULE..............................................................................................................................28

NOTES......................................................................................................................................................................................32

REFRIGERATION ABBREVIATION KEY...........................................................................................................................33

MANUAL 517701

DOOR ASSEMBLIES TOP FREEZER

MANUAL 517701

DOOR ASSEMBLIES TOP FREEZER

REF PART DESCRIPTION MODEL

1 875926 PLUG DOOR END CAP SOFT LG

882348 PLUG DOOR END CAP SOFT WHITE

2 877965 LOGO ACTIVE SMART

3 875652 COVER HANDLE RECESS SOFT WHITE

875653 COVER HANDLE RECESS SOFT LG

4 * 875040 PLUG PIVOT DOOR OFFSET WHITE

875109 PLUG PIVOT DOOR OFFSET LG GREY

875425 PLUG PIVOT DOOR CLOSING WHITE

875924 PLUG PIVOT DOOR CLOSING LG

5 874706 LABEL FREEZER GUIDE RF BLUE

878471 LABEL FREEZER STORAGE GUIDE 63

6 * 874621 DOOR ASSY FC WHITE WHITE TRIM

875128 PLUG CAM DOOR CLOSING WHITE

875425 PLUG PIVOT DOOR CLOSING WHITE

882348 PLUG DOOR END CAP SOFT WHITE

874709 DOOR ASSY FC S/STONE LT GY TRI

875129 PLUG CAM DOOR CLOSING LT GREY

875924 PLUG PIVOT DOOR CLOSING LG

875926 PLUG DOOR END CAP SOFT LG

7 874364 BIN DR FC T HSM876507 635 BLUE

876507 BIN DOOR FC ’T’635

8 878904P GASKET ASSY FC LT GREY PUSHIN

9 875128 PLUG CAM DOOR CLOSING WHITE

875129 PLUG CAM DOOR CLOSING LT GREY

10 871123 PLUG/PIN HINGE DAIRY COVER

11 880258 COVER DR SHELF HSM882692 BLUE

12 882691 COVER COMP 680 LH MOULDED P42

13 882690 SHELF DOOR SMALL LH 680 P42

14 882689 SHELF DOOR SMALL RH 680 P42

15 882671 SHELF EGG RACK 680 P42

16 * 874623 DOOR ASSY PC WHITE WHITE TRIM

875128 PLUG CAM DOOR CLOSING WHITE

875425 PLUG PIVOT DOOR CLOSING WHITE

882348 PLUG DOOR END CAP SOFT WHITE

874708 LABEL ENERGY RATING C170T

875129 PLUG CAM DOOR CLOSING LT GREY

875924 PLUG PIVOT DOOR CLOSING LG

MANUAL 517701

DOOR ASSEMBLIES TOP FREEZER

MANUAL 517701

DOOR ASSEMBLIES TOP FREEZER

REF PART DESCRIPTION MODEL

16 875926 PLUG DOOR END CAP SOFT LG

17 871129 BIN EGG/ICE MOULD ALL BRANDS

18 882734 DIVIDER BOTTLE RAIL WHITE

19 882693 RAIL BOTTLE 680 P42

20 880255 SHELF DR LGE HSM882688 BL 680

21 855156 PLUG 10 DIA COVER WHITE

22 878901P GASKET ASSY PC LT GREY PUSHIN

23 881372 BOOKLET USE&CARE ACTIVE SMART

NI 872399 BOOKLET FREEZE WITH EASE F&P

NI 878434 LEAFLET WARRANTY AUST

NI 878438 LEAFLET WARRANTY NEW ZEALAND

NI 872959 SMARTCARE LEAFLET&ENVELOPE AUS

NI 479151 LEAFLET SMART CARE NZ

MANUAL 517701

DOOR ASSEMBLIES BOTTOM FREEZER
