Fisher-Price Smart cycle Montageanleitung

Assembly Tip

Please follow these instructions carefully to properly assemble the pedals to the Smart Cycle™.

• Locate the left pedal marked with an Lon the outside end.

• Fit the threaded end of the left pedal into the hole in the left

pedal axle marked with an L.

• Hand-tighten the pedal by turning it COUNTER-CLOCKWISE.

• Fit the end of the assembly tool to the groove in the end

of the pedal.

• Turn the assembly tool COUNTER-CLOCKWISE to fully

tighten the pedal.

• Fit the end of the assembly tool to the groove in the end

of the pedal.

• Turn the assembly tool CLOCKWISE to fully tighten

the pedal.

Left Pedal Right Pedal Assembly Tool

Your Smart Cycle includes a left and right pedal along with an assembly tool.

You must use the assembly tool to attach the pedals.

• Fit the threaded end of the right pedal (marked with an R)

into the hole in the right pedal axle (also marked with an R).

• Hand-tighten the pedal by turning it CLOCKWISE.

L R

C

o

u

n

t

e

r

-

C

l

o

c

k

w

i

s

e

C

l

o

c

k

w

i

s

e

L R

C

o

u

n

t

e

r

-

C

l

o

c

k

w

i

s

e

C

l

o

c

k

w

i

s

e

12

34

TM

Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A.

©2007 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.

PRINTED IN CHINA K5054pr-0921

• Insert two #8 x 1" screws into the handlebar and tighten.

Hint: If the screws cannot be tightened, you have not

assembled the handlebar properly. Remove the handlebar

and refer back to Assembly steps 2 and 3.

• Next, push the handlebar forward and down to "snap" it

in place. Make sure you hear a "snap". This may take a

lot of force.

34

Assembly Tip

Please follow these instructions carefully to properly assemble the handlebar to the Smart Cycle™.

• Plug the handlebar connector into the socket in

the console.

Hint: The connector will only ﬁt one way into the socket.

If it does not seem to ﬁt, turn it around and try again!

• Place the handlebar, at an angle, onto the top of the post.

• Push to insert the tab on the back of the handlebar into

the slot in the console.

Handlebar

Connector

Socket

Tab

Post

12

TOP VIEW
