Kit Contents
(51001) 20ft. Stainless Braided Hose
(51002) 20ft. Black Braided Hose
(51003) 40ft. Stainless Braided Hose
(51004) 40ft. Black Braided Hose
(1) 10 Micron Fuel Filter
(2)ORB-8 to AN-6 Filter Fitting
(1) Check Valve
(6) AN-6 Straight Hose End
(3) AN-6 45° Hose End
(3) AN-6 90° Hose End
(1) Hose End Assembly Tape
Fuel Line Kit # 51001,
51002, 51003, 51004
1. Mark the desired length of hose by
wrapping the hose with provided tape. Using a
fine-tooth hack saw, cut-off wheel, or cable
cutters, cut through the tape and hose. NOTE: A
clean perpendicular cut is important to ensuring
proper installation.
2. Hold or clamp the socket side of fitting into
a soft jaw vise. Insert hose into socket and push
while turning clockwise until hose is snug against
the socket's threads. TIP: mark hose at the
socket with tape or marker to easily see if hose
backs out when threading fittings together.
3. Clamp nipple side of fitting into soft jaw
vise. Apply lube to nipple. Thread socket onto
nipple threads by hand as far as possible. Then
using a wrench, thread socket onto the nipple
end until the socket base is within 1/16th inch or
less of a gap between socket base and the nipple
hex.
When determining hose routing never
make sharp turns that can put stress
on the hose and could cause kinks.
Make sure all hose lengths have at
least a little slack and that the hose is
not twisted. This will ensure there is
no stress on the hose which will
extend the life of the hose.
1.
2.
3.
FiTech Fuel Injection
12370 Doherty Street • Riverside, CA 92503
Tech Phone: 951-340-2624
www.FiTechEFI.com
One Year
Limited
Warranty on
FiTech EFI
Systems
FiTech extends the ollowing limited warranty to the original purchaser o a FiTech EFI system. FiTech warrants its products
against de ects in materials and workmanship or one year rom the date o original purchase. This applies only to the original
purchaser and the parts must remain installed on the original vehicle or which they were purchased. This warranty is void i the
product was improperly installed, was installed on a vehicle or which it was not designed, i it was modified in any manner, or
was removed rom the original vehicle and reinstalled on another vehicle.
This warranty shall not apply to any product installed on a racing vehicle, installed im-properly, or contrary to FiTech's
instructions, altered, misused, repaired/damaged rom an accident, collision, or will ul or negligent act. To make a claim under the
terms o this Warranty, the original purchaser must return the product to FiTech along with proo o original purchase. Purchaser
must call FiTech (951-340-2624) or email to: Warranty@ iteche i.com, to obtain a Returned Material Authorization (RMA). Proo
o purchase must clearly show the place o purchase, purchase price, product purchased and date o purchase.
I , upon inspection, FiTech determines a de ect in materials or workmanship, FiTech will re und the returned goods shipping
expense, and replace the de ective part or parts with a new part or parts.
FiTech's liability is expressly limited to the payment o shipping costs and replacing the de ective part or
parts. FiTech will
have
no liability or the cost o installation, removal o the de ective product, or the cost o labor, or any
additional parts required to complete the installation o the replacement product.
In no event will FiTech be liable or any indirect, special, incidental, or consequential losses or damages
(including but not limited to interruption o business or loss o business or pro it) resulting rom the use or inability to use the
product, any breach o warranty, or any de ect in the product, even i FiTech shall have been advised o the pos-sibility o such
potential damages or losses. Some states do not allow the exclusion or limitations o incidental or consequential damages, so
the above limitation or exclusion may not apply to you. This warranty gives you speci ic legal rights. You may also have other
rights which vary rom state to state.
51001-51004 instructions 6/23/2020
California Proposition 65 warning
This product may contain one or more substances or chemicals known to the state of California
to cause cancer, birth defects, or other reproductive harm
