Flash F7100109 Produkthandbuch

380W Beam/Spot/Wash Moving Head

Manual Book

（Color display, touch screen）

Please read this manual carefully before your operation.

Catalogue

I Notice and Setup.......................................................................................................3

1. Maintaining......................................................................................................3

2. Statement..........................................................................................................3

3. Notice..............................................................................................................3

4. Parameter.........................................................................................................3

5. Signal connection（DMX）............................................................................4

6. Item installation................................................................................................4

II Menu operation..........................................................................................................5

1. Summary...........................................................................................................5

2. Operation...........................................................................................................6

1. Control item by touch screen or console...................................................6

2. Value input.................................................................................................6

3. Setup value.................................................................................................6

4. Sbupage（parameter）..............................................................................6

3. Function operation and parameter setup............................................................7

1. Setup DMX address code...........................................................................7

2. Setup work mode........................................................................................8

3. Setup menu display.....................................................................................9

4. Test............................................................................................................10

5. Setup work parameter...............................................................................10

6. Check current status..................................................................................11

III Channel description..................................................................................................12

1. Channel list.......................................................................................................12

IV Normal faulty and using attention .........................................................................15

1. Normal faulty solution............................................................................15

2. Using attention.......................................................................................16

I Notice and setup

1. Maintaining

Keep dry, don’t use it in wet environment.

Intermittent using can extend the life of item.

Please often clean fan, fan net and lens to get better cooling and brightness effect.

Please don’t clean the cover with solvent like alcohol.

2. Statement

To be on the safe side and under the terms of the security, do not allow to restructure and modify this product.

Please note that because of man-made damage caused by improper use, is beyond the scope of our warranty.

This equipment pass strict inspection before shipment, please comply with the instruction manual operation

requirements, to ensure the safe operation of the product under normal conditions. Any damage caused by

improper operation, will cause the cessation of the warranty claim. Manufacturer does not accept any because of

improper operation products or non-compliance of the instructions of any liability for property damage and

personal injury.

Please place the manual in safe place for future reference and in products for sale or lease or handling running new

holder.

3. Notice

Do not operate when temperature up to 60°

Make sure the equipment load-bearing structures can withstand the weight of more than 10 times when

above ground installation.

Only professional technique can repair this item to avoid the dangerous of electric shock.

The power voltage difference can’t be more than10% when the lamp works. Higher voltage

can short the life of lamp and lower voltage can reduce the brightness.

Cool down for 20 minutes before restart it again

Please read this notice carefully before your operation.

4. Parameter

Lamp power：350/380W；

Power consumption：500W；

Power supply：High efficiency is upon switch power supply；

Color wheel：one color wheel，10 colors +open；

Gobo wheel：one fixed gobo wheel, 13 gobos; one rotation gobo wheel, 7 rotated gobos；one

effect wheel, 5 effect gobos

Prism wheel：one rotated 8 prism and one 16 prism；

Dimmer：0-100% electric dimmer；

Bigger adjustable range of beam angle；

Strobe：Mechanical strobe and can adjust speed，support Macro function of strobe；

Channel: 23/28CH

Lens optical system，electrical focus，beam angle: 3.8°-53°linear adjustment；

Use photo-electricity reset system, self-correction；

Pan 540°，8Bit/16Bit；

Tilt 270°， 8Bit/16Bit；

Over temperature protection；

Control mode：DMX512/Master-slave/auto-run；

IP grade：IP20；

5. Signal connection（DMX）

Use standard RS-485cable：with shield, 120ohm characteristic impedance, 22-24 AWG ,low

capacitive reactance. Don’t use microphone care or other characteristic cable. Use 3 or 5 XLR

pin for connection. Must insert one 120ohm impedance matching resistance (lowest power is

1/4W) between 2 and 3 of terminal of end plug.

Importance reminder：Cable can’t be mutual contaction or touch metal cover.

Picture 1 Schematic diagram of DMX signal connection

6. Installation

Light can be installed horizontal, hung and hung upside down. Please pay attention to

installation method for hang and hang upside down. .

Like picture 2，please insure the stabilization of installation site before item position, and

please use clamps and safety rope for reversal hang installation.

During the installation and test, nobody can pass under light. Please regularly check if the

safety rope is damaged or not and screw of clamps is loosed or not.

Our company don’t respond for all the consequences because of faulty installation.

Picture 2 Reversal hang show

II Menu operation

1. Summary

Like picture 3（it’s 4 keys in this picture），left is TFT display that support touch operation;

right is 4 keys or 5 keys or encoder knob, you can control light directly or setup system parameter

by them.

Display and operation likes Android system. You can operate item by fingers if you choose

the item with touch screen.

Note：Don’t use sharp thins to touch display.

Picture 3 Display

2. Operation

1. Control item by touch screen or console

The left is TFT display and touch area. You can setup the parameter or check status by

touching menu contents.

The right is rotary encoder. Please swirl encoder to setup or check menu if you don’t use TFT

touch screen.

2. Value input

When the chosen parameter needs value input, the windows will be opened like picture4:

Picture 4 Value setup

Set value：can move slider to set needed value fast, also can click UP or DOWN

right-side or swirl the encoder to set value.

Use value：After setup, please press “apply”key at left bottom, then the value is sent to

light without saving.

Save value：Press “Enter”at right bottom to save setup anytime.

3. Value setup

When the value is ON or OFF, please click the corresponding item to change parameter

values, and it will be saved inside storage directly. Press parameter options on right, the

corresponding item will become to gray. Once release it, the item will be changed and saved.

If you don’t want to change parameter, please move fingers to other place on screen.

The important boole parameter will be changed by windows like Picture 5 as following:

Picture 5 Sure input windows

4. Subpage（parameter）

Press primary menu to get into submenu. There are 6PCS subpage with different parameter or

status as picture 6:

ADDRESS：set the DMX add；

WORKMODE：set the work mode, master/slave mode ;

DISPLAY：Set the parameter on display, like language, screen protection;

TEST：For lighting test, simulate the value of corresponding DMX channel；

ADVANCE：set operating parameter；

STATUS：check current status.

Picture 6 Submenu

3 Function operation and parameter setup

Get into menu like picture 6:

In primary menu, can get into corresponding submenu by touching 6 different button.

Press left blue option can change to other interface fast.

1. Set DMX address code

Press and choose “ADDR”to get into the set page. The range of address code is 1-512, the

code can’t be bigger than 512, otherwise, the light can’t be controlled. The detail is as

following:

Get into the DMX interface like picture 7, click the right white area, then the parameter set

windows is opened like picture 4. Please pull the red blocks of progress bar to set DMX address

code, or set code by touch “UP”and “DOWN”keys; then press ENTER to save code.

Picture 7 Add set page

2. Set work mode

Please set the work mode, control lamp and channel mode like picture . The light has four

mode-DMX mode, auto run mode, sound active mode and master/slave mode. The detail

parameter is as following:

DMX Mode：In this mode, the light can receive the data from controller and run

according to it（Common mode）；

Auto run mode：In this mode, the light will run according to the inner programme；

Sound active mode：In this mode, the light is controlled by the strong sound.

Master/slave mode：The master/slave choice only can be used in auto run mode or sound

active mode. When this mode is closed, the inner date can’t be transferred to other

lights by DMX signal line; when it is on, the inner data of master item will be sent to

slave item, then slave item will follow the master item.

Lamp ON/OFF：This function can control the lamp’s ON/OFF. The frequency ON/OFF

can reduce the life of lamp. The defined time interval is 30 seconds.

Channel mode：There are two channel mode-simple and extend mode. The simple mode

reduce several motor speed channel to save the use ratio.

Picture 8 Run mode windows

3. Set menu display

There are two language-Chinese and English like picture 9.

Langudge：Choose Chinese or English language

Screen Saver：If there is no change in 10 seconds, the light will be screen saver. When

light is in “Mode 1”, the screen is closed(black screen); when item is in “Mode 2”, the

screen will show DMX address code(DMX mode) or show icon( auto run or sound active

mode); when screen is “OFF), there is no screen saver, just show main menu.

Screen Rotion：When the light was hung upside down, please choose this option to make

menu more clearer.

Touch screen switch：If this is “OFF”, then you can’t use the touch screen. Only the

encoder knob is useful.

Touch screen revise：Press this option to adjust the precision of screen. Normally please

don’t get into this option.

Picture 9 Display setup

4. Test

The light is on test mode like picture 10. The lights don’t receive the DMX controller’s

date.The parameter on menu is related to the DMX channels value and you can control the light

run by changing value. The detail value is as following:

Pan motor：Value（0~255）；

Tilt motor：Value （0~255）；

FOCUS motor：Value（0~255）；

COLOR：Value（0~255）；

GOBO：Value（0~255）；

PRISM：Value（0~255），when the prism is inserted, the prism rotation is on;

FROST：Value（0~255）；

STROBE：Value（0~255）.

Picture 10 Test Mode

5. Setup work parameter

Get into page like picture 11, can adjust the scene parameter to make easier installation.

Pan Invert：exchange the initial position and final position of Pan motor ；

Tilt Invert：exchange the initial position and final position of Tilt motor ；

Optocoupler correction：If you choose this function, the Pan or tilt motor will self-correct if

there is off normal；

Pan Offset：set deviation angle of X motor initial position；

Tilt Offset：set deviation angle of Y motor initial position；

Lamp up when：Set on-off state of lamp when power is on；

Factory setting：Set all parameter to be factory value.

Inhaltsverzeichnis

Andere Flash DJ-Equipment Handbücher

Flash

Flash F7100520 Bedienungsanleitung

Flash

Flash F7000251 Bedienungsanleitung

Flash

Flash F7300240 Bedienungsanleitung

Flash

Flash DIAMOND ROTO PRISM Bedienungsanleitung

Flash

Flash LASER 10W RGB GOBO Bedienungsanleitung

Flash

Flash LED MOONTH FLOWER LIGHT Bedienungsanleitung

Flash

Flash F7100499 Bedienungsanleitung

Flash

Flash F7100315 Bedienungsanleitung

Flash

Flash LIGHT BOX MOON 1 Bedienungsanleitung

Flash

Flash F7100496 Bedienungsanleitung

Flash

Flash F7300215 Bedienungsanleitung

Flash

Flash F7100503 Bedienungsanleitung

Flash

Flash BEAM Moving Head 15R Bedienungsanleitung

Flash

Flash Virtuoso 420 Bedienungsanleitung

Flash

Flash F7100310 Bedienungsanleitung

Flash

Flash LED Spyder Mini Moving Head 8x15W 4in1 RGBW- No Limit... Bedienungsanleitung

Flash

Flash BEAM 2R Moving Head Bedienungsanleitung

Flash

Flash F7100495 Bedienungsanleitung

Flash

Flash F7100305 Bedienungsanleitung

Flash

Flash F7200169 Bedienungsanleitung

Flash

Flash FL-202 BEAM 5R Bedienungsanleitung

Flash

Flash F7100545 Bedienungsanleitung

Flash

Flash Spyder 3-HEAD Bedienungsanleitung

Flash

Flash F1000501 Bedienungsanleitung

Beliebte DJ-Equipment Handbücher anderer Marken

ALPHA LITE

ALPHA LITE ALPHA 1500 Betriebsanleitung

Chauvet

Chauvet OVATION E-930VW Bedienungsanleitung

Zumtobel

Zumtobel APHRODITE Home Bedienungsanleitung

Snow Masters

Snow Masters Zig Oscillator Bedienungsanleitung

EuroLite

EuroLite 50530554 Bedienungsanleitung

Beamz

Beamz BUV243 Bedienungsanleitung

thomann

thomann Stairville DJ Lase 40-G MK-III Bedienungsanleitung

Eagletone

Eagletone 6 Eyes Flower Bedienungsanleitung

EuroLite

EuroLite FLD-1508 Bedienungsanleitung

Technical Pro

Technical Pro LG8xSEA Bedienungsanleitung

JB Systems

JB Systems Lounge Laser DMX Bedienungsanleitung

Lightmaxx

Lightmaxx Vega Halo 90 Bedienungsanleitung

Elation

Elation FUZE WASH Z350 Bedienungsanleitung

Maverick

Maverick MK3 WASH Bedienungsanleitung

Infinity

Infinity TF-260C7 Fresnel Bedienungsanleitung

Chauvet

Chauvet EVE E-50Z Bedienungsanleitung

Eliminator Lighting

Eliminator Lighting E 138 Bedienungsanleitung

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Bedienungsanleitung
