Flashforge Finder Montage- und Wartungsanleitung

————————————————————————————————————————————

Start Up and Instruction Guide

Seller information

Seller Name: FlashForge 3D Printer

Amazon Storefront: www.amazon.com/shops/A8RK4QCP0IFCY

Support Contact: Mr. Tang

E-mail: 597891915@QQ.com

————————————————————————————————————————————

FlashForge Finder Start-up Guide

Content

Unpacking Your Finder........................................................................................................................ 2

Hardware Assembly............................................................................................................................ 4

Place spool into cartridge............................................................................................................4

Filament Loading and Unloading................................................................................................ 4

Loading Filament.................................................................................................................4

Unloading the filament....................................................................................................... 5

Leveling the Build Plate...............................................................................................................5

Software Configuration....................................................................................................................... 7

FlashPrint Installation..................................................................................................................7

Exploring FlashPrint.....................................................................................................................7

Printing.............................................................................................................................................. 16

Testing with USB Stick Sample.................................................................................................. 16

Printing over USB...................................................................................................................... 17

USB connection................................................................................................................. 17

Create a Gcode.................................................................................................................. 17

Print over USB................................................................................................................... 20

Printing over Wifi...................................................................................................................... 20

Wifi Configuration............................................................................................................. 20

WIFI Connection between FlashPrint and Finder.............................................................23

Firmware Update...............................................................................................................................23

————————————————————————————————————————————

Unpacking Your Finder

1. Place the packaging box on a clean work surface. Open the box, grasp the two handles and

then lift your Finder out of the box.

2. Removing the protective foam sheets at two sides, you will see the Finder in a transparent

nylon bag. Then remove the bag to unveil the Finder.

3. On the top foam sheet, you can see the Quick Start Guide, 4GB USB stick, three Allen wrenches

(M1.5, 2 and 2.5) and one screwdriver.

4. Removing the top foam sheet, you will see the extruder and X-axis guide rods which are held

————————————————————————————————————————————

with buckles. Use scissors to cut them off to release the X guide rods. Discard the blue tape that

holds the flat cable in place.

5. Taking the protective foam for filament out of the Finder, you will see a spool of PLA filament

inside. Filament color is randomly selected.

6. Then you will see the build plate. The build plate pasted with a blue build plate tape is ready

for direct use. In the grooves at both sides, you will see a filament guide tube, a power cable and

a USB cable. Move the build plate up. Remove the protective foam and take the power cable and

USB cable out.

You have now unpacked your Finder successfully.

————————————————————————————————————————————

Hardware Assembly

Your Finder has been almost assembled before leaving factory; you can start up the Finder for

printing after mounting the filament spool and completing leveling.

Place Spool into Cartridge

Remove the filament cartridge in the rear of Finder, where you place the filament spool. Thread

the filament through the filament guide tube. Note: You should ensure the filament spool rolls

anticlockwise.

Filament Loading and Unloading

Connecting Power Cable

Insert the power supply into the power input on the back of the Finder and plug the power cord

into an electrical outlet.

Loading Filament

Turn on your Finder by clicking power button at the right side of the touch screen.

Then tap [Tools]--[Filament]--[Load]. Extruder is heating up. After the extruder reaches 220℃,

the printer will sound a beep to prompt you to load the filament into the extruder. Press the

spring presser down and insert the filament into the extruder at an upright angle. Within a few

seconds, you should see an even string of plastic coming out from the extruder nozzle.

Note: Your Finder will sound a warning when the filament is running out; you should feed your

Finder in time.

————————————————————————————————————————————

Unloading the filament

1. Tap [Tools]--[Filament]--[Unload]. After the extruder reaches 220℃, the printer will sound a

beep to prompt you to unload the filament from the extruder. Keep pressing the spring presser

down, push filament in a little first until you see melted plastic coming out from nozzle end, then

gently pull the filament out.

Note: Do not pull out the filament with force as it will damage the gears. If the melted filament

has cooled down in the extruder, please repeat the steps above.

Leveling the Build Plate

1. Tap [Tools] - [Level] on your Finder touch screen. Please wait while the extruder and platform

finish initial movements. Screw three nuts under the platform anticlockwise until you can’t

tighten them any more, then tap [OK] button. On the next pop-up dialog, tap [Yes] if you can’t

finger tighten all the nuts any more, or tap [No] to continue tightening.

2. After tapping [Yes] button, the extruder starts to move towards the first point and the plate

moves up and down to verify the distance between nozzle and plate. If distance too big, please

————————————————————————————————————————————

unscrew the corresponding nut under the platform clockwise until hearing a steady beep and the

[Verify] button appears.

3. Tap [Verify] to check whether the distance is appropriate now. If distance too small, please

screw corresponding nut under platform anticlockwise until hearing a steady beep and the

[Verify] button appears again. Tap [Verify] to check whether the distance is appropriate this time.

4. If the distance is appropriate till now, Tap [OK] to second point leveling. If still not, please

follow the prompts to adjust again till you see [OK] button.

————————————————————————————————————————————

5. Repeat steps 2 through 4 above to complete second and third points leveling and then Tap

[Finish] to exit.

Software Configuration

FlashPrint Installation

Where to get FlashPrint installer

Method 1: To get the installation package from the provided USB stick come with the Finder.

Method 2: Contact Mr. Tang at [email protected] for download link of latest FlashPrint.

1. Decompress the zip and complete installation according to the prompted instructions step by

step.

2. Start the software with the start menu shortcut or by double clicking the software icon.

Exploring FlashPrint

Selecting the machine type

After starting Flashprint, you need to select the target machine type first.

When you start Flashprint, a dialog box will pop up. Just need to select FlashForge Finder in the

machine type list and click [OK]. You can also change the machine type via clicking

[Print]--[Machine type]. Please see graphic below:

————————————————————————————————————————————

Load

You can load a model file or Gcode file into your FlashPrint by the following six methods:

Method 1: Click the Load icon on the main interface. Then select the object file.

Method 2: Select the file for loading and drag the file to the main interface of the software.

Method 3: Click [File]--[Load File]. Then select the object file for loading.

Load: Load one or multiple files.

Supports: Enter the support edit mode

View: View FlashPrint home screen from one of six viewing angles.

Move: Move model around on xy-plane; shift+click to move along z axis

Rotate: Turn and rotate your model

Scale: Scale the size of your object

Cut: Cut the model into pieces

Print: Print it directly with your Finder or export to your SD card.

————————————————————————————————————————————

Method 4: Click [File] --[Examples] to load the example files

Method 5: Click [File] --[Recent Files] to load the files opened recently.

Method 6: Select and drag the target file to the icon of FlashPrint.

Files with extension .STL, .OBJ, and .FPP, are supported by FlashPrint for editing.

View

Set View

Allows users to view the object on the build plate. Six views are under the view menu, that is,

home view, bottom view, top view, front view, back view, left view and right view.

Method 1: Click the [View] menu, there are six views in the drop- down list

Method 2: Click the [View] icon on the left, click it again and a submenu will appear with six

views for selecting.

Reset View

Allow users to reset views by the following two methods:

Method 1: Click the [View] menu and select [Home View]

Method 2: Click the [View] icon on the left, click it again and you will see the viewing options, you

can click [Reset].

Show Model Outline

Click [View] menu--[Show Model Outline], it will highlight the yellow border of the object

Show Steep Overhang

Click [View] menu--[Show Steep Overhang]. When the intersection angle between the model

surface and horizontal line is within the overhang threshold value, the surface has steep

overhang and it becomes red in the software. Overhang threshold value could be set as needed.

The default value is 45 degree.
