Technical Data

Fluke 1555 and

1550C Insulation

Resistance Testers

Fluke insulation testers can now conduct the entire range of test

voltages specified in IEEE 43-2000 with a best in class, 3 year

warranty and CAT IV 600 V safety rating. With measurement storage

and PC interface, the 1555 and 1550C are perfect tools for pre-

ventative or predictive maintenance programs designed to identify

potential equipment failures before they occur.

Features include:

• Test voltages to up 10 kV provides solutions for all applications

• CAT III 1000 V, CAT IV 600 V safety rating

• Warning function alerts the user that line voltage is present and

gives the voltage reading up to 600 V ac or dc for increased user

safety

• Selectable test voltages in 50 V steps from 250 V to 1000 V, and

100 V steps above 1000 V

• Measurements can be stored in up to 99 memory locations, with

each location assigned a unique, user defined, label for easy

recall

• Long battery life gives the user over 750 tests between charges

• Automatic calculation of Dielectric Absorption (DAR) and

Polarization Index (PI) with no additional setup

• Guard system eliminates the effect of surface leakage current

on high-resistance measurements

• Large digital/analog LCD for easy viewing

• Capacitance and leakage current measurement

• Ramp function for breakdown testing

• Resistance measurements up to 2TΩ

• Timer settings up to 99 minutes for timed tests

• 3-year warranty

Digital insulation testing

up to 10 kV

The new Fluke 1555 and redesigned Fluke

1550C insulation resistance testers, offer digital

insulation testing up to 10 kV, making them

ideal for testing a wide range of high voltage

equipment including switchgear, motors,

generators and cables.

2 Fluke Corporation Fluke 1555 and 1550C Insulation Resistance Testers

Ordering

information

1550C 5 kV Insulation Tester

1555 10 kV Insulation Tester

1550C/Kit 5 kV Insulation Tester Kit

1555/Kit 10 kV Insulation Tester Kit

Optional accessories

TL1550EXT 25 foot extended

test lead set

Included accessories

Test Cables with Alligator Clips

(red, black, green)

Infrared adapter with interface cable

FlukeView Forms Basic CD-ROM

AC Power Cord

Soft Carrying Case (base models only)

English Manual

Users Manual on CD-ROM

Quick Reference Card

Software License Agreement

Registration Card

FlukeView Forms Installation Guide

USB-IR Cable Installation Guide

IP67 Hard Case (kit only)

Certificate of Calibration (kit only)

Ruggedized Alligator Clips

(kit and 1555 only)

Software specifications

Fluke ViewForms basic software

requires a PC running Windows 2000,

Windows XP and Windows Vista.

Specifications

Electrical specifications

The tester’s accuracy is specified for one year after calibration at operating

temperatures of 0 °C to 35 °C. For operating temperatures outside the range

(-20 °C to 0 °C and 35 °C to 50 °C), add ± .25 % per °C, except on the 20 %

bands add ± 1 % per °C.

Insulation resistance measurement

Test voltage (dc) Range Accuracy (± reading)

250 V < 200 kΩ

200 kΩ to 5 GΩ

5 GΩ to 50 GΩ

> 50 GΩ

unspecified

5 %

20 %

unspecified

500 V < 200 kΩ

200 kΩ to 10 GΩ

10 GΩ to 100 GΩ

> 100 GΩ

unspecified

5 %

20 %

unspecified

1000 V < 200 kΩ

200 kΩ to 20 GΩ

20 GΩ to 200 GΩ

> 200 GΩ

unspecified

5 %

20 %

unspecified

2500 V < 200 kΩ

200 kΩ to 50 GΩ

50 GΩ to 500 GΩ

> 500 GΩ

unspecified

5 %

20 %

unspecified

5000 V < 200 kΩ

200 kΩ to 100 GΩ

100 GΩ to 1 TΩ

> 1 TΩ

unspecified

5 %

20 %

unspecified

10000 V (1555 Only) < 200 kΩ

200 kΩ to 200 GΩ

200 GΩ to 2 TΩ

> 2 TΩ

unspecified

5 %

20 %

unspecified

Bar graph range 0 to 1 TΩ

Insulation test voltage accuracy -0 %, +10 % at 1 mA load current

Induced ac mains current rejection 2 mA maximum

Charging rate for capacitive load 5 seconds per μF

Discharge rate for capacitive load 1.5 s/μF

Range Accuracy

Leakage current

measurement

1 nA to 2 mA ± (5 % + 2 nA)

Capacitance measurement 0.01 uF to 15.00 μF ± (15 % rdg + 0.03 μF)

Timer Range Resolution

0 to 99 minutes Setting: 1 minute

Indication: 1 second

Live circuit warning Warning range Voltage accuracy

30 V to 660 V ac/dc, 50/60 Hz ± (15 % + 2 V)

General specifications

Display 75 mm x 105 mm

Power 12 V lead-acid rechargeable battery, Yuasa NP2.8-12

Charger Input (AC) 85 V ac 50/60 Hz 20 VA

This Class II (double insulated) instrument is supplied with a Class 1 (grounded) power cord. The protective earth terminal

(ground pin) is not connected internally. The extra pin is for added plug retention only.

Dimensions 269 mm x 277 mm x 160 mm (10.6 in x 10.9 in x 6.3 in)

Weight 3.7 kg (8.2 lb)

Temperature (operating) -20 ºC to 50 ºC (-4 ºF to 122 ºF)

Temperature (storage) -20 ºC to 65 ºC (-4 ºF to 149 ºF)

Humidity 80 % to 31 ºC decreasing linearly to 50 % at 50 ºC

Altitude 2000 m

Enclosure sealing IP40

Input overload protection 1000 V ac

Electromagnetic compatibility EN 61326

Certifications

Safety compliance EN 61010, EN 61557 Parts 1 and 2, IEC 61010-1,

CAT III 1000 V, CAT IV 600 V

Polution degree 2
