Flycam Galaxy Stabilizer Arm & Vest Bedienungsanleitung
Instruction Manual
Galaxy Stabilizer Arm &
Vest (GLXY-AV)
2
Subject Page
Foreword 3
Introducon 4
Safety Hints 5
Assembling 5-7
Warranty 8
At Flycam, our goal is to ensure 100% Customer Sasfacon in all that we do.
We back our sales with a 1 year warranty from the date of purchase and work hard
to resolve any problems in the unlikely event one should arise.
With our commitment to connuous improvement and your Feedback, building on
our reputaon of providing aordable, quality products is
PRIORITY #1.
Table of Contents
3
Dear Client,
On behalf of all the people that work so hard to provide you with the most
up-to-date, exible and cost-ecient producon gear, we would like to welcome
you into the Flycam family.
By purchasing your Galaxy Stabilizer Arm & Vest, you have just joined a host of
designers, engineers, machinists, assembly, customer service and oce sta that
take great pride in all that they do. Our mantra of connuous improvement has
been the guiding principle of how we conduct our business since day one.
Once you have the opportunity to experience your new Galaxy Stabilizer Arm &
Vest, we hope you will agree that we cra quality products at a compeve price.
Products designed to meet and exceed the standards of today’s real producon
world.
Standards set by our valued clients and standards we strive to maintain.
With Best Wishes,
Flycam Team
Welcome To ycam!
4
Introducon
The Most Commendable, Stable, versale, lightweight and aordable Vest/Arm
stabilizaon system by Flycam oers your camera stabilizer to shoot professional &
smooth tracking videos. Flycam Arm and Vest for video stabilizer allow capturing
unparalleled dynamic shots without ring your arms. The Comfort t units provides
fague free shoong and allow the camera operator to walk, run, go up and down
stairs, shoot from moving vehicles, and travel over uneven terrain without any
camera instability.
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received
everything that is listed below.
Locking buckles
Soen shoulder
padding
Arm connector
Soen shoulder
padding
Height adjustment
knob
Flexible joint
Tension adjustment knob 2pc Heavy Tension
Spring(Red & Blue)
1 x 16mm Plasc Bush
1 x 19mm Plasc Bush
1x 3mm Allen key
5
Assembling
Having put your vest on, insert the
hooks of the 26’’ long straps into the
appropriate aluminum buckle.
Tighten both straps with Velcro for a
comfortable t and lock both with the
aluminum buckles.
The length of the chest plate can be
adjusted according to the height of the
person by using this adjusng screw.
6
Our Flycam GALAXY Vest can be used
with all professionals arms incl.
Steadicam, Tin, Glide cam and
Sachtler.
Loosen the knobs & insert the male part
of the socket aached to the Flycam
GALAXY Arm into the female part of the
socket aached to the vest.
Loosen the knobs & insert the male part
of the socket aached to the Flycam
GALAXY Arm into the female part of the
socket aached to the vest.
NOTE: Properly set up and custom t, your vest should look like the provided picture.Straps are
mode of through nylon and industrial strength Velcro and can be easily replaced or adjusted
to suit individual needs.
7
ARM ADJUSTMENT : The arm tension is adjusted for the heaviest camcorder it can hold so it
does not bottom out when you put the camcorder and sled on the arm for the first time. Now
adjust the arm for the weight of your camcorder :
With the vest on, attach the arm & undock the rig.
Move the arm to the middle of its booming (up and down range) and let go. (If it stays where
it is, you are probably close to the right adjustment)
Keep making small adjustments until the camcorder does not rise or fall when you let go of it in
the middle of its booming range.
Position the arm :
Move the camcorder to your left so the arm crosses your body.
Adjust the arc of your arm so the rig feels comfortable to you.
Keep the camcorder close to your body.
For Interchanging the spring, Follow this video
hps://bit.ly/2pX67IZ
MAINTENANCE
Bearing Maintenance : The Flycam GALAXY Arm contains the bearings. If aer some period of
me your bearings don’t turn smoothly as when new, you can oil it lightly with light lubricang
oil. We recommend that you use a minimum amount. Only a few drops are required, plus
anything more than a lile will end up dripping from the bearing and onto the rest of your Galaxy
Arm . Be sure to keep the oil away from your Camera, and clean up any over spill when done.
Cleaning: Do not use solvents or harsh cleaners of any kind on your Flycam Galaxy Arm & Vest. If
the unit becomes dirty, use only a cloth or sponge with water and a very mild detergent to gently
rub the unit clean. Rinse well.
If you are unable to nd an environment like this, then we suggest you store the unit in an
airght plasc container or bag. Standing the unit upright helps to alleviate stress on the system.
Storage: If you are going to store your Flycam Galaxy Arm & Vest for a long period of me then
please store the unit up right in a dry or low to normal humidity area whenever possible.
8
YOUR FLYCAM GALAXY STABLIZER ARM & VEST
ALL DRESSED UP AND READY TO GO!
WARRANTY
We oer a one year warranty for our products from the date of purchase.
We will repair or replace your product, free of charge, in the event of a defect in materials or
crasmanship obtained during normal use or handling based on the user manual. Please note
that we will not cover any shipping costs for returning the product to us. If any VAT or import
dues are applied to the return, we will also charge these costs to the customer.
The warranty does not include, by the way of example, damage caused by products that we do
not supply or from mishandling in transit, accident, misuse, neglect, lack of care of the product ,
or service by anyone other than our company.
We are not liable for incidental or consequenal damages resulng from the use of the unit or
occurring due to any breach of this warranty.
Replacement parts of the product will be provided at nominal cost (covering the cost price of the
replacement parts only) to the customers aer the Warranty Period has expired. We will cover
the complete cost of sending replacement parts within the warranty period. Aer that, Nominal
cost of the product & Actual shipping cost will be charged.
Do not send the unit to us without rst geng a response and geng the approval to send back
the item.
In case of any kind of dissasfacon, we urge you to Contact us immediately and we shall do our
Best to help you out. For any other assistance you can reach us via email.
For any other assistance you can reach us via email.
(SHOWN WITH OTPIONAL ACCESSORIES)
