Flycam FLCM-5000-Q Bedienungsanleitung

Instruction Manual

5000 Handheld Video

Stabilizer (FLCM-5000-Q)

At Flycam, our goal is to ensure 100% Customer Sasfacon in all that we do.

We back our sales with a 1 year warranty from the date of purchase and work hard

to resolve any problems in the unlikely event one should arise.

With our commitment to connuous improvement and your Feedback, building on

our reputaon of providing aordable, quality products is

PRIORITY #1.

Subject Page

Foreword 3

Introducon 4

Safety Hints 5-6

Assembling 6-11

Balancing 11-15

Warranty 16

Table of Contents

Dear Client,

On behalf of all the people that work so hard to provide you with the most

up-to-date, exible and cost-ecient producon gear, we would like to welcome

you into the Flycam family.

By purchasing your 5000 Handheld Video Stabilizer , you have just joined a host of

designers, engineers, machinists, assembly, customer service and oce sta that

take great pride in all that they do. Our mantra of connuous improvement has

been the guiding principle of how we conduct our business since day one.

Once you have the opportunity to experience your new 5000 Handheld Video

Stabilizer , we hope you will agree that we cra quality products at a compeve

price. Products designed to meet and exceed the standards of today’s real

producon world.

Standards set by our valued clients and standards we strive to maintain.

With Best Wishes,

Flycam Team

Welcome To Flycam!

Central Post

Base Plaorm with 16

weight discs

Handle

Introducon

Flycam 5000 is a precise camera stabilizer which helps you in geng the stable and

smooth gliding movements with absolutely zero shakes. It allows you to make fast

moves while following quick acons. Thus it is easy to operate and best for travel

shoong, events, and video producons.

Please inspect the contents of your shipped package to ensure you have received

everything that is listed below.

What’s In The Box

Head Plate Boom Plate

Mid Plate

Head Assembly (These three individual pieces are shipped as one assembled unit)

Table Clamp

Quick release

adapter Lever to remove /

aach the quick release

Unico Quick Release Adapter

V-shape Adapter (to aach

Camera to Head Plate)

Note: A locking pin located at the front prevents camera rotaon.

Storage Bag

Safety Hints

ATTENTION: PLEASE READ THIS BEFORE USING TO PREVENT SERIOUS DAMAGE TO

THE GEAR!

BE HIGHLY VIGILANT OF SURROUNDINGS

Check the area you will be shoong in, before shoong. Make sure your path is

clear. Look for obstacles and note anything you might run into or trip over. Extra

care is also necessary when tackling stairs and other kinds of uneven ground.

ALWAYS WEAR PROTECTIVE GEAR

If you intend to shoot while moving fast or while traversing uneven terrain, do not

hesitate to wear protecve gear as knee or elbow pads, or a helmet.

DO NOT SHOOT IN UNSAFE CONDITIONS

Avoid situaons where one commonly falls like skis, skates or running in muddy

elds.

ADULT SUPERVISION IS RECOMMENDED

Minors using this product should have adult supervision.

FOLLOWING THESE GUIDELINES WILL PROVIDE BETTER SHOTS AND TROUBLE-FREE

OPERATION.

SHOULD YOU NEED ADDITIONAL INFORMATION, TECHNICAL ASSISTANCE IS

AVAILABLE ‘ONLINE’ BY CONTACTING YOUR SALES REPRESENTATIVE

 Loosen allen bolts at the boom of Camera Plate, align its holes with the top of Central Post &

re-ghten them securing the plate to post.

NOTE: The adjustment knob should only be

ghtened by hand. Do not over-ghten it as

it could cause thread stripping.

Assembling

 A threaded stud is located in the center of Base Plaorm for aaching Central Post. Securely

ghten the adjustment knob on telescoping clamp by rotang it clockwise.

 Remove Head Plate by unscrewing the

four side knobs to mount Quick Release

Adapter.

 Then aach Head Plate to stabilizer with appropriate fore & a posioning and ghten all

four side knobs, as shown. Further ne tuning will probably be required.

 Loosen allen bolt at the boom of Quick Release Adapter and aach it to Head Plate.

 Open the lever and remove Quick Release Plate from Adapter. Then aach it with your

camera with the help of screw driver.

 Insert your camera setup with Quick

Release Plate into the Adapter and

ghten the lever back.

 Remove Head plate from 3-piece Head

Assembly in order to aach it to your

camera. You will note a number of

mounng holes that can be used to

adapt various cameras.

NOTE: If you wish to bypass Quick Release Plate, the camera can be directly aached to Head

Plate by following this assembly sequence:

 Keep the camera in center of Head Plate

and secure it properly.Do not over

ghten this adjustment as it can break

the threaded insert.

H ea d Pl a t e X a dj u st m en t

 The many slots located on Head Plate and Boom Plate allows you to easily adjust X & Y

Axis for perfect balance.Place the assembly in line with the center of stabilizer post and

ghten the side adjusters, as shown. Further ne tuning will probably be required.

H ea d Pl a t e Y a dj us t m en t

Connuing the assembly and balance requirements to make your Flycam Handheld Video

Stabilizer fully funconal you will note that the base plaorm has a provision to mount the

balance weights in their cups via a slot found on both sides of the post.

The purpose of the counter weight system is to match the low end of the stabilizer to the weight

of the camera and accessories at the high/top end with the gimbaled handle as the pivot point in

between.

The heavier the camera and accessories, the more weights are required to achieve proper

balance. Generally as you add weight to one side of the central post, an equal amount has to be

added to the other side to maintain horizontal balance.

However if you are using an oset conguraon such as a ip out viewnder or o center

accessories, extra weights might be needed on the opposite side of the post to counter act and

maintain proper balance.

Total weight xed to the base plaorm should be equal to the weight of your camera plus the

head and any accessories.

Adding Weights & Posioning for Proper Balance

Horizontal adjustment on base plaorm is made by loosening the retaining screws and

moving counterweight plates closer to or farther away from post and then re-ghtening. You

will probably need to adjust and re-adjust the horizontal posion to achieve opmum

performance.

NOTE: When adding weight in cups, use the supplied foam spacers as silencers to prevent metal

to metal washer noise.
