What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
Flowline Edge Stabilizaon Arm (FLCM-EDGE-01)
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Assembly Manua l
Flycam Flowline Edge Stabilizaon Arm
6 Meter Rope
2.5mm Allen Key Grub Screw
2
• Loosen the screw of the camera hook
from owline N series (Note-Included)
using an Allen key and une the cord
(Note-Included) knot from the cord lock
as shown in the image.
Flowline Edge Setup
• Remove the camera hook cup from the
cord. Aach another cord (Note-
Included) with the original cord so that
the second cord goes inside the owline
(Note-Included) and the rst cord comes
out easily.
Note: We join two cords because once we
remove the actual cord, there will be no
cord le in the owline, due to which there
will be diculty in inserng any other cord.
• Take out the cords from the owline and
une the other cord (Note-Included)
aached to the original cord.
• Loosen the knob of the Flycam Flowline
Edge and pull it out to unfold the edge
arm.
Note: Foldable design of Flycam Flowline
Edge makes it easy to store as you can
stash it anywhere.
• Unfold the Flowline Edge arm, align the
knob to the arm's top thread, insert it
and secure it properly by ghtening.
Flowline N Series Cord Disassembly
3
• You can use a sharp object to insert the
cord into the Flowline Edge. Make sure it
goes precisely in the center & near the
spring, up into the hole of the Flowline
Edge.
• Pull the cord from the boom of the
edge arm while sll holding it upside
down. Loosen & remove the knob.
• Insert the cord into the cord lock and
then put it in its place.
• Insert the knob and ghten it. Then insert
the cord into the camera hook cup.
• Then Knot the cord, make a bundle of it,
and put it in the camera hook cup as
shown.
• Aach the camera hook to the Edge arm
and secure the screws using an Allen key,
as shown in the picture.
4
• Aach the Edge arm to the support
jacket (Not Included) by simple push-t
technique.
• Image showing edge arm properly
aached to the jacket (Not Included).
Note: Flowline edge is compable with all
Flowline N series and Master jacket.
• Loosen/ghten the arm bolt to reduce/
increase the load capacity. You can adjust
it according to your setup requirement.
Note: The payload capacity of the spring is
5-25kg. The Edge system has a Spring
Mechanism with Tension Adjustment Knob
to adjust the arm according to your camera
setup.
• The Edge Arm oers vercal lng from
110° to 80°. Hence, it supports you to
take low-angle shots with ease.
• The Edge Arm captures every angle with
its le/right rotaon.
• Loosen the knob of the hook and aach
the camera to it.
5
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our
company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
YOUR FLYCAM FLOWLINE EDGE STABILIZATION ARM
ALL DRESSED UP AND READY TO GO!
• Tighten the knob to ensure a slip-free
connecon. Adjust the posion of the
camera setup easily by sliding the knob
from front to back.
• Images showing the Edge System working
perfectly with various setups.
