Foscam X4 Bedienungsanleitung
1
User
User Manual
Manual
2K/QHD Wireless IP Camera
Model: X4
V3.0
2
Table of Contents
1 Overview............................................................................................................................................................................. 3
1.1 Key Features...........................................................................................................................................................3
1.2 Read before Use.................................................................................................................................................... 3
1.3 Packing Contents................................................................................................................................................... 3
1.4 Physical Description.............................................................................................................................................. 4
1.5 SD Card Management...........................................................................................................................................5
1.6 Add Device: Connection via the Foscam App................................................................................................... 5
1.7 Installation............................................................................................................................................................... 5
2 Default Parameters........................................................................................................................................................... 7
3 Specification....................................................................................................................................................................... 7
3
1 Overview
1.1 Key Features
4.0 Mega-Pixel
H.264+/H.264 video Compression
Supports 2.4GHz and 5GHz network
Supports Human detection, Motion Detection and Sound Detection
Compatible with free Foscam Video Management Software
Compatible with free Foscam iOS and Android APP
Supports Full Duplex two-way Audio
Nightvision with 940nms LEDs, no light pollution
Supports voice prompt
Supports 256GB Micro SD Card storage(External)
IR Range up to 8m(26ft)
P2P Feature for Easy Remote Access
Supports image snapshot
Supports dual-stream
Supports remote viewing & record from anywhere anytime
Multi-level users management with password protection
Supports multiple network protocols: IP, TCP, UDP, SMTP, FTP, DHCP, RTSP
Supports Alexa
Supports Google Assistant
1.2 Read before Use
Please first verify that all contents received are complete according to the Package Contents listed below.
Before the Network Camera is installed, please carefully read and follow the instructions in the Quick Setup
Guide to avoid damage due to faulty assembly and installation. This also ensures the product is used properly
as intended.
1.3 Packing Contents
● IP Camera × 1
● AC Adapter × 1
● Quick Setup Guide × 1
● Power Line × 1
● mounting plate × 1
4
1.4 Physical Description
Front panel Rear panel
Front panel:
Status light: The flashing status of the Status light are shown in the following table.
Flashing Status
Description
Constantly bright (orange)
Powered on
Flashing(blue) every 0.4 seconds
Reset to take effect
Constantly bright (blue)
Wi-Fi connected
Flashing every(blue) 0.4 seconds and
keep on 3 seconds
One-button call
Flashing every(blue) 0.2 seconds
EZLink takes effect
Lens: Fixed focus lens.
Magnetic Bracket: Adsorbing on a ferromagnetic object using a magnet on the base
Rear panel:
One-button call /Reset
One-button call: Press and hold the button for 1 to 5 seconds to trigger One-button call, the status light will
blink every 0.4 seconds and keep on 3 seconds;
Reset: Press and hold the Reset button for more than 10 seconds to set the camera to factory default, the
Power light will blink every 0.4 seconds;
Speaker: Built-in speaker
Power: DC 5V/1A Power supply.
Microphone: Built-in microphone.
Micro SD Card slot: Supports up to 128GB SD card for storing the video.
5
1.5 SD Card Management
This camera supports Micro SD Card.
When you plug in the SD card during the camera work process, please reboot the camera again, or else the
SD card might not work well.
On Foscam app go to the SettingsDevice StatusDevice Status page, you can see the SD card status.
1.6 Add Device: Connection via the Foscam App
Scan the QR code below to download and install the Foscam APP.
Please refer to the Quick Setup Guide.
1.7 Installation
Please refer to the Quick Setup Guide.
1.7.1. Place Your Camera on a Flat Surface
You can place your camera on a flat surface (desk, shelf, Table, etc.).
6
1.7.2. Adsorbing on a ferromagnetic object using a magnet on the base
You can Adsorbing on a ferromagnetic object using a magnet on the base
1.7.3. Your Camera to the Wall
Install the mounting plate on a wall or ceiling with supplied fxing screws.
Note: Align points a and b to insert the camera base to the mounting plate. Rotate so that points a and b are
aligned, this attaches the camera securely to the base.
7
2 Default Parameters
Default network parameters
IP address: obtain dynamically
Subnet mask: obtain dynamically
Gateway: obtain dynamically
3 Specification
ITEMS
X4
Image Sensor
Sensor Type
High Definition Color CMOS Sensor
Display Resolution
4.0Megapixels(2560*1440)
Min. Illumination
N/A (Without IR Illuminator)
Lens
Lens Type
f 3.14mm; F2.2
Angle of view
Diagonal: 116.6°, Horizontal: 97.2°, Vertical: 52.6°
Video
Image Compression
H.264+/H.264
Image Frame Rate
Max 25fps (2K)
Resolution
2K(2560*1440) 25fps,3MP(2304x1296)25fps,1080P(1920x1080)
25fps,720P(1280 x 720), VGA(640 x 480), QVGA(320 x 240)
Stream
Dual stream
Image Adjustment
The hue, brightness, contrast, saturation, sharpness are adjustable
Flip Image
Flip and mirror
Infrared Mode
9pcs IR-LEDs (940nm)
Night Mode
Manual and automatic modes
Night Visibility
8m
Audio
Input/Output
Build-in two-way audio
Audio Compression
PCM/ G.726
Network
Ethernet
N/A
Wireless Standard
2.4GHz&5GHz,IEEE802.11b/g/n/ac
Data
Rate
IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.).
IEEE802.11ac: 433Mbps(Max.).
Wireless Security
WPA, WPA2
Remote Access
P2P
Wifi Configuration Mode
Support scan QR code , sound wave to add camera
Network Protocol
IP, TCP, UDP, SMTP, FTP, DHCP, RTSP
System
Requirements
Operating System
Microsoft Windows (Foscam VMS), MacOS (Foscam VMS), Android
(Foscam app), iOS (Foscam app)
Other Features
Motion Detection
Alarm via E-Mail, FTP and Foscam app when an event is detected
8
Sound Detection
Alarm via E-Mail, FTP and Foscam app when an event is detected
Human Detection
Alarm via E-Mail, FTP and Foscam app when an event is detected
Privacy Block
N/A
WDR
Improve image clarity in complex scenario
Zoom
6X digital zoom function
Storage
Support max. 256GB Micro SD card, local and FTP storage,Foscam
cloud storage
User Accounts
Three levels user role
One-button call
Press the button to call the mobile phone
Power
Power Supply
Micro USB 5V/1.0A
Power Consumption
5 Watts (Max.)
Physical
Dimension(LxWxH)
70(L)x70 (W)x120 (H)
Net Weight
165g
Environment
Waterproof
N/A
Operating Temperature
-10°C~ 40°C (14°F ~ 104°F)
Operating Humidity
20% ~ 85% non-condensing
Storage Temperature
-20°C ~ 60°C (-4°F ~ 140°F)
Storage Humidity
0% ~ 90% non-condensing
Certification
CE, FCC, RoHS,WEEE
For other parts, please refer to the “FOSCAM Camera User Manual”
