Fujitsu FI-5530C2 Referenzhandbuch

Fujitsu SCSI Scanner Installation Procedures

Windows 95\98\98SE\ME\2000\XP\Vista

Rev082708A Page 1 of 1

If you are installing the following models by means of the SCSI interface then please use this

document.

Fi-5530C2 Fi-6140 Fi-6670\A

Fi-6240 Fi-6770\A

Hardware requirements.

You will need a PC system that meets our recommended specifications, an appropriate SCSI

controller, and a SCSI cable (six foot recommended maximum). For recommended PC system

specifications and SCSI controllers please reference the Scanner Hardware Reference page.

You may also need your Operating System Disk.

Step A: Installing the SCSI Host Adapter (Adaptec).

1. Shut down your PC and remove the case cover.

2. Locate a free PCI slot and remove the back plate if necessary.

3. Install the SCSI controller in an open PCI slot.

Make sure that the card is seated completely in the slot and secured in the frame

Warning! Failure to secure the SCSI controller in the PC can result in damage to the

SCSI card, scanner, and/or your system.

4. Boot your PC without the scanner attached.

Step B: Installing the SCSI drivers (Adaptec).

5. When the New Hardware wizard comes up, allow Windows to finish installing the

hardware files for the SCSI controller.

6. Then either install/update the ASPI drivers from the CD or go to www.adaptec.com,

and click on the “search” tab.

7. For Windows 95\98 or ME scroll down to the “Enter key word or quoted phrase” box

and type in “aspi32”.

8. Next scroll down to the drivers section, click on ASPI32 and follow the prompts to

download it your desktop or a new folder.

9. Afterwards go to that location and double click on the "aspi32.exe" icon and follow

the prompts.

10. When the message “ASPI is up to date” appears, reboot and go to the next step.

11. For Windows 2000 or XP scroll down to the “Enter key word or quoted phrase” box

and type in “aspi”.

12. Next scroll down to the drivers section, click on ASPI_v470 or higher and follow the

prompts to download it.

13. Afterwards go to that folder and unzip the file to the default Adaptec\ASPI folder.

14. Then go to start, run, browse to the Adaptec\ASPI folder, select ASPIINST.EXE and

run it.

15. When the message “ASPI is up to date” appears, reboot and go to the next step.

Fujitsu SCSI Scanner Installation Procedures

Windows 95\98\98SE\ME\2000\XP\Vista

Rev082708A Page 2 of 2

Step C: Installing the drivers from the Setup CD.

To begin it is recommended that you install the drivers first before connecting the scanner.

Installing the STI-Twain driver.

1. Insert the Scanner Setup CD into your CD Rom.

2. Next please complete the pre-registration box when it appears and click the submit

button.

3. Afterwards close your browser and click the Install Products button on the Scanner

Setup Menu.

4. On the next screen click on Twain Driver and you may be presented with the option

to install the Error Recovery Guide.

5. After you have installed the Error Recovery Guide (or not) follow the prompts to

complete the twain driver installation.

6. Do not reboot at this time!

Installing the ASPI-Twain driver.

Some of our scanners are not supported by the STI-Twain drivers. For those units you

must install the ASPI-Twain driver. Please refer to the driver download page to see if

your model is one of them.

7. Insert the Scanner Setup CD into your CD Rom.

8. Next please complete the pre-registration box when it appears and click the submit

button.

9. Afterwards close your browser and click the Install Products button on the Scanner

Setup Menu.

10. On the next screen click on Twain Driver and you may be presented with the option

to install the Error Recovery Guide.

11. After you have installed the Error Recovery Guide (or not) follow the prompts to

complete the twain driver installation.

12. Do not reboot at this time!

Installing the ISIS driver.

13. Next go back to the Scanner Setup Menu and click on ISIS Driver.

14. If you didn’t install the Error Recovery Guide during the Twain driver installation you

will be asked again. Proceed and follow the prompts to complete the ISIS driver

installation.

15. Do not reboot at this time!

Installing ScandAll Pro.

16. Back to the Scanner Setup Menu and click on ScandAll Pro.

17. The ScandAll 21 installation wizard will appear. Click next and follow the prompts to

complete the installation.

18. Once all of the above is completed then remove the Scanner Setup CD, Reboot

your system, and go to Step E.

Fujitsu SCSI Scanner Installation Procedures

Windows 95\98\98SE\ME\2000\XP\Vista

Rev082708A Page 3 of 3

Step D: Installing the drivers from our Web Page.

Installing the STI-Twain driver.

1. Create a new folder and name it Fujitsu Downloads.

2. Next go to the following link Drivers and Downloads.

3. Fill in the pre-registration box when it pops up and continue to the drivers download

page.

4. Afterwards click on STI Twain Software Drivers.

5. Scroll down the list of scanner models in the left column and select the appropriate

STI Twain driver to the right of your scanner model.

6. Double click on the driver file name and the File Download box will popup.

7. Click on Save and then use the browse (or other folder navigation) button until you

have the Twain Download folder you created in the Save As box.

8. Click Save.

9. When completed close the Download Complete window and go to the Twain

Download folder.

10. Open the folder and you will see the saved driver file. Double click on the file to

unzip it and the WinZip* self-extractor box will popup. Click on browse and select the

Fujitsu Downloads folder, then click on Extract. The file will begin to unzip and

when finished a message box will report the number of files unzipped. Click on OK

and close WinZip.

11. In the STI Twain Download folder locate the setup.exe file and double click.

Afterwards follow the prompts and reboot when finished

Installing the ASPI-Twain driver.

Some of our scanners are not supported by the STI-Twain drivers. For those units you

must install the ASPI-Twain driver. Please refer to the driver download page to see if

your model is one of them.

1. Create a new folder and name it Fujitsu Downloads.

2. Next go to the following link and click on Drivers and Downloads.

3. Fill in the pre-registration box when it pops up and continue to the drivers download

page.

4. Afterwards click on ASPI Twain Software Drivers.

5. Scroll down the list of scanner models in the left column and select the appropriate

ASPI Twain driver to the right of your scanner model.

6. Double click on the driver file name and the File Download box will popup.

7. Click on Save and then use the browse (or other folder navigation) button until you

have the Twain Download folder you created in the Save As box.

8. Click Save.

9. When completed close the Download Complete window and go to the Twain

Download folder.

10. Open the folder and you will see the saved driver file. Double click on the file to

unzip it and the WinZip* self-extractor box will popup. Click on browse and select the

Fujitsu Downloads folder, then click on Extract. The file will begin to unzip and

when finished a message box will report the number of files unzipped. Click on OK

and close WinZip.

11. In the ASPI Twain Download folder locate the setup.exe file and double click.

Afterwards follow the prompts and reboot when finished

Fujitsu SCSI Scanner Installation Procedures

Windows 95\98\98SE\ME\2000\XP\Vista

Rev082708A Page 4 of 4

Installing the ISIS driver.

1. Create a new folder and name it Fujitsu Downloads.

2. Next go to the following link and click on Drivers and Downloads.

3. Fill in the pre-registration box when it pops up and continue to the drivers download

page.

4. Afterwards click on ISIS Software Drivers.

5. Scroll down the list of scanner models in the left column and select the appropriate

ISIS driver to the right of your scanner model.

6. Double click on the driver file name and the File Download box will popup.

7. Click on Save and then use the browse (or other folder navigation) button until you

have the ISIS Download folder you created in the Save As box.

8. Click Save.

9. When completed close the Download Complete window and go to the ISIS

Download folder.

10. Open the folder and you will see the saved ISIS driver file. Double click on the file to

unzip it and the WinZip* self-extractor box will popup. Note and accept the default

folder it is creating then click on Extract. The file will begin to unzip and when

finished a message box will report the number of files unzipped. Click on OK and

close WinZip.

11. In the new ISIS folder that you noted earlier locate the setup.exe file and double

click. Afterwards follow the prompts and reboot when finished.

Step E: Unlocking the shipping lock.

If your model scanner does not have a flatbed then proceed to Step F.

The flatbed model scanners typically include a lock on the flatbed designed to protect

the scanner during shipment. Before the scanner can be used the shipping lock must be

unlocked. To unlock it do the following:

1. Located the shipping lock slider tab or knob either underneath or at the end of the

scanner.

2. Slide or rotate the lock to the unlock position.

Step F: Connecting the Scanner.

Warning! Ensure that the power is off when connecting or disconnecting the SCSI cable to the

scanner or workstation. Failure to follow the procedure above could result in damage to the

SCSI card, scanner, and/or your system.

The default SCSI ID setting for the scanners is 5. However, selecting a different SCSI

ID may be required when there are several devices on a SCSI chain. To change the

SCSI ID rotate the yellow dial of the SCSI ID selector on the unit. Setting the SCSI ID to

0, 1, or 7 is NOT recommended as these settings are typically reserved for hard drives

and the SCSI host adapter. Next if the scanner is the last device (only device) on the

SCSI chain then it must be terminated. If the scanner is not the last device on the SCSI

chain, then the terminator should be removed or turned off before connecting it to the

next SCSI device. SCSI termination is handled automatically by these models.

Fujitsu SCSI Scanner Installation Procedures

Windows 95\98\98SE\ME\2000\XP\Vista

Rev082708A Page 5 of 5

Typically the SCSI ports are located on the back of the scanner (the exceptions being

the Fi-5650C and Fi-6670\A which are on the front). Depending on the model the SCSI

port connector(s) may be one of the following:

A. 50-pin High Density (HD-50) or

B. 68-pin Wide SCSI.

Use the appropriate cable to connect the scanner to the SCSI controller in your PC and

ensure that all connections are securely fastened.

Special note: The Fi-6670A and Fi-6770A are equipped with a 68-pin Wide SCSI port

which is reserved for Hardware VRS usage only.

Finally connect the power cord to the scanner and a wall outlet then turn on the scanner.

For those models without a power switch plug in the power supply to the back of the

scanner. To establish communication between the Scanner and your PC system turn on

the scanner prior to turning on your system. The scanner power and LED/LCD display

will light up. Next after the scanner completes its startup initialization the LED/LCD will

display either ready or the number one. This indicates that the scanner is ready.

The New Hardware wizard will now pop up. Select search for the driver automatically

and follow the prompts. Since the driver is already installed on your system you do not

need to select search the internet. When completed you will see the scanner installed

under Imaging devices in Device Manager.

Step G: Scanning with ScandAll Pro.

To scan with Scandall Pro will require a little advance preparation because the Scan Menu has

three different scanner control zones (four if you include the “cancel” function).

1. Launch ScandAll Pro by clicking on the shortcut link on your desktop or manually by

clicking on Start, Programs, Fujitsu ScandAll Pro, Fujitsu ScandAll Pro.

2. After the Untitled Screen has open, click Scan on the Menu bar and go down to

zone three, then click Select Scanner.

3. Select the Fujitsu Twain source for your scanner by highlighting it and clicking

OK. You will only need to do this once unless you are scanning with multiple

sources.

4. Once you are back at the Untitled Screen click on Scan on the Menu bar and in zone

three click Select Settings to open the Twain User Interface..

5. Select the scanning parameters that you wish to use – Color mode, resolution,

paper size, etc…

6. Next under Scan Type choose either ADF or Flatbed in the dropdown box then

click OK.

7. Place your document in the ADF or on the Flatbed face down and click Scan on the

Menu bar and then in zone one the Scan Settings button. This is where you decide

what to do with the scanned image. E.G. Save to file, file type, file name, display

image after scan. For this test uncheck the Save to file box and click OK.

8. Now click Scan on the Menu bar and then back in zone one the Scan button.

9. After the documents are scanned the images will appear on the Untitled Screen.

Fujitsu SCSI Scanner Installation Procedures

Windows 95\98\98SE\ME\2000\XP\Vista

Rev082708A Page 6 of 6

Congratulations! You have successfully completed and tested your scanner installation.

Step H: Installing third party software applications.

After you have successfully installed all the Fujitsu software and hardware, then it is time

to install any additional third party scanning software that you wish to use. Please follow

the software manufacturer’s instructions for installation.

*If you do not have any unzipping software installed on your system, you can download a free

evaluation copy at www.winzip.com.

Andere Handbücher für FI-5530C2

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Fujitsu Scanner Handbücher

Fujitsu

Fujitsu M4097D - Fb 50PPM SCSI A3 Dupl 100Sht Adf Installationshandbuch

Fujitsu

Fujitsu S510 - ScanSnap - Document Scanner Bedienungsanleitung

Fujitsu

Fujitsu ScanSnap S1300i Bedienungsanleitung

Fujitsu

Fujitsu FI-4010CU Bedienungsanleitung

Fujitsu

Fujitsu fi-600F Handbuch

Fujitsu

Fujitsu PA03360-B505 - ScanSnap S500 Handbuch

Fujitsu

Fujitsu fi-6800 Bedienungsanleitung

Fujitsu

Fujitsu ScanSnap iX100 Bedienungsanleitung

Fujitsu

Fujitsu fi-4110CU Series Konfigurationshandbuch

Fujitsu

Fujitsu M3091DC Bedienungsanleitung

Fujitsu

Fujitsu M4099D Handbuch

Fujitsu

Fujitsu S510M - ScanSnap - Document Scanner Bedienungsanleitung

Fujitsu

Fujitsu fi-4860C Handbuch

Fujitsu

Fujitsu M3096EX Konfigurationshandbuch

Fujitsu

Fujitsu M3093GX Bedienungs- und Wartungshandbuch

Fujitsu

Fujitsu M3096EX Bedienungsanleitung

Fujitsu

Fujitsu 6240 - fi - Document Scanner Handbuch

Fujitsu

Fujitsu PA03630-B055 Bedienungsanleitung

Fujitsu

Fujitsu Fi-4750c - Color Duplex Document Scanner 50ppm 90ipm... Konfigurationshandbuch

Fujitsu

Fujitsu FI-5530C2 Bedienungsanleitung

Fujitsu

Fujitsu ScanSnap FI-4110EOX2 Bedienungsanleitung

Fujitsu

Fujitsu FI-6000NS Handbuch

Fujitsu

Fujitsu M3096EX Handbuch

Fujitsu

Fujitsu fi-4340C Konfigurationshandbuch

Beliebte Scanner Handbücher anderer Marken

Plustek

Plustek Scanner Bedienungsanleitung

Z/I Imaging

Z/I Imaging PhotoScan 2001 Bedienungsanleitung

Renkforce

Renkforce DS100-5M Bedienungsanleitung

Image Access

Image Access WideTEK A2 Bedienungsanleitung

Canon

Canon imageFORMULA CR-120N Bedienungsanleitung

GeoSlam

GeoSlam ZEB Horizon Montageanleitung

Kodak

Kodak i5800 Scanner Bedienungsanleitung

Kodak

Kodak i7300 Bedienungsanleitung

Revopoint

Revopoint POP Bedienungsanleitung

Eddyfi Technologies

Eddyfi Technologies Floormap X Bedienungsanleitung

Faselase

Faselase F6 Bedienungsanleitung

Uniden

Uniden BC340CRS Bedienungsanleitung

Infinite Peripherals

Infinite Peripherals INFINEA TAB M Bedienungsanleitung

Mustek

Mustek PageExpress 4800 Pro Bedienungsanleitung

Optex

Optex 750830 Bedienungsanleitung

Innova

Innova 5210 Bedienungsanleitung

Visioneer

Visioneer CardReader 100 Kurzanleitung

Rohde & Schwarz

Rohde & Schwarz TSME6 Bedienungsanleitung
