Fujitsu BS2000 SE Series Bedienungsanleitung

English

Fujitsu Server BS2000 SE Series

Quick Guide

User Guide

Valid for:

M2000 V6.3A

X2000 V6.3A

HNC V6.3A

Edition December 2019

Comments… Suggestions… Corrections…

The User Documentation Department would like to know your opinion on this manual. Your feedback helps us to

optimize our documentation to suit your individual needs.

Feel free to send us your comments by e-mail to: .[email protected]

Certified documentation according to DIN EN ISO 9001:2015

To ensure a consistently high quality standard and user-friendliness, this documentation was created to meet the

regulations of a quality management system which complies with the requirements of the standard DIN EN ISO

.9001:2015

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

The Xen® mark is a trademark of Citrix Systems, Inc., which manages the mark on behalf of the Xen open source

community. The Xen® mark is registered with the U.S. Patent and Trademark Office, and may also be registered in

other countries.

Novell and SUSE are registered brands of Novell, Inc. in the USA and other countries.

Linux is a registered brand of Linus Torvalds.

Windows® is a registered trademark of Microsoft Corporation.

The Linux-based basic software M2000, X2000, and HNC which is installed on the Management Unit, Server Unit

x86, and HNC contains Open Source Software. The licenses for this can be found in the LICENSES directory on

the relevant installation DVD.

Table of Contents
Quick Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Calling the SE Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1 How do I log in on the SE Manager? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 How do I log out of the SE Manager? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 How do I power on a Management Unit via the local console? . . . . . . . . . . . 10
4 How do I power on a Management Unit via iRMC? . . . . . . . . . . . . . . . . . . . . . 12
Powering on, starting up BS2000, powering off . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1 How do I power on Server Units and other units via the SE Manager? . . . . 16
2 How can I boot the BS2000 on an SU /390? . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3 How can I boot the BS2000 on an SU x86? . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4 How can I boot the BS2000 via the SE Manager? . . . . . . . . . . . . . . . . . . . . . . 25
5 How do I open or close a BS2000 dialog? . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6 How do I open a BS2000 console? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7 How can I shut down the BS2000 via the BS2000 console? . . . . . . . . . . . . . 29
8 How do I power off Server Units and other Units? . . . . . . . . . . . . . . . . . . . . . 30
Powering on/off Application Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
1 How do I power on/off an AU via iRMC? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
2 How do I power on/off an AU via the SE Manager? . . . . . . . . . . . . . . . . . . . . 35
Working with AIS Connect (remote service) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
1 How do I change the AIS Connect Service access? . . . . . . . . . . . . . . . . . . . . 37
2 How do I open a shadow terminal? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3 How do I restart the AIS Connect Service Agent? . . . . . . . . . . . . . . . . . . . . . 39
4 How do I delete the AIS session logging files? . . . . . . . . . . . . . . . . . . . . . . . . 40
Notes for error situations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
1 How do I generate diagnostic data? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
2 How do I deploy diagnostic data for the Customer Support? . . . . . . . . . . . . 43

Quick Guide

1 Introduction

With the FUJITSU Server BS2000 SE Series (SE servers), FUJITSU offers a server infrastructure which consists of

two server lines.

Depending on requirements, an SE server contains all the system components needed for operation as an overall

application:

/390-based BS2000 Server Unit

x86-based Server Units with BS2000 guest systems, SU300 also with Linux or Windows guest systems as an

option

x86-based Application Units for operation under e.g. Linux, Windows or VMware

Shareable tape and disk periphery

A high-speed, server-internal infrastructure to connect the components with each other and with the customer

LAN or SAN.

Information on using the Quick Guide

This Quick Guide is intended for people who operate an SE server and contains short instructions for the most

important scenarios when placing the SE server in service. The following requirements should be met:

Customer Support provides the customer with the SE server.

The desired BS2000 operating mode is set on each Server Unit.

A BS2000 system is configured and fully operational.

All necessary BS2000 devices are configured.

A detailed description of the SE Manager's functionality with the usage of the base software (M2000/X2000/HNC)

V6.3A is included in the “Operation and Administration” manual and in the SE Manager's online help.

Please note the following:

The base system of the MU (M2000) as well as the iRMC of the MU have a predefined administrator

account at the time the SE server is delivered. In both cases an initial password is preset, which

admin

you can ask for at the service.

Change the password immediately after you have logged in for the first time.

You may also change the validity time and the other password attributes.

You can access the password management as follows:

in SE Manager:

Authorizations

Users -> Password management

on the iRMC S4:

User management -> iRMC S4 users

on the iRMC S5 (with MU M3):

Settings User Management iRMC Local user accounts-> ->

2 Calling the SE Manager

This chapter contains the following topics:

How do I log in on the SE Manager?

How do I log out of the SE Manager?

How do I power on a Management Unit via the local console?

How do I power on a Management Unit via iRMC?

2.1 How do I log in on the SE Manager?

Requirement

A Management Unit is powered on. It might be necessary to power on a Management Unit (MU) first, to make

the access to the SE Manager possible (see or"How do I power on a Management Unit via the local console?"

)."How do I power on a Management Unit via iRMC?"

If IP-based access rights are configured for accessing the SE server, the IP address of the PC must have a

permission.

Procedure

>Enter the FQDN (Fully Qualified Domain Name) or IP address of the active MU into the address bar of the

browser and press enter:

The connection is established and the login window opens:

>Enter your account and the respective password in the login window.

If the browser now displays a warning about the security certificate, click .

Continue to this website

The procedure for confirming or importing a certificate is described in more detail in the

"Administration and Operation" user guide in section "Confirming/importing a certificate in the web

browser".

The login window is also displayed to permit you to log in again if you have logged out or the

session was terminated owing to inactivity.

Change the initial password for the account

admin

immediately after the first login (see also

information in chapter "Introduction" ).

>Click .

The tab opens as the welcome page. It provides a quick overview of the systems, Units or Units

Dashboard

/Partitions, IP networks, FC networks, Storage, Cluster, Users, and Events of the SE server.

2.2 How do I log out of the SE Manager?

Logging out explicitly

In the header area of the SE Manager main window click to terminate the session:

Log out

You will then be forwarded to the login window (for logging in again).

Logging out because of a session timeout

If you do not log out explicitly, the session terminates if there is no activity for 20 minutes, i.e. if the SE Manager

registers no activity in this time. The default session timeout is set to 20 minutes and can be changed individually:

>In the header area of the SE Manager's main window click on the arrow next to the login name and then, in

the drop down list, click to display the dialog for changing the session timeout:

Individual settings

When you want to start an activity in the SE Manager after a session has timed out, first the login window

appears, and you must log in again. Only after you have done this will the activity be executed.

When you close the browser window without logging out, then your session remains valid until session

timeout. This means that when calling the MU start address again, you will not be prompted to login.

Instead, the last opened page of the SE Manager is displayed again.

2.3 How do I power on a Management Unit via the local console?

Requirement

You are on the server rack of the SE server.

Procedure

>Open the server rack

>Pull out the tray with the local console and flip up the screen

>Press the power-on button on the MU

The MU powers itself on and starts up. The startup messages are output on the local console. As soon as the

system is ready, you receive the login request.

>Enter account and password of an administrator account

>Click

After a successful login the Gnome Desktop is loaded.

>Click in the task bar (bottom left), to open the application menu:

Computer

>Double-click the Firefox icon to open the browser.

>Enter into the address bar of the browser (or alternatively the FQDN of the powered-on MU) and

localhost

press enter:

By default the local console is attached to the MU. If the connection is attached to the Server Unit, switch

over to the MU using the console switch menu (press the HOT KEY to call it).

When the SE server is supplied, an initial password is set for standard account , which can be

admin

requested at the service. If it has already been changed (or you are using a different account), you must

enter the current password (see also ).section "How do I log in on the SE Manager?"
