PRIMERGY

PRIMERGY RX100 S3

Server System

Options Guide

Susanne Däschlein

Fujitsu Siemens Computers GmbH München

81730 München

e-mail: email: [email protected]

Tel.: (089) 61001155

Fax: (++49) 700 / 372 00000

U41617-J-Z156-1-76

Sprachen: En

Edition August 2005

Comments Suggestions Corrections

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Fax forms for sending us your comments are included in

the back of the manual.

There you will also find the addresses of the relevant

User Documentation Department.

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

U41617-J-Z156-1-76 Options Guide

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1 Overview of the documentation . . . . . . . . . . . . . . . . . . 5

1.2 Extensions and conversions . . . . . . . . . . . . . . . . . . . . 7

1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . . . 8

2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3 Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4.1 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 17

5 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 19

5.1 Equipping rules . . . . . . . . . . . . . . . . . . . . . . . . . 19

5.2 Extending/replacing the main memory . . . . . . . . . . . . . 21

6 Accessible drives . . . . . . . . . . . . . . . . . . . . . . . 23

6.1 Installing an accessible 5.25-inch slimline drive . . . . . . . . . 23

7 Hard disks . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

7.1 Installing a second non-hot-plug hard disk . . . . . . . . . . . 27

8 Controller in the PCI slots . . . . . . . . . . . . . . . . . . . 29

8.1 Installing a controller . . . . . . . . . . . . . . . . . . . . . . 29

9 RemoteView components . . . . . . . . . . . . . . . . . . . 33

9.1 RemoteView Service Board S2 LP . . . . . . . . . . . . . . . 33

10 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

10.1 Closing the server . . . . . . . . . . . . . . . . . . . . . . . . 37

11 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

11.1 Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

U41617-J-Z156-1-76 Options Guide 5

1Introduction

The PRIMERGY RX100 S3 server is an Intel-based server for small and

medium-sized networks. The compact server casing (only one height unit) as

well as its scalability and security features make the PRIMERGY RX100 S3 the

perfect choice for operational areas data centers, Internet- and application-

hosting.

1.1 Overview of the documentation

IPRIMERGY manuals are available in PDF format on the ServerBooks CD

which is supplied in the ServerView Suite package for every server

system.

These PDF files can also be downloaded free of charge from the

Internet: at http://manuals.fujitsu-siemens.com you will find an overview

page with the online documentation available on the Internet. You can go

to the PRIMERGY Server documentation by clicking on “industry

standard servers”.

Concept and target groups

This Options Guide shows you how you can expand and upgrade the server.

IThe Operating Manual for the server describes how you install/remove

the hot-plug components.

The activities described in this manual may only be performed by technical

specialists.

Additional documentation about the server

The PRIMERGY RX100 S3 documentation comprises the following additional

manuals:

– “Quick Start Hardware - PRIMERGY RX100 S3” (poster)

– “Quick Start Software - PRIMERGY ServerView Suite” (poster)

– “Warranty” manual (print version delivered together with the system, PDF file

available on the ServerBooks CD)

– “Safety” manual (print version delivered together with the system, PDF file

available on the ServerBooks CD)

– “Ergonomics” manual (PDF file available on the ServerBooks CD)

6 Options Guide U41617-J-Z156-1-76

Overview of the documentation Introduction

– “Returning used devices” (PDF file available on the ServerBooks CD)

– “Helpdesk” (poster with worldwide helpdesk telephone numbers)

– “PRIMERGY RX100 S3 Serversystem Operating Manual” (PDF file

available on the ServerBooks CD)

– Technical Manual for the system board D2004 (PDF file available on the

ServerBooks CD)

– “BIOS Setup” manual (PDF file available on the ServerBooks CD)

– “ServerView Suite” includes the ServerStart CD, the ServerBooks CD and the

print version of the manual “PRIMERGY ServerView Suite - ServerStart”.

The PDF file of the manual is also available on the ServerBooks CD.

IIf you need a backup of the ServerBooks CD, send the details of your

server via email address: [email protected].

– “Global Array Manager Client Software User’s Guide” (PDF file available on

the ServerBooks CD)

– “Global Array Manager Server Software User’s Guide” (PDF file available on

the ServerBooks CD)

– “LSI SATA Software RAID User’s Guide” (PDF file available on the Server-

Books CD)

Further sources of information:

– Technical Manual on the relevant rack

– Manual on the monitor

– Manual on ServerView Server Management

– Manual on the RemoteView Remote Test and Diagnostics System

– Documentation on your operating system

– Information files on your operating system

(see also “Related publications” on page 47)

U41617-J-Z156-1-76 Options Guide 7

Introduction Extensions and conversions

1.2 Extensions and conversions

Extension of the main memory

The four slots for the main memory are suitable for unbuffered PC2-533

(PC2-4200) DDR2 SDRAM memory modules. The organization in two memory

banks, 1 and 2, permits rapid memory access with two-way interleaving.

If the memory modules are populated in pairs, each pair must consist of

identical memory modules (2-way interleaved mode).

Additional accessible drive

One 5.25-inch slimline bay is available for accessible drives.

Additional SATA hard disk drive

A second bay is available for SATA hard disk drives.

Additional controllers in the PCI slots

The system board offers 2 x PCI-X (64 Bit / 100 MHz) or 1x PCI-Express x4 and

2 x PCI-X (64 Bit / 100 MHz) slots by a riser card.

RemoteView Service Board S2 LP

The RemoteView Service Board S2 LP (RSB S2 LP) is a PCI board with a

completely independent system, i.e. it has its own operating system with Web

server and SNMP agents and can optionally be equipped with an external

power supply. The RSB S2 LP permits remote diagnosis for system analysis,

remote system configuration and remote restart even in the event of operating

system failure or hardware faults. It has its own LAN connection and its own

COM port. All the functions of the RSB S2 LP are thus available either via a LAN

or modem.

8 Options Guide U41617-J-Z156-1-76

Notational conventions Introduction

1.3 Notational conventions

The following notational conventions are used in this manual:

Text in italics indicates commands, menu items or software programs.

„Quotation marks“ indicate names of chapters and terms that are being

emphasized.

Êdescribes activities that must be performed in the order

shown.

VCAUTION! pay particular attention to texts marked with this symbol.

Failure to observe this warning may endanger your life,

destroy the system or lead to the loss of data.

Iindicates additional information, notes and tips.

Table 1: Notational conventions

U41617-J-Z156-1-76 Options Guide 9

2Procedure

VCAUTION!

The actions described in these instructions should only be performed by

technical specialists. Equipment repairs should only be performed by

service personnel. Any unauthorized opening and improper repairs could

expose the user to risks (electric shock, energy hazards, fire hazards)

and could also damage the equipment. Please note that any unautho-

rized opening of the device will result in the invalidation of the warranty

and exclusion from all liability.

ÊFirst of all please familiarize yourself with the safety instructions in the

section chapter “Safety notes” on page 11 et seqq. .

ÊEnsure that all required manuals (see “Additional documentation about the

server” on page 5) are available, printing out the PDF files if necessary. You

will definitely need the Operating Manual for the server and the Technical

Manual for the system board.

ÊShut down the server correctly, switch it off, pull out the power plug(s), and

open the server as described in the chapter “Preparation” on page 17 et

seqq. .

ÊExtend or upgrade your server as described in the relevant chapter.

IThe Operating Manual for the server describes how you

install/remove the hot-plug components.

ÊClose the server, connect it to the power outlet, and switch it on as described

in the chapter “Completion” on page 37 et seqq. .

ÊStart the operating system and, if necessary, configure it as required (see

the Operating Manual).
