Fujitsu PRIMERGY RX800 S2 Bedienungsanleitung

Produktfamilie

PRIMERGY RX800 S2/S3 Server

Options Guide

Joachim Pichol

Fujitsu Siemens Computers GmbH Paderborn

33094 Paderborn

e-mail: email: [email protected]

Tel.: 05251 14888-18

Fax: (++49) 700 / 372 00001

Sprachen: En

Edition March 2007

This manual is printed on

paper treated with

chlorine-free bleach.

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Fax forms for sending us your comments are included in

the back of the manual.

There you will also find the addresses of the relevant

User Documentation Department.

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

Contents

1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.1 Documentation overview . . . . . . . . . . . . . . . . . . . . . . 1

1.2 Extensions and conversions . . . . . . . . . . . . . . . . . . . . 3

1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . . . . 6

2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3 Important notes . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.1 Notes on safety . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.2 Environmental Protection . . . . . . . . . . . . . . . . . . . . 15

4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4.1 Removing the server from the rack . . . . . . . . . . . . . . . 19

4.2 Opening the cover . . . . . . . . . . . . . . . . . . . . . . . . 21

4.3 Removing the bezel . . . . . . . . . . . . . . . . . . . . . . . 23

5Mainmemory. . . . . . . . . . . . . . . . . . . . . . . . . . 25

5.1 Fitting rules . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

5.2 Upgrading/exchanging main memory . . . . . . . . . . . . . . 28

5.3 Installing a memory card . . . . . . . . . . . . . . . . . . . . . 29

6 Processors . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

6.1 Installing additional processors . . . . . . . . . . . . . . . . . 32

6.2 Replacing the processor . . . . . . . . . . . . . . . . . . . . . 38

7Adapters. . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

7.1 Installing adapters . . . . . . . . . . . . . . . . . . . . . . . . 42

7.2 Installing a ServeRAID-8i adapter . . . . . . . . . . . . . . . . 42

8Completion. . . . . . . . . . . . . . . . . . . . . . . . . . . 45

8.1 Closing the server . . . . . . . . . . . . . . . . . . . . . . . . 45

8.2 Mounting the server in the rack . . . . . . . . . . . . . . . . . 46

Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

1 Preface

The PRIMERGY RX800 S2/S3 server system offers unique performance

density by packing up to four Intel®Xeon™ MP dual-core processors into a 3-

height (3U) building block (node).

Each node offers 6 PCI-X 2.0 slots and is equipped with a CD/DVD drive and

up to 6x2,5" hot-plug SAS hard disks. Full redundancy for power supplies and

fans as well as phase redundancy for AC line input is supported. Hard disks,

memory cards, fans units, power supply units, and PCI adapters are hot-

pluggable. All hot-plug operations are described in the Operating Manual.

Each node is either a base unit or an extension unit. Both units can be

combined to form an 8-way (6U) configuration. By combining two 8-way config-

urations, a 16-way (12U) configuration with four nodes can be assembled. The

assembly procedure is described in the Operating Manual.

Generally speaking, base unit and extension unit upgrade and conversion is

done in the same way. However, there are exceptions to this rule which are

explained in the appropriate chapter(s).

1.1 Documentation overview

IPRIMERGY manuals are available in PDF format on the ServerBooks CD,

which is part of the PRIMERGY ServerView Suite provided with each

server system.

The PDF files for the manuals can also be downloaded free of charge

from the Internet. The overview page showing the online documentation

available on the Internet can be found via the URL:

http://manuals.fujitsu-siemens.com (choose: industry standard servers).

Concept and target groups

This Options Guide shows you how to expand and upgrade your server.

VCAUTION!

The activities described in this manual may only be performed by

specialist personnel with technical training.

Documentation overview Preface

IThe installation and removal of the hot-plug components is described in

the Operating Manual supplied with the server. This applies to memory

cards, hard disk drives, system fans, power supply units, and PCI boards.

Additional components of the system documentation

The PRIMERGY RX800 S2/S3 documentation comprises the following

documentation:

– “Warranty” manual (printed copy always supplied with the server, and

available as a PDF file on the ServerBooks CD supplied)

– “Safety” manual (printed copy always supplied with the server, and available

as a PDF file on the ServerBooks CD supplied)

– “Ergonomics” manual (PDF file available on the ServerBooks CD supplied)

– Operating Manual for PRIMERGY RX800 S3 (PDF file available on the

ServerBooks CD supplied)

– Service Supplement for PRIMERGY RX800 S2/S3 (PDF file available on the

ServerBooks CD supplied)

– "RemoteView Management Board RSA-II User Manual" (PDF file available

on the ServerBooks CD supplied)

– "ServeRAID-8i HDD Controller User Manual" (PDF file available on the

ServerBooks CD supplied)

– "ServerView Suite" includes the ServerStart CD, the ServerBooks CD and the

ServerSupport CDs. The PDF version of the user manual "PRIMERGY -

ServerView Suite - ServerStart" is also available on the ServerBooks CD.

IYou can order a supplementary ServerBooks CD by sending an e-mail

to the following address, quoting your server data:

Reklamat-PC-LO[email protected]

Further sources of information:

– Technical Manual for the relevant rack

– Manual for the monitor

– Manual on ServerView Server Management

– Manual on the RemoteView Remote Test and Diagnostics System

– Documentation for your operating system

– Information files on your operating system

(see also chapter “Related publications” on page 55)

Preface Extensions and conversions

1.2 Extensions and conversions

Main memory

In the basic configuration (base/extension unit), two memory cards are supplied

with either 2 GB or 4 GB of memory installed in memory card A.

The system board offers four hot-plug memory cards (A to D) slots, each of

which can accommodate up to four DIMMs (in two memory banks each). The

slots are suitable for DDR RAM PC2-3200 ECC DIMMs with 2 GB or 4 GB

capacity, depending on the type of memory. Thus, each node supports up to 32

GB (64 GB) of system memory.

No mixing of DIMM types is allowed within one memory bank. Memory mirroring

is only possible if DIMM types are identical between mirrored memory banks.

Memory upgrade/exchange with the server switched off is described in chapter

“Main memory” on page 25.

IThe hot-plug memory card exchange and upgrade procedure is

described in the Operating Manual.

Processors

In the basic configuration (base/extension unit), the system comes with two

microprocessors. You can install up to four microprocessors to further enhance

performance and symmetric multiprocessing (SMP) capability.

You may only use processors of the same type on the system board. All

processors must have the same frequency and cache size.

Processor upgrade/exchange is described in chapter “Processors” on page 31.

Accessible drives

The basic configuration (base/extension unit) includes a CD/DVD drive.

However, this drive is disabled in the extension unit of an 8-way configuration.

IIn 16-way configuration, only one CD/DVD drive is operable.

No built-in accessible drives are available. Therefore, additional drives must be

plugged in via the USB port. This can be done while the system is up and

running.

Extensions and conversions Preface

Adapters in PCI slots

The server is equipped with six PCI-X 2.0 slots, all offering 64-bit support,

operating at 266 MHz, and supporting hot-plug functionality.

The following adapter types are available:

●PCI adapters for external SCSI storage system

If you want to connect additional external SCSI devices, up to two 1-channel

PCI SCSI adapters may optionally be installed per scalable partition.

●PCI adapters for external disk arrays

If you want to connect additional external disk arrays, up to four 2-channel

PCI RAID adapters may optionally be installed per scalable partition.

●PCI Fibre Channel adapters

Up to four 1-channel Fibre Channel PCI adapters for subsystems and SAN

(Storage Area Network) may optionally be installed per scalable partition.

●Single-port or dual-port PCI LAN adapters

The server comes with an integrated Broadcom dual-port LAN adapter.

Up to four single-port PCI LAN adapters may optionally be installed per

scalable partition

Up to three dual-port PCI LAN adapters may optionally be installed per

scalable partition.

PCI card upgrade with the server switched off is described in chapter “Adapters”

on page 41.

IInstallation of hot-plug adapters is described in the Operating Manual.

Preface Extensions and conversions

SAS/RAID adapters

In addition to the six standard PCI slots, a dedicated PCI slot is reserved for the

ServerRAID-8i RoMB adapter (controller).

By default, the base unit has a ServeRAID-8i adapter installed to handle up to

six hard disk drives. This adapter works in conjunction with the onboard SAS

controller.

In the extension unit, a ServeRAID-8i adapter is optionally available. However,

in a multi-node configuration, a maximum of two adapters is allowed to handle

up to 12 hard disk drives.

IIn a 16-way configuration, a ServeRAID-8i adapter is installed in both

base units. Consequently, no more optional adapters are allowed for any

of the two extension units.

ServeRAID-8i upgrade is described in chapter “Adapters” on page 41.

IAn BBU (Battery Backup Unit) is integrated in the ServeRAID-8-i adapter

to protect its memory contents in the event of a power failure. Lithium

battery exchange is described in the Service Supplement.

Notational conventions Preface

1.3 Notational conventions

The following notational conventions are used in this manual:

Italics indicate commands, menu items or software programs.

“Quotation marks” indicate names of chapters and terms that need to be

emphasized.

Êindicates an activity that must be performed.

VCAUTION! indicates that, if you ignore the information given at this

point, your health, the correct functioning of your

system or the security of your data may be at risk.

Iindicates supplementary information, remarks and tips.

Table 1: Notational conventions

Andere Handbücher für PRIMERGY RX800 S2

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Fujitsu Server Handbücher

Fujitsu

Fujitsu Primergy TX300 S4 Kurzanleitung

Fujitsu

Fujitsu PRIMERGY RX2530 M4 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise T2000 Bedienungsanleitung

Fujitsu

Fujitsu primergy h250 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX300 S7 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY ECONEL30 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX200 S3 Bedienungsanleitung

Fujitsu

Fujitsu primequest 2400E2 Leitfaden

Fujitsu

Fujitsu PRIMEQUEST 1000 Series Bedienungsanleitung

Fujitsu

Fujitsu Primergy CX250 S2 Bedienungsanleitung

Fujitsu

Fujitsu D3320 PRIMERGY BX2560 M2 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX1330 M2 Bedienungsanleitung

Fujitsu

Fujitsu PRIMEQUEST 1000 Series Service-Handbuch

Fujitsu

Fujitsu PRIMERGY 870 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise M4000 Installationsanleitung

Fujitsu

Fujitsu PRIMERGY BX924 S2 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX100 S3 Bedienungsanleitung

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY BX620 S4 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY CX420 S1 Bedienungsanleitung

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Service-Handbuch

Fujitsu

Fujitsu PRIMERGY RX4770 M6 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise M5000 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX1320 M5 Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung
